CAT24C01/02/04/08/16
13
Doc No. 1115, Rev. C
© 2006 by Catalyst Semiconductor, Inc.
Characteristics subject to change without notice
8-Lead MSOP (Z)
c
E
E1
e
b
D
A2
A
A1
L2
GAUGE
PLANE
L
L1
SYMBOL MIN NOM MAX
A 1.1
A1 0.05 0.10 0.15
A2 0.75 0.85 0.95
b 0.28 0.33 0.38
c
D 2.90 3.00 3.10
E 4.80 4.90 5.00
E1 2.90 3.00 3.10
e 0.65 BSC
L 0.35 0.45 0.55
L1
L2
0° 6°
8-lead_MSOP.eps
Notes:
(1) All dimensions are in millimeters. Angels in degrees.
(2) Complies with JEDEC specification MS-187.
(3) Stand off height/coplanarity are considered as special characteristics.
For current Tape and Reel information,
download the PDF file from:
http://www.catsemi.com/documents/tapeandreel.pdf.
