INA230EVM Software Setup
After the installation process initializes, the user is given the choice of selecting the directory in which to
install the program; the default location is C:\Program Files\INA230\ and C:\Program Files\National
Instruments\. Following this option, two license agreements are presented that must be accepted, as
shown in Figure 12. After accepting the Texas Instruments and National Instruments license agreements,
the progress bar opens and shows the installation of the software, as Figure 13 illustrates. Once the
installation process is completed, click Finish.
Figure 12. INA230EVM License Agreements
