1-717-217-2299 www.lumberg-automationusa.com16

M8-Round-Plug Connector According to IEC 61976-2-104

M8-Cordsets

M8-Male Straight

Actuator-/Sensor-Cordsets, Single Ended,

M8-Male Straight Connector, 3- and 4-Poles with

Threaded Joint and Molded Cable. IP 67 Rated.

Cable Type: 06 | 07 = PVC, orange

224 | 225 = PUR, halogen-free, black

M8-Female 90°

Actuator-/Sensor-Cordsets, Single Ended,

M8-Female 90° Connector, 3- and 4-Poles with

Threaded Joint and Molded Cable. IP 67 Rated.

Cable Type: 06 | 07 = PVC, orange

224 | 225 = PUR, halogen-free, black

M8-Female Straight

Actuator-/Sensor-Cordsets, Single Ended,

M8-Female Straight Connector, 3-, 4- and 8-Poles

with Threaded Joint and Molded Cable. IP 67 Rated.

Cable Type: 06 | 07 = PVC, orange

224 | 225 = PUR, halogen-free, black

M8-Male 90°

Actuator-/Sensor-Cordsets, Single Ended,

M8-Male 90° Connector, 3- and 4-Poles with

Threaded Joint and Molded Cable. IP 67 Rated.

Cable Type: 06 | 07 = PVC, orange

224 | 225 = PUR, halogen-free, black

Part No. Part No.

RSMV 3-06/2 M RSMV 4-07/2 M

RSMV 3-06/5 M RSMV 4-07/5 M

RSMV 3-06/10 M RSMV 4-07/10 M

RSMV 3-224/2 M RSMV 4-225/2 M

RSMV 3-224/5 M RSMV 4-225/5 M

RSMV 3-224/10 M RSMV 4-225/10 M

Part No. Part No.

RSMWV 3-06/2 M RSMWV 4-07/2 M

RSMWV 3-06/5 M RSMWV 4-07/5 M

RSMWV 3-06/10 M RSMWV 4-07/10 M

RSMWV 3-224/2 M RSMWV 4-225/2 M

RSMWV 3-224/5 M RSMWV 4-225/5 M

RSMWV 3-224/10 M RSMWV 4-225/10 M

Part No.

RKMV 3-06/2 M

RKMV 3-06/5 M

RKMV 3-06/10 M

RKMV 3-224/2 M

RKMV 3-224/5 M

RKMV 3-224/10 M

RKMV 4-07/2 M

RKMV 4-07/5 M

RKMV 4-07/10 M

RKMV 4-225/2 M

RKMV 4-225/5 M

RKMV 4-225/10 M

RKMV 8-354/2 M

RKMV 8-354/5 M

RKMV 8-354/10 M

Part No. Part No.

RKMWV 3-06/2 M RKMWV 4-07/2 M

RKMWV 3-06/5 M RKMWV 4-07/5 M

RKMWV 3-06/10 M RKMWV 4-07/10 M

RKMWV 3-224/2 M RKMWV 4-225/2 M

RKMWV 3-224/5 M RKMWV 4-225/5 M

RKMWV 3-224/10 M RKMWV 4-225/10 M

RSMV

RKMWV

RKMV

RSMWV

www.lumberg-automationusa.com 1-717-217-2299 17

M8-Round-Plug Connector According to IEC 61976-2-104

M8-Cordsets

M8-Female 90° – LED

Actuator-/Sensor-Cordsets with LED, Single Ended,

M8-Female 90° Connector, 3-Poles with Threaded

Joint and Molded Cable. IP 67 Rated.

Cable Type: 06 = PVC, orange

224 = PUR, halogen-free, black

M8-Female 90° – Snap-In – LED

Actuator-/Sensor-Cordsets with LED, Single Ended,

M8-Female 90° Connector, 3-Poles with Snap-In

Joint and Molded Cable. IP 65 Rated.

Cable Type: 06 = PVC, orange

224 = PUR, halogen-free, black

Part No.

RKMWV/LED A 3-06/2 M

RKMWV/LED A 3-06/5 M

RKMWV/LED A 3-06/10 M

RKMWV/LED A 3-224/2 M

RKMWV/LED A 3-224/5 M

RKMWV/LED A 3-224/10 M

Part No.

RKMW/LED A 3-06/2 M

RKMW/LED A 3-06/5 M

RKMW/LED A 3-06/10 M

RKMW/LED A 3-224/2 M

RKMW/LED A 3-224/5 M

RKMW/LED A 3-224/10 M

RKMWV/LED

RKMW/LED

M8-Female Straight – Snap-In

Actuator-/Sensor-Cordsets, Single Ended,

M8-Female Straight Connector, 3- and 4-Poles with

Snap-In Joint and Molded Cable. IP 65 Rated.

Cable Type: 06 | 07 = PVC, orange

224 | 225 = PUR, halogen-free, black

M8-Female 90° – Snap-In

Actuator-/Sensor-Cordsets, Single Ended,

M8-Female 90° Connector, 3- and 4-Poles with Snap-

In Joint and Molded Cable. IP 65 Rated.

Cable Type: 06 | 07 = PVC, orange

224 | 225 = PUR, halogen-free, black

Part No.

RKM 3-06/2 M

RKM 3-06/5 M

RKM 3-06/10 M

RKM 3-224/2 M

RKM 3-224/5 M

RKM 3-224/10 M

RKM 4-07/2 M

RKM 4-07/5 M

RKM 4-07/10 M

RKM 4-225/2 M

RKM 4-225/5 M

RKM 4-225/10 M

Part No.

RKMW 3-06/2 M

RKMW 3-06/5 M

RKMW 3-06/10 M

RKMW 3-224/2 M

RKMW 3-224/5 M

RKMW 3-224/10 M

RKMW 4-07/2 M

RKMW 4-07/5 M

RKMW 4-07/10 M

RKMW 4-225/2 M

RKMW 4-225/5 M

RKMW 4-225/10 M

RKM

RKMW

Cordsets

Single-Ended

Cordsets, Single-Ended

1-717-217-2299 www.lumberg-automationusa.com18

M8-Female Straight – Shielded

Actuator-/Sensor-Cordsets, Single Ended,

M8-Female Straight Connector, 3- and 4-Poles,

Shielded with Threaded Joint and Molded Cable.

IP 67 Rated.

Cable Type: 357 | 358 = PUR, halogen-free, black

M8-Female 90° – Shielded

Actuator-/Sensor-Cordsets, Single Ended,

M8-Female 90° Connector, 3- and 4-Poles, Shielded

with Threaded Joint and Molded Cable.

IP 67 Rated.

Cable Type: 357 | 358 = PUR, halogen-free, black

Part No.

RKMVS 3-357/5 M

RKMVS 4-358/5 M

Part No.

RKMWVS 3-357/5 M

RKMWVS 4-358/5 M

RKMVS

RKMWVS

M8 | M12-Round-Plug Connector According to IEC 61976-2-104 | IEC 61076-2-101

M8-Cordsets | M12-Cordsets

M12-Round-Plug Connector According to IEC 61076-2-101

M12-Cordsets

M12-Male Straight

Actuator-/Sensor-Cordsets, Single Ended,

M12-Male Straight Connector, 3-, 4-, 5- and 8-Poles

with Threaded Joint and Molded Cable. IP 67 Rated.

Cable Types:

06 | 07 | 56 = PVC, orange

224 | 225 | 228 | 282 = PUR, halogen-free, black

251 | 259 | 260 = PUR, halogen-free, weld

and spark proof, orange

Part No. Part No.

RST 3-06/2 M RST 4-251/2 M

RST 3-06/5 M RST 4-251/5 M

RST 3-06/10 M RST 4-251/10 M

RST 3-224/2 M RST 5-56/2 M

RST 3-224/5 M RST 5-56/5 M

RST 3-224/10 M RST 5-56/10 M

RST 3-260/2 M RST 5-228/2 M

RST 3-260/5 M RST 5-228/5 M

RST 3-260/10 M RST 5-228/10 M

RST 4-07/2 M RST 5-259/2 M

RST 4-07/5 M RST 5-259/5 M

RST 4-07/10 M RST 5-259/10 M

RST 4-225/2 M RST 8-282/2 M

RST 4-225/5 M RST 8-282/5 M

RST 4-225/10 M RST 8-282/10 M

RST
