SW-316

Part # SW-316
Description PRINTED CIRCUIT TRANSFORMER,Isolation Transformer Primary
Category TRANSFORMER
Availability In Stock
Qty 1
Qty Price
1 + $7.49255
Manufacturer Available Qty
STANCOR
Date Code: 0246
  • Shipping Freelance Stock: 1
    Ships Immediately

Related Items

01-612-664-8021-00
ALADDIN
TRANSFORMER
01-612-664-8021-00

019-5017-00
ACI
TRANSFORMER
019-5017-00

019-8021-00
KING RADIO CORP
TRANSFORMER
019-8021-00

019-8032-00
TOKO
TRANSFORMER
019-8032-00

019-8040-06A
TOKO
TRANSFORMER
019-8040-06A

02134
Vicor Corporation
TRANSFORMER
02134
$6.32840


Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

7/15 ASB Inc. sales@asb.co.kr Tel: +82-42-528-7225 February 2017
ASW316
5 ~ 3000 MHz MMIC Amplifier
0 2 4 6 8 10
Output Power (dBm)
-70
-65
-60
-55
-50
-45
-40
ACLR (dBc)
20 MHz BW
10 MHz BW
1) Test Source : LTE_FDD_test model 3.1, BW: 10 MHz & 20 MHz, Test Frequency: 1.8 GHz
2) Test Source : LTE_FDD_test model 3.1, BW: 20 MHz, Test Frequency: 1.8 GHz
LTE ACLR – 10 MHz & 20 MHz
LTE ACLR – 20 MHz
8/15 ASB Inc. sales@asb.co.kr Tel: +82-42-528-7225 February 2017
ASW316
5 ~ 3000 MHz MMIC Amplifier
1) OIP3 is measured with two tones at an output power of +6 dBm/tone
separated by 1 MHz.
Board Layout (FR4, 40x40 mm
2
, 0.8T)
Schematic
S-parameters & K-factor
APPLICATION CIRCUIT
Frequency (MHz)
1950
Magnitude S21 (dB)
16
Magnitude S11 (dB)
-20
Magnitude S22 (dB)
-10
Output P1dB (dBm)
22.5
Output IP3
1)
(dBm)
39
Noise Figure (dB)
2.6
Device Voltage (V)
+5
Current (mA)
110
WCDMA
1950 MHz
+5 V
L1=3.9 nH
RF IN
RF OUT
ASW316
Vs=5 V
C1=3.3 pF
C5=68 pF
C6=1 F
L2=2.7 nH
C2=100 pF
C3=0.5 pF C4=1.2 pF
1700 1800 1900 2000 2100 2200
0
5
10
15
20
Gain (dB)
Frequency (MHz)
1700 1800 1900 2000 2100 2200
-30
-25
-20
-15
-10
-5
0
S11 (dB)
Frequency (MHz)
1700 1800 1900 2000 2100 2200
-20
-15
-10
-5
0
S22 (dB)
Frequency (MHz)
0 500 1000 1500 2000 2500 3000 3500
0
1
2
3
4
5
Stability Factor
Frequency (MHz)
9/15 ASB Inc. sales@asb.co.kr Tel: +82-42-528-7225 February 2017
ASW316
5 ~ 3000 MHz MMIC Amplifier
1) OIP3 is measured with two tones at an output power of +4 dBm/tone
separated by 1 MHz.
Board Layout (FR4, 40x40 mm
2
, 0.8T)
Schematic
S-parameters & K-factor
APPLICATION CIRCUIT
Frequency (MHz)
2400
Magnitude S21 (dB)
15.5
Magnitude S11 (dB)
-12
Magnitude S22 (dB)
-12
Output P1dB (dBm)
18
Output IP3
1)
(dBm)
38.5
Noise Figure (dB)
2.8
Device Voltage (V)
+5
Current (mA)
110
WLAN
2400 MHz
+5 V
1800 2000 2200 2400 2600 2800 3000
0
5
10
15
20
Gain (dB)
Frequency (MHz)
1800 2000 2200 2400 2600 2800 3000
-25
-20
-15
-10
-5
0
S11 (dB)
Frequency (MHz)
1800 2000 2200 2400 2600 2800 3000
-20
-15
-10
-5
0
S22 (dB)
Frequency (MHz)
0 500 1000 1500 2000 2500 3000 3500
0
1
2
3
4
5
Stability Factor
Frequency (MHz)
L1=15 nH
RF IN
RF OUT
ASW316
Vs=5 V
C1=10 pF
C4=68 pF
C5=1 F
L2=3.3 nH
C2=1.8 pF
C3=1.2 pF
3 mm
