HV MLCC

Page <4> 17/04/12 V1.1

www.element14.com

www.farnell.com

www.newark.com

Change Range (X7R Dielectric 200 V to 3,000 V):

Dielectric X7R

Size 0805 1206 1210 1812

Rated Voltage (V dc) 200 200 630 1,000 2,000 200 630 1,000 630 1,000 3,000

100 pF (101) B

150 pF (151) B D D D D

0.015 µF (153) D D D C D D K

0.022 µF (223) D D G C D D

220 pF (221) D D D D

330 pF (331) D D D D D

470 pF (471) D D D D D

680 pF (681) D D D D D K

1,000 pF (102) D D G C D D D D K

1,500 pF (152) D D D C D D D D

2,200 pF (222) D D C D D D D

3,300 pF (332) D D D C D D D D

4,700 pF (472) D D C D G D D

6,800 pF (682) D D D C D G D D

0.010 µF (103) D D C D G D D

0.033 µF (333) G G C G D

0.047 µF (473) G D G D

0.068 µF (683) G G K

0.10 µF (104) G G K

0.15 µF (154) M

0.22 µF (224) M

0.33 µF (334) M

0.47 µF (474) M

Capacitance

1. The letter in cell is expressed the symbol of product thickness

2. The letter in cell with “^” mark is expressed product with Ag / Ni / Sn terminations

HV MLCC

Page <5> 17/04/12 V1.1

www.element14.com

www.farnell.com

www.newark.com

Part Number Table

Description

Size Inch

(mm)

Dielectric Capacitance Tolerance

Rated

Voltage

(VDC)

Termination Part Number

Capacitor, 0603, NP0, 200 V, 1 pF

0603

(1608)

NP0

(C0G)

1 pF

±0.25 pF

200 V

Cu / Ni / Sn

MCCA000634

Capacitor, 0603, NP0, 200 V, 1.5 pF 1.5 pF MCCA000635

Capacitor, 0603, NP0, 200 V, 2.2 pF 2.2 pF MCCA000636

Capacitor, 0603, NP0, 200 V, 3.3 pF 3.3 pF MCCA000637

Capacitor, 0603, NP0, 200 V, 4.7 pF 4.7 pF MCCA000638

Capacitor, 0603, NP0, 200 V, 6.8 pF 6.8 pF MCCA000639

Capacitor, 0603, NP0, 200 V, 10 pF 10 pF

±5%

MCCA000640

Capacitor, 0603, NP0, 200 V, 15 pF 15 pF MCCA000641

Capacitor, 0603, NP0, 200 V, 22 pF 22 pF MCCA000642

Capacitor, 0603, NP0, 200 V, 33 pF 33 pF MCCA000643

Capacitor, 0603, NP0, 200 V, 47 pF 47 pF MCCA000644

Capacitor, 0603, NP0, 200 V, 68 pF 68 pF MCCA000645

Capacitor, 0603, NP0, 200 V, 100 pF 100 pF MCCA000646

Capacitor, 0603, NP0, 200 V, 150 pF 150 pF MCCA000647

Capacitor, 0603, NP0, 200 V, 220 pF 220 pF MCCA000648

Capacitor, 0805, NP0, 200 V, 1 pF

0805

(2012)

1 pF

±0.25 pF

MCCA000649

Capacitor, 0805, NP0, 200 V, 1.5 pF 1.5 pF MCCA000650

Capacitor, 0805, NP0, 200 V, 2.2 pF 2.2 pF MCCA000651

Capacitor, 0805, NP0, 200 V, 3.3 pF 3.3 pF MCCA000652

Capacitor, 0805, NP0, 200 V, 4.7 pF 4.7 pF MCCA000653

Capacitor, 0805, NP0, 200 V, 6.8 pF 6.8 pF MCCA000654

Capacitor, 0805, NP0, 200 V, 10 pF 10 pF ±5% MCCA000655

Capacitor, 0805, NP0, 500 V, 1 pF 1 pF

±0.25 pF

500 V

MCCA000656

Capacitor, 0805, NP0, 500 V, 1.5 pF 1.5 pF MCCA000657

Capacitor, 0805, NP0, 500 V, 2.2 pF 2.2 pF MCCA000658

Capacitor, 0805, NP0, 500 V, 3.3 pF 3.3 pF MCCA000659

Capacitor, 0805, NP0, 500 V, 4.7 pF 4.7 pF MCCA000660

Capacitor, 0805, NP0, 500 V, 6.8 pF 6.8 pF MCCA000661

Capacitor, 0805, NP0, 500 V, 10 pF 10 pF

±5%

MCCA000662

Capacitor, 0805, NP0, 500 V, 15 pF 15 pF MCCA000663

Capacitor, 0805, NP0, 500 V, 22 pF 22 pF MCCA000664

Capacitor, 0805, NP0, 500 V, 33 pF 33 pF MCCA000665

HV MLCC

Page <6> 17/04/12 V1.1

www.element14.com

www.farnell.com

www.newark.com

Part Number Table

Description

Size Inch

(mm)

Dielectric Capacitance Tolerance

Rated

Voltage

(VDC)

Termination Part Number

Capacitor, 0805, NP0, 500 V, 47 pF

0805

(2012)

NP0

(C0G)

47 pF

±5% 500 V

Cu / Ni / Sn

MCCA000666

Capacitor, 0805, NP0, 500 V, 68 pF 68 pF MCCA000667

Capacitor, 0805, NP0, 500 V, 100 pF 100 pF MCCA000668

Capacitor, 0805, NP0, 500 V, 150 pF 150 pF MCCA000669

Capacitor, 0805, NP0, 500 V, 220 pF 220 pF MCCA000670

Capacitor, 0805, NP0, 500 V, 330 pF 330 pF MCCA000671

Capacitor, 0805, X7R, 200 V, 100 pF

X7R

100 pF

±10%

200 V

MCCA000672

Capacitor, 0805, X7R, 200 V, 150 pF 150 pF MCCA000673

Capacitor, 0805, X7R, 200 V, 15 nF 15 nF MCCA000674

Capacitor, 0805, X7R, 200 V, 22 nF 22 nF MCCA000675

Capacitor, 1206, NP0, 200 V, 1.5 pF

1206

(3216)

NP0

(C0G)

1.5 pF

±0.25 pF

MCCA000676

Capacitor, 1206, NP0, 200 V, 2.2 pF 2.2 pF MCCA000677

Capacitor, 1206, NP0, 200 V, 3.3 pF 3.3 pF MCCA000678

Capacitor, 1206, NP0, 200 V, 4.7 pF 4.7 pF MCCA000679

Capacitor, 1206, NP0, 200 V, 6.8 pF 6.8 pF MCCA000680

Capacitor, 1206, NP0, 200 V, 10 pF 10 pF

±5%

MCCA000681

Capacitor, 1206, NP0, 200 V, 15 pF 15 pF MCCA000682

Capacitor, 1206, NP0, 200 V, 22 pF 22 pF MCCA000683

Capacitor, 1206, NP0, 200 V, 33 pF 33 pF MCCA000684

Capacitor, 1206, NP0, 200 V, 47 pF 47 pF MCCA000685

Capacitor, 1206, NP0, 200 V, 68 pF 68 pF MCCA000686

Capacitor, 1206, NP0, 200 V, 100 pF 100 pF MCCA000687

Capacitor, 1206, NP0, 200 V, 150 pF 150 pF MCCA000688

Capacitor, 1206, NP0, 200 V, 220 pF 220 pF MCCA000689

Capacitor, 1206, NP0, 200 V, 330 pF 330 pF MCCA000690

Capacitor, 1206, NP0, 200 V, 470 pF 470 pF MCCA000691

Capacitor, 1206, NP0, 200 V, 680 pF 680 pF MCCA000692

Capacitor, 1206, NP0, 200 V, 1.5 nF 1.5 nF MCCA000693

Capacitor, 1206, NP0, 200 V, 2.2 nF 2.2 nF MCCA000694

Capacitor, 1206, NP0, 630 V, 1.5 pF 1.5 pF

±0.25 pF 630 V

MCCA000695

Capacitor, 1206, NP0, 630 V, 2.2 pF 2.2 pF MCCA000696

Capacitor, 1206, NP0, 630 V, 3.3 pF 3.3 pF MCCA000697
