TECHNICAL DATA
N-CHANNEL J-FET
Qualified per MIL-PRF-19500/428
Devices Qualified Level
2N4416A
JAN
JANTX
JANTXV
ABSOLUTE MAXIMUM RATINGS
Parameters / Test Conditions Symbol 2N4416A
Unit
Gate-Source Voltage V
GS
-35 Vdc
Drain-Source Voltage V
DS
35 Vdc
Drain-Gate Voltage V
DG
35 Vdc
Gate Current I
G
10 mAdc
Power Dissipation T
A
= +25
0
C
(1)
P
T
300 mWdc
Operating Junction & Storage Temperature Range T
op
, T
stg
-65 to +200
0
C
(1) Derate linearly 1.7 mW/
0
C for T
A
> +25
0
C.
TO-72*
(TO-206AF)
*See appendix A for
package outline
ELECTRICAL CHARACTERISTICS (T
A
= +25
0
C unless otherwise noted)
Parameters / Test Conditions Symbol Min. Max. Units
Gate-Source Breakdown Voltage
V
DS
= 0, I
G
= 1.0 µAdc
V
(BR)GSS
-35
Vdc
Gate Reverse Current
V
DS
= 0, V
GS
= 20 Vdc
I
GSS
-0.1
ηAdc
Drain Current
V
DS
= 15 Vdc
I
DSS
5
15
mAdc
Gate-Source Voltage
V
DS
= 15 Vdc, I
D
= 0.5 mAdc
V
GS
-1
-5.5
Vdc
Gate-Source Cutoff Voltage
V
DS
= 15 Vdc, I
D
= 1.0 ηAdc
V
GS(off)
-2.5
-6.0
Vdc
Gate-Source Forward Voltage
V
DS
= 0 Vdc, I
G
= 1.0 mAdc
V
GSF
1 Vdc
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
120101
Page 1 of 2
2N4416A JAN SERIES
ELECTRICAL CHARACTERISTICS (T
A
= +25
0
C unless otherwise noted) (con’t)
Parameters / Test Conditions Symbol Min. Max. Units
Magnitude of Small-Signal Common Source, Short-
Circuit Forward Transfer Admittance
(2)
V
GS
= 0, V
DS
= 15 Vdc, f = 1.0 kHz
|y
fs
|
2
4.5
7.5
ms
Small-Signal, Common-Source Short-Circuit
Input Capacitance
V
GS
= 0, V
DS
= 15 Vdc, 100 kHz f 1.0 MHz
C
iss
4.0
pF
Small-Signal, Common-Source Short-Circuit
Reverse Transfer Capacitance
V
DS
= 15 Vdc, V
GS
= 0, 100 kHz f 1.0 MHz
C
rss
0.8
pF
Small-Signal, Common-Source Short-Circuit
Output Capacitance
V
DS
= 15 Vdc, V
GS
= 0, 100 kHz f 1.0 MHz
C
oss
2.0
pF
(2) Pulse Width = 100ms; Duty Cycle = 10%
