MOT / FC JAN2N3715

Cross Number:

Item Description: TRANS GP BJT NPN 60V 10A 3PINTO-3 - Bulk

Qty Price
1 - 2 $53.20920
3 + $41.51930



Other Cross Reference

Manufacturer Date Code Qty Available Qty
MOT / FC 7800
  • Freelance Stock: 2
    Ships Immediately


Motorola Corp 8228
  • Freelance Stock: 1
    Ships Immediately


Motorola Corp 8031
  • Freelance Stock: 1
    Ships Immediately





Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

TECHNICAL DATA
NPN HIGH POWER SILICON TRANSISTOR
Qualified per MIL-PRF-19500/408
Devices Qualified Level
2N3715 2N3716
JAN
JANTX
JANTXV
MAXIMUM RATINGS
Ratings
Symbol
2N3715
2N3716
Units
Collector-Emitter Voltage
V
CEO
60 80 Vdc
Collector-Base Voltage
V
CBO
80 100 Vdc
Emitter-Base Voltage
V
EBO
7.0 Vdc
Base Current I
B
4.0 Adc
Collector Current
I
C
10 Adc
Total Power Dissipation @ T
A
= 25
0
C
@ T
C
=100
0
C
P
T
5.0
85.7
W
W
Operating & Storage Junction Temperature Range
T
J
,
T
stg
-65 to +200
0
C
THERMAL CHARACTERISTICS
Characteristics Symbol Max. Unit
Thermal Resistance, Junction-to-Case
R
θJC
1.17
0
C/W
1) Derate linearly 28.57 mW/
0
C for T
A
>25
0
C
2) Derate linearly 0.857 W/
0
C for T
C
>100
0
C
TO-3* (TO-204AA)
*See Appendix A for
Package Outline
ELECTRICAL CHARACTERISTICS (T
C
= 25
0
C unless otherwise noted)
Characteristics Symbol Min. Max. Unit
OFF CHARACTERISTICS
Collector-Emitter Breakdown Current
I
C
= 10 mAdc 2N3715
2N3716
V
(BR)
CEO
60
80
Vdc
Collector-Base Cutoff Current
V
CB
= 80 Vdc 2N3715
V
CB
= 100 Vdc 2N3716
I
CBO
10
10
µAdc
Emitter-Base Breakdown Voltage
V
EB
= 7.0 Vdc
I
EBO
1.0
mAdc
Collector-Emitter Cutoff Current
V
BE
= 1.5 Vdc, V
CE
= 60 Vdc 2N3715
V
BE
= 1.5 Vdc, V
CE
= 80 Vdc 2N3716
I
CEX
1.0
1.0
mAdc
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
120101
Page 1 of 2
2N3715, 2N3716 JAN SERIES
ELECTRICAL CHARACTERISTICS (con’t)
Characteristics Symbol Min. Max. Unit
Collector-Emitter Cutoff Current
V
CE
= 60 Vdc 2N3715
V
CE
= 80 Vdc 2N3716
I
CES
1.0
1.0
mAdc
ON CHARACTERISTICS
(3)
Forward-Current Transfer Ratio
I
C
= 1.0 Adc, V
CE
= 2.0 Vdc
I
C
= 3.0 Adc, V
CE
= 2.0 Vdc
I
C
= 5.0 Adc, V
CE
= 2.0 Vdc
I
C
= 10 Adc, V
CE
= 4.0 Vdc
h
FE
50
30
10
5.0
150
120
Collector-Emitter Saturation Voltage
I
C
= 5.0 Adc, I
B
= 0.5 Adc
I
C
= 10 Adc, I
B
= 2.0 Adc
V
CE(sat)
1.0
2.5
Vdc
Base-Emitter Saturation Voltage
I
C
= 5.0 Adc, I
B
= 0.5 Adc
I
C
= 10 Adc, I
B
= 2.0 Adc
V
BE(sat)
1.5
3.0
Vdc
DYNAMIC CHARACTERISTICS
Magnitude of Common Emitter Small-Signal Short Circuit
Forward Current Transfer Ratio
I
C
= 0.5 Adc, V
CE
= 10 Vdc, f = 100 kHz 1.0 MHz
h
fe
4.0
20
Forward Current Transfer Ratio
I
C
= 0.5 Adc, V
CE
= 10 Vdc, f = 1.0 kHz
h
fe
30
300
Output Capacitance
V
CB
= 10 Vdc, I
E
= 0, f = 1.0 MHz
C
obo
500
pF
SAFE OPERATING AREA
DC Tests
T
C
= +25
0
C, 1 Cycle, t 1.0 s
Test 1
V
CE
= 15 Vdc, I
C
= 10 Adc
Test 2
V
CE
= 40 Vdc, I
C
= 3.75 Adc
Test 3
V
CE
= 55 Vdc, I
C
= 0.9 Adc 2N3715
V
CE
= 65 Vdc, I
C
= 0.9 Adc 2N3716
(3) Pulse Test: Pulse Width = 300µs, Duty Cycle 2.0%.
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
120101
Page 2 of 2
