Ordering codes and packing units (lead spacing 15 mm)

V DC

RMS

f ≤1 kHz

V AC

Max. dimensions

w × h × l

Ordering code

(composition see

below)

Ammo

pack

pcs./MOQ

Reel

pcs./

MOQ

Untaped

pcs./

MOQ

MOQ = Minimum Order Quantity, consisting of 4 packing units.

Further E series and intermediate capacitance values on request.

Composition of ordering code

+ = Capacitance tolerance code: *** = Packaging code:

K = ±10%

J = ±5%

289 = Ammo pack

189 = Reel

000 = Untaped (lead length 6 1 mm)

1000 250 10 5.0 × 10.5 × 18.0 B32652A0103+*** 4680 5200 4000

15 5.0 × 10.5 × 18.0 B32652A0153+*** 4680 5200 4000

22 5.0 × 10.5 × 18.0 B32652A0223+*** 4680 5200 4000

33 6.0 × 11.0 × 18.0 B32652A0333+*** 3840 4400 4000

47 7.0 × 12.5 × 18.0 B32652A0473+*** 3320 3600 4000

68 8.5 × 14.5 × 18.0 B32652A0683+*** 2720 2800 2000

100 9.0 × 17.5 × 18.0 B32652A0104+*** 2560 2800 2000

120 11.0 × 18.5 × 18.0 B32652A0124+***  2200 1000

150 11.0 × 18.5 × 18.0 B32652A0154+***  2200 1000

1250 500 6.8 5.0 × 10.5 × 18.0 B32652A7682+*** 4680 5200 4000

10 6.0 × 11.0 × 18.0 B32652A7103+*** 3840 4400 4000

15 7.0 × 12.5 × 18.0 B32652A7153+*** 3320 3600 4000

22 8.5 × 14.5 × 18.0 B32652A7223+*** 2720 2800 2000

33 9.0 × 17.5 × 18.0 B32652A7333+*** 2560 2800 2000

47 11.0 × 18.5 × 18.0 B32652A7473+***  2200 1000

56 11.0 × 18.5 × 18.0 B32652A7563+***  2200 1000

1600 500 3.3 5.0 × 10.5 × 18.0 B32652A1332+*** 4680 5200 4000

4.7 6.0 × 11.0 × 18.0 B32652A1472+*** 3840 4400 4000

6.8 7.0 × 12.5 × 18.0 B32652A1682+*** 3320 3600 4000

10 8.5 × 14.5 × 18.0 B32652A1103+*** 2720 2800 2000

15 9.0 × 17.5 × 18.0 B32652A1153+*** 2560 2800 2000

22 11.0 × 18.5 × 18.0 B32652A1223+***  2200 1000

1600 700 2.2 5.0 × 10.5 × 18.0 B32652J1222+*** 4680 5200 4000

3.3 6.0 × 11.0 × 18.0 B32652J1332+*** 3840 4400 4000

4.7 7.0 × 12.5 × 18.0 B32652J1472+*** 3320 3600 4000

6.8 8.5 × 14.5 × 18.0 B32652J1682+*** 2720 2800 2000

10 9.0 × 17.5 × 18.0 B32652J1103+*** 2560 2800 2000

12 9.0 × 17.5 × 18.0 B32652J1123+*** 2560 2800 2000

15 11.0 × 18.5 × 18.0 B32652J1153+***  2200 1000

B32652

High pulse (wound)

Page 10 of 39Please read Cautions and warnings and

Important notes at the end of this document.

Ordering codes and packing units (lead spacing 15 mm)

V DC

RMS

f ≤1 kHz

V AC

Max. dimensions

w × h × l

Ordering code

(composition see

below)

Ammo

pack

pcs./MOQ

Reel

pcs./

MOQ

Untaped

pcs./

MOQ

MOQ = Minimum Order Quantity, consisting of 4 packing units.

Further E series and intermediate capacitance values on request.

Composition of ordering code

+ = Capacitance tolerance code: *** = Packaging code:

K = ±10%

J = ±5%

289 = Ammo pack

189 = Reel

000 = Untaped (lead length 6 1 mm)

2000 700 1.0 5.0 × 10.5 × 18.0 B32652A2102+*** 4680 5200 4000

1.5 6.0 × 11.0 × 18.0 B32652A2152+*** 3840 4400 4000

2.2 7.0 × 12.5 × 18.0 B32652A2222+*** 3320 3600 4000

3.3 8.5 × 14.5 × 18.0 B32652A2332+*** 2720 2800 2000

4.7 9.0 × 17.5 × 18.0 B32652A2472+*** 2560 2800 2000

5.6 9.0 × 17.5 × 18.0 B32652A2562+***  2200 1000

6.8 11.0 × 18.5 × 18.0 B32652A2682+***  2200 1000

B32652

High pulse (wound)

Page 11 of 39Please read Cautions and warnings and

Important notes at the end of this document.

Ordering codes and packing units (lead spacing 22.5 mm)

V DC

RMS

f ≤1 kHz

V AC

Max. dimensions

w × h × l

Ordering code

(composition see

below)

Ammo

pack

pcs./MOQ

Reel

pcs./

MOQ

Untaped

pcs./

MOQ

MOQ = Minimum Order Quantity, consisting of 4 packing units.

Further E series and intermediate capacitance values on request.

Composition of ordering code

+ = Capacitance tolerance code: *** = Packaging code:

K = ±10%

J = ±5%

289 = Ammo pack

189 = Reel

000 = Untaped (lead length 6 1 mm)

250 160 220 6.0 × 15.0 × 26.5 B32653A3224+*** 2720 2800 2880

330 6.0 × 15.0 × 26.5 B32653A3334+*** 2720 2800 2880

470 7.0 × 16.0 × 26.5 B32653A3474+*** 2320 2400 2520

680 8.5 × 16.5 × 26.5 B32653A3684+*** 1920 2000 2040

1000 10.5 × 16.5 × 26.5 B32653A3105+*** 1560 1600 2160

1200 10.5 × 18.5 × 26.5 B32653A3125+*** 1560 1600 2160

1500 11.0 × 20.5 × 26.5 B32653A3155+*** 1480 1400 2040

2200 14.5 × 29.5 × 26.5 B32653A3225+000   1040

3300 14.5 × 29.5 × 26.5 B32653A3335+000   1040

400 200 150 6.0 × 15.0 × 26.5 B32653A4154+*** 2720 2800 2880

220 6.0 × 15.0 × 26.5 B32653A4224+*** 2720 2800 2880

330 7.0 × 16.0 × 26.5 B32653A4334+*** 2320 2400 2520

470 8.5 × 16.5 × 26.5 B32653A4474+*** 1920 2000 2040

680 10.5 × 16.5 × 26.5 B32653A4684+*** 1560 1600 2160

1000 11.0 × 20.5 × 26.5 B32653A4105+*** 1480 1400 2040

1200 12.0 × 22.0 × 26.5 B32653A4125+000   1800

1500 14.5 × 29.5 × 26.5 B32653A4155+000   1040

2200 14.5 × 29.5 × 26.5 B32653A4225+000   1040

630 250 100 6.0 × 15.0 × 26.5 B32653A6104+*** 2720 2800 2880

150 6.0 × 15.0 × 26.5 B32653A6154+*** 2720 2800 2880

220 8.5 × 16.5 × 26.5 B32653A6224+*** 1920 2000 2040

330 10.5 × 16.5 × 26.5 B32653A6334+*** 1560 1600 2160

470 11.0 × 20.5 × 26.5 B32653A6474+*** 1480 1400 2040

560 11.0 × 20.5 × 26.5 B32653A6564+*** 1480 1400 2040

680 14.5 × 29.5 × 26.5 B32653A6684+000   1040

1000 14.5 × 29.5 × 26.5 B32653A6105+000   1040

1200 14.5 × 29.5 × 26.5 B32653A6125+000   1040

B32653

High pulse (wound)

Page 12 of 39Please read Cautions and warnings and

Important notes at the end of this document.
