Toggle Switch Selection Guide
Ordering Table – Standard Toggle Switches
MINIATURE SWITCHES
Following the table from left to right, the designer is able to specify the options wanted. The options are described and illustrated. To determine a part
number select the options desired and fill in the boxes in the selection guides illustrated below.
Toggle
Switch
Series
Poles
+
Lever
Finish
+
Circuit
+
Lever
Options
+
Bushing
Options
+ +
Contact
Material
Other
++
Term inal
Type
Keyway
A1 Pole 1 ON OFF ON 21
2 Pole 2 ON NONE ON 23
3 Pole 3 ON NONE ON* 26
4 Pole 4 ON* OFF ON* 27
ON OFF ON* 31
ON ON ON 32
ON ON ON* 33
NONE ON ON* 34
ON* ON ON* 35
NONE ON ON 53
.350 Threaded (Std.) Y
.370 Threaded High Torque Y1
.370 Threaded High Torque w/ Flat Y4
.437 Threaded Y5
.350 Smooth with Keyway Y91
.350 Smooth Y9
.280 Threaded (Std.) D
.280 Smooth with keyway D91
.280 Smooth D9
.280 Smooth with Flat D8
.350 Flatted with Shoulder (Std.) H
.350 Keyway with Shoulder H3
.315 Threaded High Torque H31
8mm Threaded High Torque H4
Splashproof lever & Bushing Seal CW
Splashproof lever Seal Only CX
15/32” Bushing Options for Large Bats
15/32 Dia. (Std.) T
Splashproof Lever & Panel Seal TW
15/32 Splashproof Lever Seal Only TX
For Locking Lever Only K
Solder Lugs (Std.) Z
Quick Connect Z3
Right Angle PC (Std.) A
Right Angle PC / Snap-in A3
Right Angle PC .156 A2
Right Angle PC .200 A7
Vertical PC .100 Spacing AV
Vertical PC .150 Spacing (Std.) AV2
Vertical PC .150 Snap-in AV3
Right Angle extended PC AW
Right Angle extended PC AW1
Right Angle extended PC AW3
Right Angle extended PC AW4
Printed Circuit Terminals (Std.) C
Right Angle Same Throw R
Right Angle Opposite Throw R2
.555 PC Support Bracket V20
.555 PC Snap-In Bracket HD V21
.460 PC Support Bracket (Std.) V30
.460 PC Snap-In Bracket V31
.630 PC Support Bracket V40
.630 PC Snap-In Bracket V41
.460 PC Support Bracket V60
.460 PC Snap-In Bracket HD V61
.630 PC Support Bracket V70
.630 PC Snap-In Bracket HD V71
.953 PC Support Bracket V80
.953 PC Snap-In Bracket HD V81
1.150 PC Support Bracket V90
1.150 PC Snap-In Bracket V91
.750 Wire Wrap W
.964 Wire Wrap W1
.425 Wire Wrap W3
1.062 Wire Wrap W4
Gold/Nickel/Brass B
Gold/Nickel/Silver G
Coin Silver Q
Optional Platings
Same as B, G, Q, respectively
Terminals tin-lead alloy K
Terminals tin-lead alloy L
Terminals tin-lead alloy M
K,L,M not available with Z&Z3
Epoxy Sealed Terminals Std.
Anti-Rotation P
Series No. Code Code Type Code Finish Code Type Code Type Code Type Code Type Code
Poles Circuits Lever Options Finishes Bushing Options Terminal/Mounting Options Contact Material Other Options
* Momentary Contact
Pos. “C”
.410 Bat (Std.) S Bright Chrome 1
.200 Bat (Std.) M Satin Chrome 2
Black 3
Flatted Bats
.840 Flat P1
.450 (Std.) P3
.250 Flat P4
Longer Bats
.840 Bat L0
.640 Bat L1
.550 Bat L2
Plastic Bats L3 and L4 Colors
.840 Plastic L3 Black Nylon 4
.571 Plastic L4 Red Nylon 5
White Nylon 6
Large Bats
15/32” Bushing
.468 Large T1
.687 Large T
.610 Flatted T2
Lever Locking
Actuators
Std. taper threaded K1
Dome threaded K2
Dome unthreaded K9
Taper threaded K12
Taper unthreaded K19
