interrupt vector addresses
The interrupt vectors and the power-up starting address are located in the address range of 0FFFFh to 0FFC0h.
The vector contains the 16-bit address of the appropriate interrupt handler instruction sequence.
If the reset vector (located at address 0FFFEh) contains 0FFFFh (e.g., flash is not programmed) the CPU goes
into LPM4 immediately after power up.
INTERRUPT SOURCE INTERRUPT FLAG SYSTEM INTERRUPT WORD ADDRESS PRIORITY
Power-up
External reset
Watchdog
Flash key violation
PC out-of-range (see Note 1)
PORIFG
RSTIFG
WDTIFG
KEYV
(see Note 2)
Reset 0FFFEh 31, highest
NMI
Oscillator fault
Flash memory access violation
NMIIFG
OFIFG
ACCVIFG
(see Notes 2 & 4)
(non)-maskable,
(non)-maskable,
(non)-maskable
0FFFCh 30
Timer_B3 TBCCR0 CCIFG (see Note 3) maskable 0FFFAh 29
Timer_B3
TBCCR1 and TBCCR2
CCIFGs, TBIFG
(see Notes 2 and 3)
maskable 0FFF8h 28
0FFF6h 27
Watchdog Timer WDTIFG maskable 0FFF4h 26
Timer_A3 TACCR0 CCIFG (see Note 3) maskable 0FFF2h 25
Timer_A3
TACCR1 CCIFG.
TACCR2 CCIFG
TAIFG (see Notes 2 and 3)
maskable 0FFF0h 24
USCI_A0/USCI_B0 Receive
UCA0RXIFG, UCB0RXIFG
(see Notes 2)
maskable 0FFEEh 23
USCI_A0/USCI_B0 Transmit
UCA0TXIFG, UCB0TXIFG
(see Notes 2)
maskable 0FFECh 22
ADC10 ADC10IFG (see Note 3) maskable 0FFEAh 21
0FFE8h 20
I/O Port P2
(eight flags)
P2IFG.0 to P2IFG.7
(see Notes 2 and 3)
maskable 0FFE6h 19
I/O Port P1
(eight flags)
P1IFG.0 to P1IFG.7
(see Notes 2 and 3)
maskable 0FFE4h 18
0FFE2h 17
0FFE0h 16
(see Note 5) 0FFDEh 15
(see Note 6) 0FFDCh ... 0FFC0h 14 ... 0, lowest
NOTES: 1. A reset is generated if the CPU tries to fetch instructions from within the module register memory address range (0h−01FFh) or from
within unused address ranges.
2. Multiple source flags
3. Interrupt flags are located in the module.
4. (non)-maskable: the individual interrupt-enable bit can disable an interrupt event, but the general interrupt enable cannot.
Nonmaskable: neither the individual nor the general interrupt-enable bit will disable an interrupt event.
5. This location is used as bootstrap loader security key (BSLSKEY).
A 0AA55h at this location disables the BSL completely.
A zero (0h) disables the erasure of the flash if an invalid password is supplied.
6. The interrupt vectors at addresses 0FFDCh to 0FFC0h are not used in this device and can be used for regular program code if
necessary.
