C8051F320/1
82 Rev. 1.4
PCA0CPM2 0xDC PCA Module 2 Mode Register 242
PCA0CPM3 0xDD PCA Module 3 Mode Register 242
PCA0CPM4 0xDE PCA Module 4 Mode Register 242
PCA0H 0xFA PCA Counter High 243
PCA0L 0xF9 PCA Counter Low 243
PCA0MD 0xD9 PCA Mode 241
PCON 0x87 Power Control 98
PSCTL 0x8F Program Store R/W Control 112
PSW 0xD0 Program Status Word 85
REF0CN 0xD1 Voltage Reference Control 56
REG0CN 0xC9 Voltage Regulator Control 70
RSTSRC 0xEF Reset Source Configuration/Status 104
SBUF0 0x99 UART0 Data Buffer 193
SCON0 0x98 UART0 Control 192
SMB0CF 0xC1 SMBus Configuration 175
SMB0CN 0xC0 SMBus Control 177
SMB0DAT 0xC2 SMBus Data 179
SP 0x81 Stack Pointer 84
SPI0CFG 0xA1 SPI Configuration 203
SPI0CKR 0xA2 SPI Clock Rate Cont
rol 205
SPI0CN 0xF8 SPI Control 204
SPI0DAT 0xA3 SPI Data 205
TCON 0x88 Timer/Counter Control 213
TH0 0x8C Timer/Counter 0 High 216
TH1 0x8D Timer/Counter 1 High 216
TL0 0x8A Timer/Counter 0 Low 216
TL1 0x8B Timer/Counter 1 Low 216
TMOD 0x89 Timer/Counter Mode 214
TMR2CN 0xC8 Timer/Counter 2 Control 220
TMR2H 0xCD Timer/Counter 2 High 221
TMR2L 0xCC Timer/Counter 2 Low 221
TMR2RLH 0xCB Timer/Counter 2 Reload High 221
Table 9.3. Special Function Registers (Continued)
SFRs are listed in alphabetical order. All undefined SFR locations are reserved.
Register Address Description Page
