TECHNICAL DATA
NPN SILICON SWITCHING TRANSISTOR
Qualified per MIL-PRF-19500/312
Devices Qualified Level
2N708
JAN, JANTX
MAXIMUM RATINGS
Ratings Symbol Value Units
Collector-Emitter Voltage
V
CEO
15 Vdc
Collector-Base Voltage
V
CBO
40 Vdc
Emitter-Base Voltage
V
EBO
5.0 Vdc
Collector-Emitter Voltage
V
CER
20 Vdc
Total Power Dissipation @ T
A
= +25
0
C
(1)
@ T
C
= +25
0
C
(2)
P
T
0.36
1.2
W
W
Operating & Storage Junction Temperature Range
T
op
,
T
stg
-65 to +200
0
C
1) Derate linearly 2.06 mW/
0
C for T
A
> 25
0
C
2) Derate linearly 6.90 mW/
0
C for T
C
> 25
0
C
TO-18 (TO-206AA)*
*See appendix A for
package outline
ELECTRICAL CHARACTERISTICS (T
A
= 25
0
C unless otherwise noted)
Characteristics Symbol Min. Max. Unit
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
I
C
= 1.0 µAdc
V
(BR)
CBO
40
Vdc
Emitter-Base Breakdown Voltage
I
E
= 10 µAdc
V
(BR)
EBO
5.0
Vdc
Collector-Emitter Breakdown Voltage
I
C
= 10 mAdc
V
(BR)
CEO
15
Vdc
Collector-Emitter Breakdown Voltage
I
C
= 10 mAdc, R
BE
10
V
(BR)
CER
20
Vdc
Collector-Base Cutoff Current
V
CB
= 20 Vdc
I
CBO
25
ηAdc
Emitter-Base Cutoff Current
V
EB
= 4.0 Vdc
I
EBO
80
ηAdc
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
120101
Page 1 of 2
2N708 JANTX SERIES
ELECTRICAL CHARACTERISTICS (con’t)
Characteristics Symbol Min. Max. Unit
ON CHARACTERISTICS
(3)
Forward-Current Transfer Ratio
I
C
= 0.5 mAdc, V
CE
= 1.0 Vdc
I
C
= 10 mAdc, V
CE
= 1.0 Vdc
h
FE
15
40
120
Collector-Emitter Saturation Voltage
I
C
= 10 mAdc, I
B
= 1.0 mAdc
V
CE(sat)
0.40
Vdc
Base-Emitter Voltage
I
C
= 10 mAdc, I
B
= 1.0 mAdc
I
C
= 1.0 mAdc, I
B
= 0.1 mAdc
V
BE(sat)
0.72
0.80
0.72
Vdc
DYNAMIC CHARACTERISTICS
Small-Signal Short-Circuit Forward Current Transfer Ratio
I
C
= 10 mAdc, V
CE
= 10 Vdc, f = 100 MHZ
h
fe
3.0 9.0
Output Capacitance
V
CB
= 10 Vdc, I
E
= 0, f = 1.0 MHz
C
obo
6.0
p
ƒ
Input Capacitance
V
EB
= 0.5 Vdc, I
C
= 0, f = 1.0 MHz
C
ibo
9.0
p
ƒ
SWITCHING CHARACTERISTICS
Charge Storage Time
I
C
= I
B1
= -I
B21
= 10 mAdc
t
s
25
ηs
Turn-On Time
V
BE
-2.0 Vdc; I
C
10 mAdc; I
B1
3.0 mAdc
t
on
40
ηs
Turn-Off Time
I
C
10 mAdc; I
B1
3.0 mAdc, I
B2
-1.0 mAdc
t
off
75
ηs
(3) Pulse Test: Pulse Width = 300µs, Duty Cycle 2.0%.
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
120101
Page 2 of 2
