DS17001 Rev. 13 - 2 1 of 3 DF005S-DF10S
www.diodes.com
ã Diodes Incorporated
Characteristic Symbol
DF
005S
DF
01S
DF
02S
DF
04S
DF
06S
DF
08S
DF
10S
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RMM
V
RWM
V
R
50 100 200 400 600 800 1000 V
RMS Reverse Voltage
V
RMS
35 70 140 280 420 560 700 V
Average Forward Rectified Current @ T
A
= 40°C
I
O
1.0 A
Non-Repetitive Peak Forward Surge Current, 8.3 ms
single half-sine-wave superimposed on rated load
I
FSM
50 A
Forward Voltage (per element) @ I
F
= 1.0A
V
FM
1.1 V
Peak Reverse Current at Rated @ T
A
= 25°C
DC Blocking Voltage (per element) @ T
A
= 125°C
I
RM
10
500
µA
I
2
t Rating for Fusing (t<8.3ms)
I
2
t 10.4 A
2
s
Typical Total Capacitance (per element) (Note 1)
C
T
25 pF
Typical Thermal Resistance, Junction to Ambient
(Note 2)
R
qJA
40 °C/W
Operating and Storage Temperature Range
T
j
,T
STG
-65 to +150 °C
DF005S - DF10S
1.0A SURFACE MOUNT GLASS PASSIVATED BRIDGE
RECTIFIER
·
Case: DF-S
·
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
·
Moisture Sensitivity: Level 1 per J-STD-020C
·
Terminals: Finish - Tin. Solderable per MIL-STD-202,
Method 208
·
Polarity: As marked on Case
·
Marking: Type Number, See Page 3
·
Weight: 0.38 grams (approximate)
Mechanical Data
Notes: 1. Measured at 1.0 MHz and Applied Reverse Voltage of 4.0V DC.
2. Thermal resistance, junction to ambient, measured on PC board with 5.0mm
2
(0.03mm thick) land areas.
3. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
EU Directive Annex Notes 5 and 7
.
·
Glass Passivated Die Construction
·
Low Forward Voltage Drop, High Current Capability
·
Surge Overload Rating to 50A Peak
·
Designed for Surface Mount Application
·
UL Listed Under Recognized Component Index, File
Number E94661
·
Lead Free Finish, RoHS Compliant (Date Code 0532+)
(Note 3)
Single phase, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Maximum Ratings and Electrical Characteristics
@ T
A
= 25°C unless otherwise specified
DF-S
Dim Min Max
A
7.40 7.90
B
6.20 6.50
C
0.22 0.30
D
0.076 0.33
E
— 10.40
G
1.02 1.53
H
8.13 8.51
J
2.40 2.60
K
5.00 5.20
L
1.00 1.20
All Dimensions in mm
Features
A B
C
D E
G
H
J
L
K
SPICE MODELS: DF005S DF01S DF02S DF04S DF06S DF08S DF10S
