Texas Instruments JAN4N49

Cross Number:

Item Description: OPTOISO 1KV TRANS W/BASE TO78-6

Qty Price
1 + $12.69180



Other Cross Reference

Manufacturer Date Code Qty Available Qty
Texas Instruments 8745
  • Freelance Stock: 1
    Ships Immediately





Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

MICROPAC INDUSTRIES, INC. OPTOELECTRONIC PRODUCTS DIVISION 725 E.Walnut St., Garland, TX 75040 (972) 272-3571 Fax (972) 487-6918
www.micropac.com E-MAIL: optosales@micropac.com
3 - 14
4N47
4N48
JAN, JANTX, JANTXV, SINGLE CHANNEL OPTOCOUPLERS
4N49
Mii
OPTOELECTRONIC
PRODUCTS{PRIVATE }
DIVISION
Features:
High Reliability
Base lead provided for conventional transistor
biasing
Rugged package
High gain, high voltage transistor
+1kV electrical isolation
Applications:
Eliminate ground loops
Level shifting
Line receiver
Switching power supplies
Motor control
DESCRIPTION
Gallium Aluminum Arsenide (GaAlAs) infrared LED and a high gain N-P-N silicon phototransistor packaged in a hermetically
sealed TO-5 metal can. The 4N47, 4N48 and 4N49’s can be tested to customer specifications, as well as to MIL-PRF-19500
JAN, JANTX, JANTXV and JANS quality levels.
*ABSOLUTE MAXIMUM RATINGS
Input to Output Voltage.............................................................................................................................................................1kV
Emitter-Collector Voltage............................................................................................................................................................7V
Collector-Emitter Voltage (Value applies to emitter-base open-circuited & the input-diode equal to zero) ............................40V
Collector-Base Voltage .............................................................................................................................................................45V
Reverse Input Voltage ...............................................................................................................................................................2V
Input Diode Continuous Forward Current at (or below) 65°C Free-Air Temperature (see note 1) ......................................40mA
Peak Forward Input Current (Value applies for tw
< 1µs, PRR < 300 pps) ...............................................................................1A
Continuous Collector Current ................................................................................................................................................50mA
Continuous Transistor Power Dissipation at (or below) 25°C Free-Air Temperature (see Note 2) ..................................300mW
Storage Temperature........................................................................................................................................... -65°C to +125°C
Operating Free-Air Temperature Range ............................................................................................................. -55°C to +125°C
Lead Solder Temperature (1/16” (1.6mm) from case for 10 seconds) ................................................................................ 240°C
Notes:
1. Derate linearly to 125°C free-air temperature at the rate of 0.67 mA/°C above 65°C.
2. Derate linearly to 125°C free-air temperature at the rate of 3 mW/°C.
*JEDEC registered data
Package Dimensions Schematic Diagram
NOTE: ALL LINEAR DIMENSIONS ARE IN INCHES (MILLIMETERS)
6 LEADS
0.016Ø [0.41]
0.019Ø[0.48]
1
2
3
5
6
7
0.335 [8.51]
0.305 [7.75]
MIN.
0.040 [1.02]
MAX.
0.500 [12.70]
0.155 [3.94]
0.185 [4.70]
0.045 [1.14]
0.029 [0.73]
0.034 [0.864]
0.028 [0.711]
45°
3
5
E
B
K
7
2
1
C
A
0.022Ø [5.08]
MICROPAC INDUSTRIES, INC. OPTOELECTRONIC PRODUCTS DIVISION 725 E.Walnut St., Garland, TX 75040 (972) 272-3571 Fax (972) 487-6918
www.micropac.com E-MAIL: optosales@micropac.com
3 - 15
4N47, 4N48, and 4N49 JAN, JANTX, JANTXV, JANS, SINGLE CHANNEL OPTOCOUPLERS
*ELECTRICAL CHARACTERISTICS T
A
= 25
°
C Unless otherwise specified
PARAMETER SYMBOL MIN TYP MAX UNITS TEST CONDITIONS NOTE
Input Diode Static Reverse Current I
R
100 µA V
R
= 2V
Input Diode Static Forward Voltage -55
°
C
+25
°
C
+100
°
C
V
F
1.0
0.8
0.7
1.4
1.7
1.5
1.3
V
I
E
= 10mA
*OUTPUT TRANSISTOR T
A
= 25
°
C Unless otherwise specified
PARAMETER SYMBOL MIN TYP MAX UNITS TEST CONDITIONS NOTE
Collector-Base Breakdown Voltage V
(BR)CBO
45 V I
C
= 100µA, I
B
= 0, I
F
= 0
Collector-Emitter Breakdown Voltage V
(BR)CEO
40 V I
C
= 1mA, I
B
= 0, I
F
= 0
Emitter-Collector Breakdown Voltage V
(BR)EBO
7
V I
C
= 0, I
E
= 100µA, I
F
= 0
*COUPLED CHARACTERISTICS T
A
= 25
°
C Unless otherwise specified
PARAMETER SYMBOL MIN TYP MAX UNITS TEST CONDITIONS NOTE
On State Collector Current 4N47
4N48
4N49
I
C(ON)
0.5
1.0
2.0
5
10
mA
V
CE
= 5V, I
B
= 0, I
F
= 1mA
On State Collector Current 4N47
-55
°
C 4N48
4N49
I
C(ON)
0.7
1.4
2.8
mA
V
CE
= 5V, I
B
= 0, I
F
= 2mA
On State Collector Current 4N47
+100
°
C 4N48
4N49
I
C(ON)
0.5
1.0
2.0
mA
V
CE
= 5V, I
B
= 0, I
F
= 2mA
2
Off State Collector Current +25
°
C I
C(OFF)
100 nA V
CE
= 20V, I
B
= 0, I
F
= 0mA
Off State Collector Current +100°C I
C(OFF)
100 µA V
CE
= 20V, I
B
= 0, I
F
= 0mA
Collector-Emitter Saturation Voltage 4N47
4N48
4N49
V
CE(SAT)
V
CE(SAT)
V
CE(SAT)
0.3
0.3
0.3
V
V
V
I
C
= 0.5mA, I
B
= 0, I
F
= 2mA
I
C
= 1mA, I
B
= 0, I
F
= 2mA
I
C
= 2mA, I
B
= 0, I
F
= 2mA
Input to Output Resistance R
I-O
10
11
V
IN-OUT
= 1kV 1
Input to Output Capacitance C
I-O
5 pF f = 1MHz, V
IN-OUT
= 1kV 1
Rise Time/ Fall Time 4N47
Phototransistor Operation 4N48
4N49
t
r
/ t
f
t
r
/ t
f
t
r
/ t
f
20
25
25
µs
µs
µs
V
CC
= 10V, I
F
= 10mA, R
L
= 100
Rise Time/ Fall Time 4N47
Photodiode Operation 4N48
4N49
t
r
/ t
f
t
r
/ t
f
t
r
/ t
f
0.85
0.85
0.85
µs
µs
µs
V
CC
= 10V, I
F
= 10mA, R
L
= 100
NOTES:
1. These parameters are measured between all phototransistor leads shorted together and with both input diode leads shorted together.
2. This parameter measured using pulse techniques t
w
=100µs, duty cycle < 1%.
MICROPAC INDUSTRIES, INC. OPTOELECTRONIC PRODUCTS DIVISION 725 E.Walnut St., Garland, TX 75040 (972) 272-3571 Fax (972) 487-6918
www.micropac.com E-MAIL: optosales@micropac.com
3 - 16
4N47, 4N48, and 4N49 JAN, JANTX, JANTXV, JANS, SINGLE CHANNEL OPTOCOUPLERS
RECOMMENDED OPERATING CONDITIONS:
PARAMETER SYMBOL MIN MAX UNITS
Input Current, Low Level I
FL
0 100 µA
Input Current, High Level I
FH
2 10 mA
Supply Voltage V
CE
5 10 V
SELECTION GUIDE
PART NUMBER PART DESCRIPTION
JAN4N47 4N47 Optocoupler, JAN Screening level
JAN4N48 4N48 Optocoupler, JAN Screening level
JAN4N49 4N49 Optocoupler, JAN Screening level
JANTX4N47 4N47 Optocoupler, JANTX Screening level
JANTX4N48 4N48 Optocoupler, JANTX Screening level
JANTX4N49 4N49 Optocoupler, JANTX Screening level
JANTXV4N47 4N47 Optocoupler, JANTXV Screening level
JANTXV4N48 4N48 Optocoupler, JANTXV Screening level
JANTXV4N49 4N49 Optocoupler, JANTXV Screening level
JANS4N47 4N47 Optocoupler, JANS Screening level
JANS4N48 4N48 Optocoupler, JANS Screening level
JANS4N49 4N49 Optocoupler, JANS Screening level
*JEDEC registered data
