REVISION HISTORY
Date Revision Comments
07/18/06 A Combine 5 data sheets into one data sheet.
07/31/06 B Update Package Marking
11/29/06 C Update Features
Update Pin Configuration
Update Functional Symbol
Added 8-Lead MSOP Package Outline
Remove Package Marking
Update Example of Ordering Information
