CCI 104A40

Cross Number:

Item Description: 4 PIN PLASTIC LINEAR CAP

Qty Price
1 - 7 $19.80000
8 - 19 $15.45000
20 - 40 $13.50000
41 - 59 $13.05000
60 + $11.70000



Other Cross Reference

Manufacturer Date Code Qty Available Qty
CCI
  • Freelance Stock: 17
    Ships Immediately


CCI
  • Freelance Stock: 9
    Ships Immediately


CCI
  • Freelance Stock: 42
    Ships Immediately


CCI
  • Freelance Stock: 1
    Ships Immediately





Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

Potentiometer 1 & 2
Resistance Range
10 K ohms through 200 K ohms
Resistance Tolerance
Standard : ± 30%
Special: ± 10%, ± 20% available
Insulation Resistance
100 Megohms @ 250 VDC for 1 minute
Operational Torque
200 ± 80 gf.cm
Power Rating
0.0125 watt @ 50°C, Derated to no load at 85°C
Operating Voltage
50 VAC or 5 VDC maximum
Angle of Rotation
60° maximum
Life
Available Switch
Type
Momentary
Contact Resistance
100 milliohms maximum initially
Dielectric Strength
250 VAC 50/60 Hz for 1 minute
Insulation Resistance
100 Megohms minmum
@
100 VDC
Operational Force
800 ±
gf
Power Rating
5 VDC, 50 mA maximum
Travel
0.9 ± 0.4mm
Switch Life
500,000 cycles
Two Axis,
Mini-joystick With
Momentary Switch
Features
Compact Size (20x21x13mm)
Long Life 1 Million Cycles
Optional momentary switch is
operational at all rotations
Sturdy metal case with convenient
mounting tabs
Electrical and Mechanical Specifications
Series 252 DDaattaa SShheeeett
Mini-joystick
RoHS compliant
200 milliohms max after 500,000 cycles
switching 5 mA @ 5 VDC
1 - 2 © 2008 CTS Corporation. All rights reserved. I nformation subject to change.
7/02/08
CTS Electrocomponents www.ctscorp.com
1,000,000 cycles
Pat. No: US 6,353,430 , Taiwan: 128688.
®
Electrocomponents
Dielectric Strength
250 VAC 50/60 Hz for 1 minute
200
Ordering Information
mm
CTS Series 252
252 A 103 C 60 N A
RESIST TOL
A ±10%
B ±20%
C ±30%
TAP CONFIGURATION
N NO TAP
T 4° TAP AT CENTER
ROTATIONAL
ANGLE
40 40º
Operating Temperature
-10°C to +70°C
Mounting Information
PC Terminals
Soldering Conditions
260
±
5°C for 5 seconds
Electrical and Mechanical Specifications
RESISTANCE CODE
EXAMPLES
CODE RESISTANCE
103 10K
203 20K
503 50K
104 100K
124 120K
154 150K
DRIVE ARM LENGTH
DIM "L"
A 19.3mm
inch
DIMENSION:
FROM MOUNTING SIDE
MOUNTING HOLE DETAIL VIEWED
-0.0
(4)
Ø1.3
CENT.
5.00
13.30
2
CENT.
1
0
5.6
.TNE
C
d
c
.TNEC
3.00
0
5
.51
00
.
5
OPTIONAL SWITCH
09.1
Ø1.0
3
HOLES FOR
(4)
-0.0
+0.1
.TNEC
b
a
1
2
3
(6)
Ø1.0
+0.1
-0.0
4.50
CENT.
+0.1
TERMINALS
B 24.3mm
LENGTH FROM
MOUNTING SURFACE
50 50º
60 60º
Potentiometer 1 & 2
SWITCH
CONFIGURATION
A W/O SWITCH
B MOMENTARY SWITCH
2 - 2
© 2008 CTS Corporation. All rights reserved. I nformation subject to change.
7/02/08
CTS Electrocomponents www.ctscorp.com
11.2
2.11
5.9
16
.
0 C
E
NT.
9.5 CENT.
VR 2
12
.
0 C
E
NT.
1RV
16.0 CENT.
9.3
"L"MID
2.21
OPERATION ANGLE
(ALL DIRECTION)
3.0±3.3
0.8±0.1(6)
3.7
1 2
3.0
±
8.3
1.1(4)
3
5
3
°
~
6
3
°
A A
11.8
CIRCUIT DIAGRAM
SWITCH
d
b
c a
1.90±0.05
SECTION A-A
1.20±0.05
