CAT24C04WI-G

Part # CAT24C04WI-G
Description EEPROM Serial-I2C 4K-bit 512x 8 1.8V/2.5V/3.3V/5V 8-Pin S
Category IC
Availability In Stock
Qty 39
Qty Price
1 + $0.08670
Manufacturer Available Qty
ON Semiconductor
Date Code: 1048
  • Shipping Freelance Stock: 39
    Ships Immediately

Related Items

CAT24C04P
CSI
IC
CAT24C04P
$1.06972
CAT24C08YI-GT3
ON Semiconductor
IC
CAT24C08YI-GT3
$0.07855
CAT24C64WI-GT
ON Semiconductor
IC
CAT24C64WI-GT
$0.76230
CAT24WC256K
CSI
IC
CAT24WC256K
$27.71322
008-25424
Fairchild Semiconductor
IC
008-25424
$11.58351
01-6945-9
Harris Corporation
IC
01-6945-9



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

CAT24C01, CAT24C02, CAT24C04, CAT24C08, CAT24C16
http://onsemi.com
10
PACKAGE DIMENSIONS
SOIC 8, 150 mils
CASE 751BD
ISSUE O
E1 E
A
A1
h
θ
L
c
e
b
D
PIN # 1
IDENTIFICATION
TOP VIEW
SIDE VIEW
END VIEW
Notes:
(1) All dimensions are in millimeters. Angles in degrees.
(2) Complies with JEDEC MS-012.
SYMBOL MIN NOM MAX
θ
A
A1
b
c
D
E
E1
e
h
0º 8º
0.10
0.33
0.19
0.25
4.80
5.80
3.80
1.27 BSC
1.75
0.25
0.51
0.25
0.50
5.00
6.20
4.00
L
0.40 1.27
1.35
CAT24C01, CAT24C02, CAT24C04, CAT24C08, CAT24C16
http://onsemi.com
11
PACKAGE DIMENSIONS
TSSOP8, 4.4x3
CASE 948AL
ISSUE O
E1
E
A2
A1
e
b
D
c
A
TOP VIEW
SIDE VIEW
END VIEW
q1
L1
L
Notes:
(1) All dimensions are in millimeters. Angles in degrees.
(2) Complies with JEDEC MO-153.
SYMBOL
θ
MIN NOM MAX
A
A1
A2
b
c
D
E
E1
e
L1
0º 8º
L
0.05
0.80
0.19
0.09
0.50
2.90
6.30
4.30
0.65 BSC
1.00 REF
1.20
0.15
1.05
0.30
0.20
0.75
3.10
6.50
4.50
0.90
0.60
3.00
6.40
4.40
CAT24C01, CAT24C02, CAT24C04, CAT24C08, CAT24C16
http://onsemi.com
12
PACKAGE DIMENSIONS
MSOP 8, 3x3
CASE 846AD
ISSUE O
E1E
A2
A1 e b
D
c
A
TOP VIEW
SIDE VIEW END VIEW
L1
L2
L
DETAIL A
DETAIL A
Notes:
(1) All dimensions are in millimeters. Angles in degrees.
(2) Complies with JEDEC MO-187.
SYMBOL
MIN NOM MAX
q
θ
A
A1
A2
b
c
D
E
E1
e
L
0º 6º
L2
0.05
0.75
0.22
0.13
0.40
2.90
4.80
2.90
0.65 BSC
0.25 BSC
1.10
0.15
0.95
0.38
0.23
0.80
3.10
5.00
3.10
0.60
3.00
4.90
3.00
L1 0.95 REF
0.10
0.85
