STELLEX / WATKIN-JOHNSON A82

Cross Number:

Item Description: RF Amplifier 10-300MHz NF 2.8dB VSWR:1.3:1

Qty Price
1 - 1 $216.96800
2 - 3 $169.30079
4 - 6 $147.93273
7 - 13 $138.07055
14 + $128.20837



Other Cross Reference

Manufacturer Date Code Qty Available Qty
STELLEX / WATKIN-JOHNSON 9400
  • Freelance Stock: 28
    Ships Immediately


Watkin-Johnson 9709
  • Freelance Stock: 1
    Ships Immediately





Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

Specifications subject to change without notice.
North America: 1-800-366-2266
Visit www.macom.com for complete contact and product information.
Typical Performance @ 25°C
Guaranteed Characteristics Typical
0
°
°°
°
to 50
°
°°
°
C -54
°
°°
°
to +85
°
°°
°
C
Frequency
Small Signal Gain (min.)
Gain Flatness (max.)
Reverse Isolation
Noise Figure (max.)
Power Output @ 1 dB comp. (min.)
IP3
IP2
Second Order Harmonic IP
VSWR Input / Output (max.)
DC Current @ 15 Volts (max.)
Absolute Maximum Ratings
Storage Temperature
Max. Case Temperature
Max. DC Voltage
Max. Continuous RF Input Power
Max. Short Term RF Input Power (1 minute max.)
Max. Peak Power (3
µ
sec max.)
SSeries Burn-in Temperature (Case)
Thermal Data: V
cc
= 15 Vdc
Thermal Resistance
θ
jc
Transistor Power Dissipation P
d
Junction Temperature Rise Above Case T
jc
Outline Drawings
Package TO-8 Surface Mount SMA Connectorized
Figure
Model
· HIGH REVERSE ISOLATION: >28.5 dB (TYP.)
· HIGH LEVEL OUTPUT: +20 dBm (TYP.)
· LOW NOISE: 2.8 dB (TYP.)
· high gain: 24.5 dB (TYP.)
A82/SMA82
20 TO 250 MHz
CASCADABLE AMPLIFIER
Specifications (Rev. Date: 11/00)*
* Measured in a 50-ohm system at +15 Vdc Nominal. Subject to change without notice.
BG
AA
CE
10-300 MHz
25.0 dB
±0.3 dB
29 dB
2.8 dB
20.0 dBm
+31 dBm
+36 dBm
+42 dBm
1.3:1 / 1.3:1
50 mA
20-250 MHz
24.0 dB
±0.7 dB
18.0 dBm
19.0 dBm
1.9:1 / 1.9:1
54 mA
1.7:1 / 1.7:1
52 mA
20-250 MHz
23.5 dB
±1.0 dB
4.0 dB
-62° to +125°C
125°C
+17 Volts
+10 dBm
50 mW
0.5 W
125°C
144°C/W
0.273 W
39°C
A82
SMA82
CA82
