3003
3 Watts - 28 Volts, Class C
Microwave 3000 MHz
GENERAL DESCRIPTION
The 3003 is a COMMON BASE transistor capable of providing 3 Watts Class
C, RF output power at 3000 MHz. Gold metalization and diffused ballasting
are used to provide high reliability and supreme ruggedness. The transistor
uses a fully hermetic High Temperature Solder Sealed package.
CASE OUTLINE
55BT-1, STYLE 1
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25 C 10 Watts
o
Maximum Voltage and Current
BVces Collector to Emitter Voltage 50 Volts
BVebo Emitter to Base Voltage 3.5 Volts
Ic Collector Current 0.6 A
Maximum Temperatures
Storage Temperature - 65 to + 200 C
o
Operating Junction Temperature + 200 C
o
ELECTRICAL CHARACTERISTICS @ 25 C
O
SYMBOL CHARACTERISTICS TEST CONDITIONS MIN TYP MAX UNITS
Pout
Pin
Pg
η
c
VSWR
1
Power Out
Power Input
Power Gain
Collector Efficiency
Load Mismatch Tolerance
F = 3.0 GHz
Vcb = 28 Volts
Po = 3 Watts
As Above
F = 3 GHz, Po = 3 W
3.0
6.0
30
0.75
30:1
Watt
Watt
dB
%
BVces
BVebo
Icbo
h
FE
Cob
θjc
Collector to Emitter Breakdown
Emitter to Base Breakdown
Collector to Base Current
Current Gain
Output Capacitance
Thermal Resistance
Ic = 30 mA
Ie = 3 mA
Vcb = 28 Volts
Vce = 5 V, Ic = 300 mA
F =1.0 MHz, Vcb = 28 V
50
3.5
10
7.0
1.5
17
Volts
Volts
m
A
pF
C/W
o
Issue August 1996
