200-0101

Part # 200-0101
Description
Category RESISTOR
Availability In Stock
Qty 5000
Qty Price
1 - 475 $0.31561
476 - 1,194 $0.25106
1,195 - 2,323 $0.23671
2,324 - 3,523 $0.21997
3,524 + $0.19606
Manufacturer Available Qty
SEI ELECTRONICS
  • Shipping Freelance Stock: 5000
    Ships Immediately

Related Items

200-0108-RR
SEI ELECTRONICS
RESISTOR
200-0108-RR
$0.26090
200-037-7926
COMPONENTS CORP
RELAY
200-037-7926

200-0576-01
Military Spec
ASSEMBLY
200-0576-01

0-050825-0001
Dale
RESISTOR
0-050825-0001

007-11634-4
L3
RESISTOR
007-11634-4

0181A0101-1
MILWAUKEE
RESISTOR
0181A0101-1



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

20
High Temperature Box Header
Series 8383
00
Connector Code
Prefix
00 = Standard
Connector
Assembly
8383
Series Number
050
Number of
Contacts
010 = 10 position
014 = 14 position
016 = 16 position
020 = 20 position
026 = 26 position
034 = 34 position
040 = 40 position
050 = 50 position
060 = 60 position
064 = 64 position
000
Contact Variation
000 = Solder PC
Straight
(1.60mm
PCB) Length
2.90mm
001 = Solder PC
Right Angle
(2.40mm
PCB) Length
3.70mm
002 = Solder PC
Right Angle
(1.6mm PCB)
Length
2.90mm
003 = Solder
PC Straight
(2.40mm
PCB) Length
3.70mm
009 = Press Fit
contact for
2.4/3.2mm
PCB or
contact length
4.5mm
0
Clip Variation
0 = No Clip
1
Plating Variation
1 = 30µ" Gold
over Nickel
4 = 10µ" Gold
over Nickel
0
Polarization
0 = No Polarizing
ORDERING CODE
Series 8383 box headers are designed to be suitable
for applications using either infra red or vapor phase
equipment. These connectors are designed to mate
with Series 8290 IDC sockets as well as other industry
compatible connectors.
Termination Type:
Plated Through Hole
Termination Pitch:
0.100" (2.54mm)
Material:
Housing - UL94VO rated high thermal
resistant nylon
Contact - Brass
Contact Plating:
Gold over nickel
Contact Resistance:
Initially 10 milliohms maximum
Current Rating:
1 ampere at 70ºC maximum ambient
Insulation Resistance:
>1000 megohms
Voltage Rating:
350V DC or AC peak
Heat Deflection Temperature:
285ºC
TECHNICAL SPECIFICATION
21
High Temperature Box Header
Series 8383
No. of Contacts
ABC
10 17.90 (0.705) 4 10.16 (0.40)
14 22.98 (0.905) 6 15.24 (0.60)
16 25.52 (1.00) 7 17.78 (0.70)
20 30.60 (1.20) 9 22.86 (0.90)
26 38.22 (1.50) 12 30.48 (1.20)
34 48.38 (1.90) 16 40.64 (1.60)
40 56.00 (2.20) 19 48.26 (1.90)
50 68.70 (2.70) 24 60.96 (2.40)
60 81.40 (3.20) 29 73.66 (2.90)
64 86.48 (3.20) 31 78.74 (3.10)
DIMENSIONS: millimeters (inches)
