ERJ/UNI JANTX1N4454

Cross Number: 1N4454JANTX

Item Description: SWITING 50V 0.2A 2PIN DO-35 -Bulk

Qty Price
1 - 102 $0.99000
103 - 205 $0.77250
206 - 308 $0.67500
309 - 410 $0.65250
411 + $0.58500



Other Cross Reference

Manufacturer Date Code Qty Available Qty
ERJ/UNI
  • Freelance Stock: 401
    Ships Immediately


Semtech Corporation 9852
  • Freelance Stock: 18
    Ships Immediately


Semtech Corporation
  • Freelance Stock: 22
    Ships Immediately


N/A 7900
  • Freelance Stock: 48
    Ships Immediately





Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

22 COREY STREET, MELROSE, MASSACHUSETTS 02176
PHONE (781) 665-1071 FAX (781) 665-7379
WEBSITE: http://www.cdi-diodes.com E-mail: mail@cdi-diodes.com
1N4454
1N4454-1
I
R1
I
R2 CAPACITANCE
@ 50 V dc @ 50 V @ 0 V
T
A
= 150°C
µA µA pF
0.1 100 2.0
FIGURE 1
DESIGN DATA
CASE: Hermetically sealed
glass case per MIL-S-19500/144
D0-35 outline
LEAD MATERIAL: Copper clad steel.
LEAD FINISH: Tin / Lead
THERMAL RESISTANCE: (R
O
JL
):
250 ˚C/W maximum at L = .375
THERMAL IMPEDANCE: (Z
O
JX
): 70
˚C/W maximum
POLARITY: Cathode end is banded.
MOUNTING POSITION: Any.
V
f 1
V
f 2
t
rr
V
BR
V
RWM
I
0@
I
F
= 10 mA
@
I
F
= 10 mA
@5µA T
A
= 150°C
Volts Volts (pk) mA V dc V dc n sec
75 50 200 1.0 0.7 4
MAXIMUM RATINGS
Junction Temperature: -55°C to +175°C
Storage Temperature: -55°C to +175°C
Operating Current: 200 mA @ T
A
= +25°C
Derating Factor: 1.33 mA/°C Above T
A
= + 25°C
Surge Current A: 1A (pk), P
w
= 1 sec
Surge Current B: 4A (pk), P
w
= 1 µs
ELECTRICAL CHARACTERISTICS @ 25°C, unless otherwise specified.
1N4454 and IN4454-1 AVAILABLE IN
JAN, JANTX,
AND
JANTXV
PER MIL-PRF-19500/144
SWITCHING DIODE
HERMETICALLY SEALED
METALLURGICALLY BONDED
DOUBLE PLUG CONSTRUCTION
IN4454 and 1N4454-1
.3 .4 .5 .6 .7 .8 .9 1.0 1.1 1.2 1.3
VF - Forward Voltage (V)
FIGURE 2
Typical Forward Current
vs Forward Voltage
I
F
- Forward Current - (mA)
1000
100
10
1
0.1
150ºC
100ºC
25ºC
-65ºC
20 40 60 80 100 120 140
Percent of Reverse Working Voltage (%)
FIGURE 3
Typical Reverse Current
vs Reverse Voltage
I
R
- Reverse Current - (µA)
1000
100
10
1
0.1
.01
.001
150ºC
100ºC
25ºC
-65ºC
NOTE : All temperatures shown on graphs are
junction temperatures
