5/15 ASB Inc. sales@asb.co.kr Tel: +82-42-528-7225 February 2017
5 ~ 3000 MHz MMIC Amplifier
1) OIP3 is measured with two tones at an output power of +5
dBm/tone separated by 1 MHz.
Board Layout (FR4, 40x40 mm
2
, 0.8T)
L1=15 nH
RF IN
RF OUT
ASW316
Vs=5 V
C1=100 pF
C5=68 pF
C6=1 F
L2=8.2 nH
C2=100 pF
C3=1.2 pF
C4=1.2 pF
600 700 800 900 1000 1100 1200
0
5
10
15
20
25
Gain (dB)
Frequency (MHz)
600 700 800 900 1000 1100 1200
-25
-20
-15
-10
-5
0
S11 (dB)
Frequency (MHz)
600 700 800 900 1000 1100 1200
-20
-15
-10
-5
0
S22 (dB)
Frequency (MHz)
0 500 1000 1500 2000 2500 3000 3500
0
1
2
3
4
5
Stability Factor
Frequency (MHz)
