Models 5450,5451,5452,5453,
5454, 5455 & 5878
PLCC Socket Breakouts
Sales: 800-490-2361 Fax: 888-403-3360
Technical Assistance: 800-241-2060
PLCC socket breakouts fit into any PLCC socket and provide wire wrap pins for connection to your instrument. Gold
plated contacts assure noise free connections. A template (shown at right) is included which provides PLCC pin
numbers. One side is for chips with pin #1 in the top center position, the other side is for chips with pin #1 in the top left
position.
• Interfaces directly with board mounted PLCC sockets in place of the PLCC chip.
• PLCC socket is included to replace the PLCC chip in the circuit.
• Gold plated wire wrap pins and socket contacts assure noise free connections.
Pomona’s PLCC socket breakouts are perfect for use with logic analyzers, for field service testing, failure analysis, and
for use with emulators.
