[ 107 ]
POWER DIVIDERS
0º : 2-WAY
POWER DIVIDERS
0º : 2-WAY
201 McLean Boulevard • Paterson, New Jersey 07504 • Tel: (973) 881-8800 • Fax: (973) 881-8361
E-Mail: sales@synergymwave.com • World Wide Web: http://www.synergymwave.com
2 - 300 25/20 30/20 25/20 0.5/0.9 0.6/0.8 0.8/1.0 3.0 4.0 5.0 0.4 0.5 0.5 159 1 SDL-1
2 - 500 35/18 35/25 27/20 0.3/0.8 0.3/0.6 0.5/1.0 1.0 2.0 3.0 0.15 0.2 0.3 159 2 SDL-173
2 - 1000 35/25 27/17 23/17 0.5/0.6 0.7/0.9 1.2/1.5 1.0 2.0 4.0 0.2 0.3 0.6 159 2 SDL-100
5 - 500 25/20 30/20 25/20 0.4/0.7 0.5/0.8 0.6/1.0 3.0 4.0 5.0 0.4 0.4 0.6 159 2 SDL-2
5 - 750 25/18 30/23 23/17 0.6/1.4 0.8/1.6 1.5/1.8 1.0 3.0 5.0 0.2 0.3 0.5 159 2 SDL-174
5 - 500 25/20 30/20 25/20 0.4/0.7 0.5/0.8 0.6/1.0 3.0 4.0 5.0 0.4 0.4 0.6 134J 2 SDZ-2
10 - 1000 25/20 30/17 25/17 0.5/0.8 0.6/1.0 1.0/1.5 2.0 4.0 7.0 0.4 0.5 0.7 159 2 SDL-3
10 - 1000 25/20 30/17 25/17 0.5/0.8 0.6/1.0 1.0/1.5 2.0 4.0 7.0 0.4 0.5 0.7 134J 2 SDZ-3
20 -2000 20/15 20/15 25/15 0.6/0.8 0.7/1.0 0.8/1.5 2.0 3.0 5.0 0.2 0.3 0.5 159 2 SDL-6
500 -1500 20/15 20/15 18/13 0.6/0.8 0.7/0.8 1.0/1.4 3.0 4.0 7.0 0.3 0.4 0.7 159 2 SDL-4
700 - 900 -/- -/- 23/20 -/- -/- 0.5/0.8 -/- -/- 2.0 -/- -/- 0.5 134J 2 SDZ-125
1200 -1600 -/- -/- 25/18 -/- -/- 1.0/1.5 -/- -/- 3.0 -/- -/- 0.3 159 2 SDL-5
1700 -2500 -/- -/- 20/16 -/- -/- 0.8/1.3 -/- -/- 10 -/- -/- 0.9 159 2 SDL-7
LEADED SURFACE-MOUNT
MODEL
PHASE UNBALANCE
(Degrees)
LB MB UB
MAX MAX MAX
INSERTION LOSS (dB)
LB MB UB
TYP/MAX TYP/MAX TYP/MAX
FREQUENCY
RANGE
(MHz)
ISOLATION (dB)
LB MB UB
TYP/MIN TYP/MIN TYP/MIN
PIN-OUT
(See
Below)
AMPLITUDE UNBALANCE
(dB)
LB MB UB
MAX MAX MAX
PACKAGE
159134J
*GROUND = Ground externally
#1 2 4,6 1,3,5
#2 6 3,4 1,2,5
#3 1 2,3 All other
INPUT OUTPUT *GROUND
PIN-OUT TABLE
Notes:
75 Ohm Model
Power Rating(All Models) = 1 watt, max
LB = 500-700 MHz, MB = 750-1000 MHz, UB = 1000-1500 Mhz
(UB) - Denotes full bandwidth specification
* Expanded frequency range available
§ Expanded frequency range available
** 50 Ohms, 5 Watts with mismatch of 1.2:1 or less
¥ 50 Ohms, 10 Watts with mismatch of 1.2:1 or less
For pin location and package outline drawings, see back pages.
LB = LF to 10 LF
MB = 10 LF to HF/2
UB = HF/2 to HF
MODEL
PHASE UNBALANCE
(Degrees)
Full Band
TYP/MAX
INSERTION LOSS
(dB)
Full Band
TYP/MAX
FREQUENCY
RANGE
(MHz)
ISOLATION
(dB)
Full Band
TYP/MIN
PIN-OUT
(See Below)
AMPLITUDE UNBALANCE
(dB)
Full band
TYP/MAX
PACKAGE
650 - 1200 22/12 0.2/0.3 1.0/2.0 ±0.15/0.20 1.3/1.5:1 234 3 S2D6512**
800 - 1200 25/20 0.2/0.4 1.0/2.0 ±0.2/0.4 1.3/1.4:1 234 3 S2D8120¥§
1400 - 2600 20/12 0.3/0.4 1.0/2.0 ±0.20/0.25 1.3/1.5:1 245 3 S2D1426**
1800 - 2200 25/20 0.2/0.4 1.0/2.0 ±0.2/0.4 1.3/1.4:1 234 3 S2D1822§
2000 - 2500 25/18 0.3/0.4 1.0/2.0 ±0.2/0.4 1.3/1.4:1 234 3 S2D2025¥
SYNSTRIP
®
SURFACE MOUNT
VSWR
TYP/MAX
234
245
New!
