4-32
Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com
Color = 0) Blank 1) Red or Red/Green Bicolor 2) Green 3) Yellow 4) Yellow/Green Bicolor
7) Orange 8) Blue
Features
Multiple CBIs form horizontal LED arrays on 5.08mm
(0.200”) center-lines.
High Contrast, UL 94 V-0 rated, black housing
Oxygen index: 32%
Polymer content: PBT, 0.405 g
Housing stand-offs facilitate PCB cleaning
Solderability per MIL-STD-202F, method 208F
LEDs are safe for direct viewing per IEC 825-1, EN-60825-1
Compatible with:
553-xxxx-306 Bi-Level Array
Tolerance note: As noted, otherwise:
LED Protrusion: ±0.04 mm [±0.016]
CBI Housing: ±0.02mm[±0.008]
Custom Combinations
• Contact factory for information on custom bi-level arrays and
color combinations.
5.08
[.200]
5.08
[.200]
9.65
[.380]
3.68 [.145]
CATHODE
Red/Yel
Cathode for
Bicolor
8.76
[.345]
2.54
[.100]
5.08
[.200]
RECOMMENDED
P.C. BOARD
LAYOUT
1.0
[.040]
2.54 [.100]
2.54
[.100]
2.54
[.100]
2.9
[.115]
Top LED
.254
[.100]
.50
[.020]
3mm
LED CBI
®
Circuit Board Indicator
Bi-level
553-xxxx-300
Dimensions in mm [inches]
PART NO. COLOR*
HIGH EFFICIENCY - LED TYPE 01
553-0111-300 Red
553-0122-300 Green
553-0133-300 Yellow
553-0177-300 Orange
553-0188-300 Blue
³
LOW CURRENT - LED TYPE 02
553-0211-300 Red
553-0222-300 Green
553-0233-300 Yellow
RESISTOR 5 VOLTS - LED TYPE 03
553-0311-300 Red
553-0322-300 Green
553-0333-300 Yellow
BI-COLOR - LED TYPE 07
553-0711-300 Red/Green
553-0744-300 Yellow/Green
NON-DIFFUSED - LED TYPE 22
553-2211-300 Red
553-2222-300 Green
553-2233-300 Yellow
* Top-Bottom LED
REVERSE POLARITY OPTION AVAILABLE
See Part Number Ordering Code below.
Standard Polarity shown in drawing: Cathode right
Color
5 5 3 - x x x x - 3 x 0
Top Position
Bottom Position
LED Type
Series
PART NUMBER ORDERING CODE
Housing Type
Polarity Option
0 - Standard Cathode Right
1 - Reverse Cathode Left
NEW
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE
DEVICES
³
4-33
Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com
4
553-xxxx-300
Peak I
V
V
F
Test Viewing LED
Part Number Color Wavelength nm mcd Volts Current (mA) Angle 2
ΘΘ
½
Data sheet Page #
553-0111-300 Red 650 10 2 10 45° 521-9427 4-64
553-0122-300 Green 563 16 2.1 10 45° 521-9408 4-64
553-0133-300 Yellow 585 6.3 2.1 10 45° 521-9428 4-64
553-0177-300 Orange 600 7 2.2 10 60° 521-9498 4-58
553-0188-300 Blue 428 12 3.5 10 70° 521-9831 4-57
HIGH EFFICIENCY
Peak I
V
V
F
Test Viewing LED
Part Number Color Wavelength nm mcd Volts Current (mA) Angle 2
ΘΘ
½
Data sheet Page #
553-0211-300 Red 635 1.6 1.7 2 60° 521-9324 4-60
553-0222-300 Green 565 1.6 1.9 2 60° 521-9326 4-60
553-0233-300 Yellow 585 1.6 1.8 2 60° 521-9325 4-60
LOW CURRENT
Peak I
V
Test Forward Viewing LED
Part Number Color Wavelength nm mcd Voltage Current (mA) Angle 2
ΘΘ
½
Data sheet Page #
553-0311-300 Red 635 29 5 10 60° 521-9215 4-59
553-0322-300 Green 565 19 5 10 60° 521-9323 4-59
553-0333-300 Yellow 585 12.6 5 10 60° 521-9322 4-59
INTEGRAL RESISTOR, 5 VOLTS
Peak I
V
V
F
Test Viewing LED
Part Number Color Wavelength nm mcd Volts Current (mA) Angle 2
ΘΘ
½
Data sheet Page #
553-0711-300 Red/Green 635/565 4.7/10 2/2.1 10 50° 521-9459 4-63
553-0744-300 Yellow/Green 585/565 4.3/6.3 2.1*/2.1* 10 80° 521-9478 4-62
BI-COLOR
Peak I
V
V
F
Test Viewing LED
Part Number Color Wavelength nm mcd Volts* Current (mA) Angle 2
ΘΘ
½
Data sheet Page #
553-2211-300 Red 635 29 2 10 45° 521-9432 4-61
553-2222-300 Green 565 50 2.1 10 45° 521-9430 4-61
553-2233-300 Yellow 585 20 2.1 10 45° 521-9431 4-61
NON-DIFFUSED
Typical Operating Characteristics
(T
A
=25°C)
See LED data sheet for additional information
See page 4-70 and 4-71 for Reference Only LED Drive Circuit Examples. See page 4-72 for Pin Out
* I
F
= 20mA
* I
F
= 20mA
4-57
Dialight Corporation • 1501 Route 34 South • Farmingdale, NJ 07727 • TEL: (732) 919-3119 • FAX: (732) 751-5778 •www.dialight.com
4
3mm Discrete LED
Tinted, Diffused
521-9831
3.4 [.134]
3.1 [.122]
0.6 [.024]
0.4 [.016]
ø
2.9 [.114]
2.7 [.106]
4.8 [.189]
4.4 [.173]
3.7 [.145]
3.5 [.138]
6.1 [.240]
5.7 [.224]
29 [1.142]
27 [1.063]
1.8 [.071]
1.2 [.047]
CATHODE
2.54 [.100]
0.6 [.024]
0.4 [.016]
0.7 [.028]
0.4 [.016]
4.8 [.189]
4.4 [.173]
SURFACE NOT FLAT
PART NO. COLOR
521-9831 Blue
³
Blue
ABSOLUTE MAXIMUM RATINGS (T
A
=25°C)
-9831
Power Dissipation (mW) 100
Forward Current (mA) 20
Derating (mA/°C)
From 55°C
.44
Operating Temperature (°C) -40/+100
Storage Temperature (°C) -40/+100
Soldering Temperature 260°C, 5 seconds, 1.6 mm from case
Blue
OPERATING CHARACTERISTICS (T
A
=25°C)
-9831
Luminous Intensity (mcd) Min. 6.3
I
F
=10mA Typical 12
Peak Wavelength (nm) Typical 428
λ Peak
Viewing Angle (2
Θ½) Typical 70°
Forward Voltage (V) Typical 3.5
I
F
=10mA Max. 4.2
Reverse Voltage (V) IR=10µA Min. 3
Dimensions in mm [inches]
Θ
is the off axis angle at which the luminous intensity is half the axial luminous intensity
Solder Adherence per MIL-STD-202E, Method 208C
MOUNTING CLIP:
515-0006
located on page 4-65
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE
DEVICES
³
NEW
