Hercules Encoders
Smart Encoder
Series SE25
• Combined Heavy Duty Encoder and Motor Con-
trol Features
• Automatically adjusts to maintain speed with
changes in motor load
• Enclosure: SE25-2.5” Dia.
NEMA 6P and IEC IP 67 type sealing
Servo, Flush or Flanged Mounting
• Shielded ABEC 5 Stainless Steel Spindle Bearings,
Standard and Self-Mounting options
• Operating Voltage Flexibility – 8 to 28 Vdc or 5
Vdc TTL Output, 5V or 8-15V with Line Driver
• Operating Temperature Rating designed for ex-
tremes, from -40° to +85°C (-40° to +185°F)
Specifications
Mechanical
Shaft Speed 6000 RPM maximum
Shaft Direction Bidirectional
Standard Shaft Sizes .3747”, .4997”
Shaft Extension(s) Std 0.875”, .50 x .05” flat
Shaft Seals Neoprene or PTFE Options
Mounting Refer to dimensional drawings
Bearings .5000” ID ABEC 5 Spindle
Radial Loading 90 lbs. Operating
Axial Loading 45 lbs. Operating
Accuracy ±0.1° of Shaft Rotation Typ.
Housing Black Anodized Aluminum
Weight 22 oz.
Connector 6, 7, 10 Pin MS3102 or 18” Cable Out
Electrical
Supply Voltage 8 to 28 Vdc
5 Vdc TTL output
Supply Current 100 mA typical., 120 mA maximum
Current Sinking 250 mA max
Connections Configured to Customer Requirement
Environmental
Operating Temperature -40° to +85°C (-40° to +185°F)
Shock 50 g’s for 11 Milliseconds
Vibration 5 to 2000 Hertz at 20 g’s
Humidity 100% Relative Humidity
Enclosures (Sealed) NEMA 6P, IEC IP 67 – Water-tight
for the latest specifications visit our website
www.herculesencoders.com
Rev. A
