198 PHR-SI
Aluminum Capacitors
Power High Ripple Current Snap-In
Vishay BCcomponents
Table 1
Note
Unless otherwise specified, all electrical values in Table 2 apply at
T
amb
= 20 °C, P = 86 to 106 kPa, RH = 45 to 75 %
ORDERING EXAMPLE
Electrolytic capacitor 198 PHR-SI
470µF/450V; ± 20 %
Nominal case size: Ø 35 x 50 mm
2-terminal snap-in:
3-terminal snap-in:
DIMENSIONS in millimeters, MASS AND PACKAGING QUANTITIES
NOMINAL
CASE SIZE
Ø D x L
(mm)
Ø D
max.
L
max.
MASS
(g)
PACKAGING QUANTITIES
(units per box)
CARDBOARD BOX DIMENSIONS
L x W x H
22 x 25 23 27 ≈ 12 100 260 x 250 x 39
22 x 30 23 32 ≈ 16 100 260 x 250 x 44
22 x 35 23 37 ≈ 20 100 260 x 250 x 49
22 x 40 23 42 ≈ 23 100 260 x 250 x 54
25 x 25 26 27 ≈ 20 100 290 x 280 x 39
25 x 30 26 32 ≈ 22 100 290 x 280 x 44
25 x 35 26 37 ≈ 24 100 290 x 280 x 49
25 x 40 26 42 ≈ 27 100 290 x 280 x 54
25 x 45 26 47 ≈ 32 100 290 x 280 x 59
25 x 50 26 52 ≈ 38 100 290 x 280 x 64
30 x 25 31 27 ≈ 25 100 340 x 330 x 39
30 x 30 31 32 ≈ 30 100 340 x 330 x 44
30 x 35 31 37 ≈ 35 100 340 x 330 x 49
30 x 40 31 42 ≈ 40 100 340 x 330 x 54
30 x 45 31 47 ≈ 45 100 340 x 330 x 59
30 x 50 31 52 ≈ 50 100 340 x 330 x 64
35 x 25 36 27 ≈ 33 50 390 x 198 x 39
35 x 30 36 32 ≈ 40 50 390 x 198 x 44
35 x 35 36 37 ≈ 48 50 390 x 198 x 49
35 x 40 36 42 ≈ 55 50 390 x 198 x 54
35 x 45 36 47 ≈ 63 50 390 x 198 x 59
35 x 50 36 52 ≈ 72 50 390 x 198 x 64
35 x 60 36 62 ≈ 87 50 390 x 198 x 74
ELECTRICAL DATA
SYMBOL DESCRIPTION
C
R
rated capacitance at 100 Hz
I
R
rated RMS ripple current at 100 Hz, 85 °C
I
L1
max. leakage current after 1 minute at U
R
I
L5
max. leakage current after 5 minutes at U
R
ESR typ./max. equivalent series resistance at 100 Hz
Z typ./max. impedance at 10 kHz
Ordering code: MAL2198 57471E3
Former 12NC: 222219857471
Ordering code: MAL2198 77471E3
Former 12NC: 222219877471
