Part Number Table
Description
Size Inch
(mm)
Dielectric Capacitance Tolerance
Rated
Voltage
(VDC)
Termination Part Number
Capacitor, 1812, NP0, 3,000 V, 68 pF
1812
(4532)
NP0
(C0G)
68 pF
±5% 3,000 V
Cu / Ni / Sn
MCCA000860
Capacitor, 1812, NP0, 3,000 V, 100 pF 100 pF MCCA000861
Capacitor, 1812, NP0, 3,000 V, 150 pF 150 pF MCCA000862
Capacitor, 1812, NP0, 3,000 V, 220 pF 220 pF MCCA000863
Capacitor, 1812, NP0, 3,000 V, 330 pF 330 pF MCCA000864
Capacitor, 1812, NP0, 3,000 V, 470 pF 470 pF MCCA000865
Capacitor, 1812, X7R, 630 V, 1 nF
X7R
1 nF
±10%
630 V
MCCA000866
Capacitor, 1812, X7R, 630 V, 1.5 nF 1.5 nF MCCA000867
Capacitor, 1812, X7R, 630 V, 2.2 nF 2.2 nF MCCA000868
Capacitor, 1812, X7R, 630 V, 3.3 nF 3.3 nF MCCA000869
Capacitor, 1812, X7R, 630 V, 4.7 nF 4.7 nF MCCA000870
Capacitor, 1812, X7R, 630 V, 6.8 nF 6.8 nF MCCA000871
Capacitor, 1812, X7R, 630 V, 10 nF 10 nF MCCA000872
Capacitor, 1812, X7R, 630 V, 15 nF 15 nF MCCA000873
Capacitor, 1812, X7R, 630 V, 22 nF 22 nF MCCA000874
Capacitor, 1812, X7R, 630 V, 33 nF 33 nF MCCA000875
Capacitor, 1812, X7R, 630 V, 47 nF 47 nF MCCA000876
Capacitor, 1812, X7R, 630 V, 68 nF 68 nF MCCA000877
Capacitor, 1812, X7R, 630 V, 100 nF 100 nF MCCA000878
Capacitor, 1812, X7R, 1,000 V, 330 pF 330 pF
1,000 V
MCCA000879
Capacitor, 1812, X7R, 1,000 V, 470 pF 470 pF MCCA000880
Capacitor, 1812, X7R, 1,000 V, 680 pF 680 pF MCCA000881
Capacitor, 1812, X7R, 1,000 V, 1 nF 1 nF MCCA000882
Capacitor, 1812, X7R, 1,000 V, 1.5 nF 1.5 nF MCCA000883
Capacitor, 1812, X7R, 1,000 V, 2.2 nF 2.2 nF MCCA000884
Capacitor, 1812, X7R, 1,000 V, 3.3 nF 3.3 nF MCCA000885
Capacitor, 1812, X7R, 1,000 V, 4.7 nF 4.7 nF MCCA000886
Capacitor, 1812, X7R, 1,000 V, 6.8 nF 6.8 nF MCCA000887
Capacitor, 1812, X7R, 1,000 V, 10 nF 10 nF MCCA000888
Capacitor, 1812, X7R, 1,000 V, 15 nF 15 nF MCCA000889
Capacitor, 1812, X7R, 3,000 V, 680 pF 680 pF
3,000 V
MCCA000890
Capacitor, 1812, X7R, 3,000 V, 1 nF 1 nF MCCA000891
