LX8385-00CDD

Part # LX8385-00CDD
Description LDO Regulator Pos 3.5A 4-Pin(3+Tab) TO-263
Category RECTIFIER
Availability In Stock
Qty 3278
Qty Price
1 - 41 $6.03487
42 - 104 $4.80046
105 - 220 $4.52615
221 - 475 $4.20612
476 + $3.74893
Manufacturer Available Qty
Date Code: 0048
  • Shipping Freelance Stock: 4
    Ships Immediately
Date Code: 0048
  • Shipping Freelance Stock: 18
    Ships Immediately
Date Code: 0048
  • Shipping Freelance Stock: 86
    Ships Immediately
Linfinity Microelectronics Inc
Date Code: 9926
  • Shipping Freelance Stock: 1500
    Ships Immediately
Linfinity Microelectronics Inc
Date Code: 9930
  • Shipping Freelance Stock: 750
    Ships Immediately
Linfinity Microelectronics Inc
Date Code: 0048
  • Shipping Freelance Stock: 749
    Ships Immediately
Microsemi Corp
Date Code: 0614
  • Shipping Freelance Stock: 171
    Ships Immediately



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

PRODUCTION DATA SHEET
Microsemi Inc.
Integrated Products Division
11861 Western Avenue, Garden Grove, CA. 92841, 714-898-8121, Fax: 714-893-2570
Page 1
Copyright © 2000
Rev. 2.0b, 2005-10-25
WWW.Microsemi .COM
LX8385x-xx
3A Low Dropout Positive Re
g
ulators
TM
®
DESCRIPTION
The LX8385/85A/85B Series ICs are
positive regulators designed to provide 3A
output current. These regulators yield
higher efficiency than currently available
devices with all internal circuitry designed
to operate down to a 1V input-to-output
differential. In each of these products, the
dropout voltage is fully specified as a
function of load current. Dropout is
guaranteed at a maximum of 1.3V
(8385A/B) and 1.5V (8385) at maximum
output current, decreasing at lower load
currents.
In addition, on-chip trimming adjusts the
reference voltage tolerance to 1% maximum
at room temperature and 2% maximum over
the 0 to 125°C range for the LX8385A. The
LX8385B offers 0.8% tolerance at room
temperature and 1.0% maximum over line,
load and temperature. Fixed versions are
also available and specified in the Available
Options table below.
The LX8385/85A/85B Series devices are
pin-compatible with earlier 3-terminal
regulators, such as the 117 series products,
but they do require input and output
capacitors. A minimum 10µF capacitor is
required on the input and a 15µF or greater
on the output of these new devices for
stability. Although, these capacitors are
generally included in most regulator designs.
The LX8385/85A/85B Series quiescent
current flows into the load, thereby
increasing efficiency. This feature contrasts
with PNP regulators where up to 10% of the
output current is wasted as quiescent
current.
The LX8385-xxI is specified over the
industrial temperature range of -25°C to
125°C, while the LX8385-xxC / 85A-xxC /
85B-xxC is specified over the commercial
range of 0°C to 125°C.
IMPORTANT: For the most current data, consult MICROSEMI’s website: http://www.microsemi.com
PRODUCT HIGHLIGHT
*1500µF
6MV1500GX
Sanyo
LX8385A
121Ω
1%
200Ω
1%
IN
ADJ
OUT
5V
3.3V
at 3A
1500µF
2x 6MV1500GX
Sanyo
+
+
KEY FEATURES
Three-Terminal Adjustable Or
Fixed Output
Guaranteed 1% Voltage
Reference Accuracy Over Line,
Load, And Temperature
(LX8385B)
Guaranteed < 1.5V Headroom At
3A (LX8385)
Guaranteed < 1.3V Headroom At
3A (LX8385A/8385B)
0.015% Line Regulation
0.15% Load Regulation
APPLICATIONS
High Efficiency Linear
Regulators
Post Regulators For Switching
Power Supplies
Battery Chargers
Constant Current Regulators
Graphics & Standard Supplies
Processor I/O Supply
Low Voltage Memory & Chipset
Supplies
PART #
OUTPUT
VOLTAGE
LX8385/85A/85B-00 Adjustable
LX8385/85A/85B-33 3.3V
LX8385/85A/85B-05 5.0V
Table 1 - Available Options
PACKAGE ORDER INFO
DT
Plastic TO-252
(D-Pak) 3-Pin
P
Plastic TO-220
3-Pin
DD
Plastic TO-263
3-Pin
T
A
(°C)
Max Ref
Accuracy
Max Dropout
Voltage
RoHS Compliant
Transition DC: 0532
RoHS Compliant
Transition DC: 0543
RoHS Compliant
Transition DC: 0535
2.0% 1.5V
LX8385-xxCDT LX8385-xxCP LX8385-xxCDD
2.0% 1.3V
LX8385A-xxCDT LX8385A-xxCP LX8385A-xxCDD
0 to 125
1.0% 1.3V
LX8385B-xxCDT LX8385B-xxCP LX8385B-xxCDD
-25 to 125 2.0% 1.5V
LX8385-xxIDT LX8385-xxIP LX8385-xxIDD
Note: Available in Tape & Reel. Append the letters “TR” to the part number. (i.e. LX8385-xxCP-TR)
L
L
X
X
8
8
3
3
8
8
5
5
X
X
PRODUCTION DATA SHEET
Microsemi Inc.
Integrated Products Division
11861 Western Avenue, Garden Grove, CA. 92841, 714-898-8121, Fax: 714-893-2570
Page 2
Copyright © 2000
Rev. 2.0b, 2005-10-25
WWW.Microsemi .COM
LX8385x-xx
3A Low Dropout Positive Re
g
ulators
TM
®
ABSOLUTE MAXIMUM RATINGS (NOTE 1)
Power Dissipation................................................................................... Internally Limited
Input Voltage ................................................................................................................ 10V
Input to Output Voltage Differential............................................................................. 10V
Operating Junction Temperature................................................................................150°C
Storage Temperature Range....................................................................... -65°C to 150 °C
Peak Package Solder Reflow Temp (40 seconds max. exposure) .................260°C (+0, -5)
Note 1: Exceeding these ratings could cause damage to the device. All voltages are with respect to
Ground. Currents are positive into, negative out of specified terminal.
THERMAL DATA
DD
Plastic TO-263 3-Pin
THERMAL RESISTANCE-JUNCTION TO AMBIENT, θ
JA
60°C/W
THERMAL RESISTANCE-JUNCTION TO TAB, θ
JT
2.7°C/W
P
Plastic TO-220 3-Pin
THERMAL RESISTANCE-JUNCTION TO AMBIENT, θ
JA
60°C/W
THERMAL RESISTANCE-JUNCTION TO TAB, θ
JT
2.7°C/W
DT
Plastic TO-252 3-Pin
THERMAL RESISTANCE-JUNCTION TO AMBIENT, θ
JA
60°C/W
THERMAL RESISTANCE-JUNCTION TO TAB, θ
JT
2.7°C/W
Junction Temperature Calculation: T
J
= T
A
+ (P
D
x θ
JT
).
The θ
JA
&
θ
JT
numbers are guidelines for the thermal performance of the device/pc-board
system. All of the above assume no ambient airflow.
PACKAGE PIN OUT
1
V
IN
ADJ /
GND*
V
OUT
2
3
TAB is V
OUT
DD
PACKAGE (3-PIN)
(Top View)
V
IN
V
OUT
ADJ/
GND*
TAB is V
OUT
3
2
1
DT PACKAGE (3-PIN)
(Top View)
TAB is V
OUT
ADJ /
GND*
V
OUT
V
IN
1
2
3
P PACKAGE (3-PIN)
(Top View)
*Pin 1 is GND for fixed voltage versions
RoHS 100% Matte Tin Lead Finish
BLOCK DIAGRAM
Thermal
Limit Circuit
Bias Circuit
Bandgap
Circuit
Control
Circuit
Output
Circuit
SOA
Protection
Circuit
Current
Limit Circuit
V
IN
ADJ or
GND*
V
OUT
*Pin 1 is GND for fixed voltage versions
P
P
A
A
C
C
K
K
A
A
G
G
E
E
D
D
A
A
T
T
A
A
PRODUCTION DATA SHEET
Microsemi Inc.
Integrated Products Division
11861 Western Avenue, Garden Grove, CA. 92841, 714-898-8121, Fax: 714-893-2570
Page 3
Copyright © 2000
Rev. 2.0b, 2005-10-25
WWW.Microsemi .COM
LX8385x-xx
3A Low Dropout Positive Re
g
ulators
TM
®
ELECTRICAL CHARACTERISTICS
Unless otherwise specified, the following specifications apply over the operating ambient temperature for the LX8385x-xxC with
0°C T
A
125°C and the LX8385-xxI with -25°C T
A
125°C except where otherwise noted. Test conditions: V
IN
-V
OUT
= 3V;
I
OUT
= 3A. Low duty cycle pulse testing techniques are used which maintains junction and case temperatures equal to the ambient
temperature.
LX8385x-xx
Parameter Symbol Test Conditions
Min Typ Max
Units
`
LX8385-00 / 8385A-00 / 8385B-00 (ADJUSTABLE)
I
OUT
= 10mA, T
A
= 25°C 1.238 1.250 1.262 V
10mA < I
OUT
< 3A, 1.5V < (V
IN
-V
OUT
),
V
IN
< 10V, P < P
MAX
1.225 1.250 1.270 V
I
OUT
= 10mA, T
A
= 25°C 1.240 1.250 1.260 V
Reference Voltage LX8385/85A-00
(Note 4)
LX8385B-00
V
REF
10mA <
I
OUT
< 3A, 1.5V < (V
IN
-V
OUT
),
V
IN
< 10V, P < P
MAX
1.238 1.250 1.262 V
Line Regulation (Note 2)
Δ V
REF
(V
IN
)
1.5V <
(V
IN
-V
OUT
), V
IN
< 7V, I
OUT
= 10mA 0.015 0.2 %
Load Regulation (Note 2)
Δ V
REF
(I
OUT
)
V
OUT
> V
REF
, V
IN
- V
OUT
= 3V,
10mA <
I
OUT
< 3A
0.15 0.5 %
Thermal Regulation
ΔV
OUT
(Pwr)
T
A
= 25°C, 20ms pulse 0.01 0.04 % / W
Ripple Rejection (Note 3)
V
OUT
= 5V, f= 120Hz, C
OUT
= 100µF Tantalum,
V
IN
= 6.5V, C
ADJ
= 10µF, I
OUT
= 3A
65 83 dB
Adjust Pin Current I
ADJ
55 100 µA
Adjust Pin Current Change (Note 4) ΔI
ADJ
10mA < I
OUT
< I
OUT(MAX)
, 1.5V < (V
IN
-V
OUT
), V
IN
<10V 0.2 5 µA
ΔV
REF
= 1%, I
OUT
= 3A 1.2 1.5 V
Dropout Voltage LX8385-00
LX8385A/85B-00
ΔV
ΔV
REF
= 1%, I
OUT
= 3A 1.1 1.3 V
Minimum Load Current I
OUT(MIN)
V
IN
< 10V 2 10 mA
Maximum Output Current I
OUT(MAX)
(V
IN
- V
OUT
) < 7V, V
IN
< 10V 3 3.5 A
Long Term Stability (Note 3) ΔV
OUT
(t) T
A
= 125°C, 1000 hours 0.3 1 %
Temperature Stability (Note 3) ΔV
OUT
(T) 0.25 %
RMS Output Noise (% of V
OUT
)
(Note 3)
ΔV
OUT(RMS)
T
A
= 25°C, 10Hz < f < 10kHz 0.003 %
`
LX8385-33/ 8385A-33/ 8385B-33 (3.3V FIXED)
V
IN
= 5V, I
OUT
= 0mA, T
A
= 25°C 3.267 3.3 3.333 V
4.75V < V
IN
< 10V, 0mA < I
OUT
< 3A, P < P
MAX
3.235 3.3 3.365 V
V
IN
= 5V, I
OUT
= 0mA, T
A
= 25°C 3.274 3.3 3.326 V
Output Voltage LX8385/85A-33
(Note 4)
LX8385B-33
V
OUT
4.75V <
V
IN
< 10V, 0A < I
OUT
< 3A, P < P
MAX
3.267 3.3 3.333 V
4.75V < V
IN
< 7V 1 6 mV
Line Regulation (note 2)
ΔV
OUT
(V
IN
)
4.75V <
V
IN
< 10V 2 10 mV
Load Regulation (note 2)
ΔV
OUT
(I
OUT
)
V
IN
= 5V, 0mA < I
OUT
< I
OUT(MAX)
5 15 mV
Thermal Regulation
ΔV
OUT
(Pwr)
T
A
= 25°C, 20ms pulse 0.01 0.02 % / W
Ripple Rejection (note 3) C
OUT
= 100µF (Tantalum), I
OUT
= 3A 60 83 dB
Quiescent Current I
Q
0mA < I
OUT
< I
OUT(MAX)
, 4.75V < V < 10V 4 10 mA
ΔV
OUT
= 1%, I
OUT
< I
OUT(MAX)
1.2 1.5 V
Dropout Voltage LX8385-33
LX8385A/85B-33
ΔV
ΔV
OUT
= 1%, I
OUT
< I
OUT(MAX)
1.1 1.3 V
E
E
L
L
E
E
C
C
T
T
R
R
I
I
C
C
A
A
L
L
S
S
