NS346 Calibrated Noise Sources
NS346B-1
10 MHz to 18000 MHz
Specifications
RF Frequency 10 MHz to 18000 MHz
Noise Output 14 to 16 dB ENR
Noise Spectral Density (N
o
) -159 dBm/Hz
VSWR 1.15:1 Max (0.01 - 5 GHz)
1.25:1 Max (5 - 18 GHz)
Peak Factor 5:1
Bias Voltage 28 V
Supply Current 25 mA Max
Impedance 50 ohms
Package and Connectivity
Construction Coaxial
Package Type Type N (m)
Environmental
Operating Temperature -55 to 95 °C
Storage Temperature -65 to 125 °C
Notes
15 VDC available upon request
Specifications subject to change without notice
