4. With diode type (For DC)

1) Plug-in type

Standard packing: Carton: 20 pcs.; Case: 200 pcs.

2) Plug-in type (with LED indication)

Standard packing: Carton: 20 pcs.; Case: 200 pcs.

5. With CR circuit type

1) Plug-in type

Standard packing: Carton: 20 pcs.; Case: 200 pcs.

2) Plug-in type (with LED indication)

Standard packing: Carton: 20 pcs.; Case: 200 pcs.

* For sockets and terminal sockets, see page 87.

RATING

1. Standard type

1) Coil data

(1) AC coils (50/60Hz)

Notes: 1. The relay operates in a range of 80% to 110% V of the voltage rating, but ideally, in consideration of temporary voltage ﬂuctuations, it should be operated at the

rated voltage. In particular, for AC operation, if the applied voltage drops to 80% V or more below the rated voltage, humming will occur and a large current will ﬂow

leading possibly to coil burnout.

2. The maximum applied voltage is the maximum voltage ﬂuctuation value for the coil power supply. This value is not a permissible value for continuous operation.

(This value differs depending on the ambient temperature. Please contact us for details.)

Nominal coil voltage

1 Form C 2 Form C 3 Form C 4 Form C 4 Form C (twin)

Part No. Part No. Part No. Part No. Part No.

6V DC HC1-DC6V-D-F HC2-DC6V-D-F HC3-DC6V-D-F HC4-DC6V-D HC4D-DC6V-D

12V DC HC1-DC12V-D-F HC2-DC12V-D-F HC3-DC12V-D-F HC4-DC12V-D HC4D-DC12V-D

24V DC HC1-DC24V-D-F HC2-DC24V-D-F HC3-DC24V-D-F HC4-DC24V-D HC4D-DC24V-D

48V DC HC1-DC48V-D-F HC2-DC48V-D-F HC3-DC48V-D-F HC4-DC48V-D HC4D-DC48V-D

100/110V DC HC1-DC100V-D-F HC2-DC100V-D-F HC3-DC100V-D-F HC4-DC100V-D HC4D-DC100V-D

Nominal coil voltage

1 Form C 2 Form C 3 Form C 4 Form C 4 Form C (twin)

Part No. Part No. Part No. Part No. Part No.

6V DC HC1-L-DC6V-D-F HC2-L-DC6V-D-F HC3-L-DC6V-D-F HC4-L-DC6V-D HC4D-L-DC6V-D

12V DC HC1-L-DC12V-D-F HC2-L-DC12V-D-F HC3-L-DC12V-D-F HC4-L-DC12V-D HC4D-L-DC12V-D

24V DC HC1-L-DC24V-D-F HC2-L-DC24V-D-F HC3-L-DC24V-D-F HC4-L-DC24V-D HC4D-L-DC24V-D

48V DC HC1-L-DC48V-D-F HC2-L-DC48V-D-F HC3-L-DC48V-D-F HC4-L-DC48V-D HC4D-L-DC48V-D

100/110V DC HC1-L-DC100V-D-F HC2-L-DC100V-D-F HC3-L-DC100V-D-F HC4-L-DC100V-D HC4D-L-DC100V-D

Nominal coil voltage

1 Form C 2 Form C 3 Form C 4 Form C 4 Form C (twin)

Part No. Part No. Part No. Part No. Part No.

100/110V AC HC1-AC100V-R-F HC2-AC100V-R-F HC3-AC100V-R-F HC4-AC100V-R HC4D-AC100V-R

110/120V AC HC1-AC120V-R-F HC2-AC120V-R-F HC3-AC120V-R-F HC4-AC120V-R HC4D-AC120V-R

200/220V AC HC1-AC200V-R-F HC2-AC200V-R-F HC3-AC200V-R-F HC4-AC200V-R HC4D-AC200V-R

220/240V AC HC1-AC240V-R-F HC2-AC240V-R-F HC3-AC240V-R-F HC4-AC240V-R HC4D-AC240V-R

Nominal coil voltage

1 Form C 2 Form C 3 Form C 4 Form C 4 Form C (twin)

Part No. Part No. Part No. Part No. Part No.

100/110V AC HC1-L-AC100V-R-F HC2-L-AC100V-R-F HC3-L-AC100V-R-F HC4-L-AC100V-R HC4D-L-AC100V-R

110/120V AC HC1-L-AC120V-R-F HC2-L-AC120V-R-F HC3-L-AC120V-R-F HC4-L-AC120V-R HC4D-L-AC120V-R

200/220V AC HC1-L-AC200V-R-F HC2-L-AC200V-R-F HC3-L-AC200V-R-F HC4-L-AC200V-R HC4D-L-AC200V-R

220/240V AC HC1-L-AC240V-R-F HC2-L-AC240V-R-F HC3-L-AC240V-R-F HC4-L-AC240V-R HC4D-L-AC240V-R

Type

Nominal coil

voltage

Pick-up voltage

(at 20°C 68°F)

Drop-out

voltage

(at 20°C 68°F)

Nominal coil current

[±20%] (at 20°C 68°F)

Coil inductance

Nominal operating

power

Max. applied

voltage

(at 70°C 158°F)

50Hz 60Hz

N.C.

condition

N.O.

condition

50Hz 60Hz

Standard

6V AC

80%V or less of

nominal voltage

(Initial)

30%V or more

of nominal

voltage

(Initial)

224mA 200mA 0.078H 0.074H

1.3VA 1.2VA

110%V of

nominal voltage

12V AC 111mA 100mA 0.312H 0.295H

24V AC 56mA 50mA 1.243H 1.181H

48V AC 28mA 25mA 4.974H 4.145H

100/110V AC 13.4/14.7mA 12/13.2mA 23.75H 20.63H

110/120V AC 12.2/13.5mA 10.9/11.9mA 27.19H 25.57H

200/220V AC 6.7/7.4mA 6/6.6mA 85.98H 81.76H

ASCTB4E 201201-T

Panasonic Corporation Automation Controls Business Unit industrial.panasonic.com/ac/e

(2) DC coils

Notes: 1. The coil resistance for DC operation is the value measured when the coil temperature is 20°C 68°F. Compensate ±0.4% for every ±1°C change in temperature.

2. The relay operates in a range of 80% to 110% V of the voltage rating, but ideally, in consideration of temporary voltage ﬂuctuations, it should be operated at the

rated voltage.

3. For use with 200 V DC, connect a 10 KΩ (5W) resistor, in series, to the 100 V DC relay.

4. The maximum applied voltage is the maximum voltage ﬂuctuation value for the coil power supply. This value is not a permissible value for continuous operation.

(This value differs depending on the ambient temperature. Please contact us for details.)

2) Speciﬁcations

Notes: *1. This value can change due to the switching frequency, environmental conditions and desired reliability level, therefore it is recommended to check this with the

actual load.

*2. For the AC coil types, the operate/release time will differ depending on the phase.

*3. The upper limit of the ambient temperature is the maximum temperature that can satisfy the coil temperature rise value. Refer to Usage, transport and storage

conditions in NOTES.

Type

Nominal coil

voltage

Pick-up voltage

(at 20°C 68°F)

Drop-out voltage

(at 20°C 68°F)

Nominal coil current

[±10%]

(at 20°C 68°F)

Coil resistance

[±10%]

(at 20°C 68°F)

Nominal operating

power

Max. applied voltage

(at 70°C 158°F)

Standard

6V DC

80%V or less of

nominal voltage

(Initial)

10%V or more of

nominal voltage

(Initial)

150mA 40Ω

0.9W

110%V of

nominal voltage

12V DC 75mA 160Ω

24V DC 37mA 650Ω

48V DC 18.5mA 2,600Ω

100/110V DC 10/11mA 10,000Ω 1.0W

Characteristics Item Speciﬁcations

Contact

Arrangement 1 Form C 2 Form C 3 Form C 4 Form C 4 Form C (twin)

Contact resistance (Initial) Max. 30 mΩ (By voltage drop 6 V DC 1A)

Contact material Ag alloy (cd free) + Au ﬂash AgNi type + Au clad

Rating

Nominal switching capacity

(resistive load)

10A 250V AC 7A 250V AC 7A 250V AC 5A 250V AC 3A 250V AC

Max. switching power

(resistive load)

2,500VA 1,750VA 1,750VA 1,250VA 750VA

Max. switching voltage 250VAC

Max. switching current 10A 7A 7A 5A 3A

Nominal operating power AC (50Hz): 1.3VA, AC (60Hz): 1.2VA, DC: 0.9 to 1.1W

Min. switching capacity

(Reference value)*

1mA 1V DC 100µA 1V DC

Electrical

characteristics

Insulation resistance (Initial) Min. 1,000MΩ (at 500V DC) Measurement at same location as “Breakdown voltage” section.

Breakdown

voltage

(Initial)

Between open

contacts

700 Vrms for 1min. (Detection current: 10mA.)

Between contact

sets

700 Vrms for 1min. (Detection current: 10mA.)

Between contact

and coil

2,000 Vrms for 1min. (Detection current: 10mA.)

Temperature rise (coil)

(at 70°C 158°F)

Max. 80°C 176°F (By resistive method, nominal coil voltage)

Operate time (at 20°C 68°F)*

Max. 20ms (Nominal coil voltage applied to the coil, excluding contact bounce time.)

Release time (at 20°C 68°F)*

Max. 20ms (Nominal coil voltage applied to the coil, excluding contact bounce time.) (without diode)

Mechanical

characteristics

Shock

resistance

Functional Min. 196 m/s

(Half-wave pulse of sine wave: 11 ms; detection time: 10µs.)

Destructive Min. 980 m/s

(Half-wave pulse of sine wave: 6 ms.)

Vibration

resistance

Functional 10 to 55 Hz at double amplitude of 1 mm (Detection time: 10µs.)

Destructive 10 to 55 Hz at double amplitude of 2 mm

Expected life

Mechanical Min. 5×10

: AC coil type (at 180 times/min.); Min. 10

: DC coil type (at 180 times/min.)

Electrical

Min. 2×10

resistive load

(at 20 times/min.)

Min. 2×10

resistive load

(at 20 times/min.)

Min. 10

resistive load

(at 20 times/min.)

Min. 2×10

resistive load

(at 20 times/min.)

Min. 2×10

resistive load

(at 20 times/min.)

Conditions

Conditions for operation,

transport and storage*

Ambient temperature: –50°C to +70°C –58°F to +158°F (without LED); –50°C to +60°C –58°F to +140°F (with LED)

Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)

Max. Operating speed 20 times/min. (at max. rating)

Unit weight Approx. 30g 1.06 oz

ASCTB4E 201201-T

Panasonic Corporation Automation Controls Business Unit industrial.panasonic.com/ac/e

3) Switching capacity and expected life

(1) Electrical (at 20 times/min.)

(2) Mechanical (at 180 times/min.)

AC coil type: Min. 5×10

; DC coil type: Min. 10

2. Amber sealed type

1) Coil data

Same coil data as HC relay standard type. Please refer to standard type information.

2) Speciﬁcations

Notes: Other speciﬁcations are same as standard types.

*1. This value can change due to the switching frequency, environmental conditions and desired reliability level, therefore it is recommended to check this with the

actual load.

*2. The upper limit of the ambient temperature is the maximum temperature that can satisfy the coil temperature rise value. Refer to Usage, transport and storage

conditions in NOTES.

3) Switching capacity and expected life

(1) Electrical (at 20 times/min.)

(2) Mechanical (at 180 times/min.)

AC coil type: Min. 5×10

; DC coil type: Min. 10

Load

AC DC

Expected lifeResistive (cos ϕ = 1) Inductive (cos ϕ 0.4) Resistive Inductive

Voltage 125V AC 250V AC 125V AC 250V AC 30V DC 30V DC

1 Form C

10A 10A 5A 3A — — Min. 2×10

7A 7A 3A 2.5A 3A 1A Min. 5×10

5A 5A 2A 1.5A — — Min. 10

2 Form C

7A 7A 3.5A 2A — — Min. 2×10

5A 5A 2.5A 1.5A 3A 0.6A Min. 5×10

3A 3A 1.5A 1A — — Min. 10

3 Form C

7A 7A ————Min. 10

——3.5A 2A — — Min. 2×10

5A 5A — — 3A 0.4A Min. 5×10

4 Form C

5A 5A 2A 1A — — Min. 2×10

3A 3A 1A 0.8A 3A 0.4A Min. 5×10

2A 2A 0.5A 0.4A — — Min. 10

4 Form C (twin) 3A 3A 1A 0.8A 3A — Min. 2×10

Characteristics Item

Speciﬁcations

1 Form C 2 Form C 4 Form C 4 Form C (twin)

Contact Arrangement 1 Form C 2 Form C 4 Form C 4 Form C

Rating

Nominal switching capacity (resistive load) 5A 250V AC 3A 250V AC 2A 250V AC 1A 250V AC

Max. switching power (resistive load) 1,250VA 700VA 500VA 250VA

Max. switching voltage 250VAC 250VAC 250VAC 250VAC

Max. switching current 5A 3A 2A 1A

Min. switching capacity (Reference value)*

1mA 100mV DC 100µA 100mV DC

Electrical characteristics Temperature rise (coil) (at 60°C 140°F) Max. 90°C 194°F (By resistive method, nominal voltage)

Expected life Electrical Min. 2×10

resistive load (at 20 times/min.)

Conditions

Conditions for operation, transport and

storage*

Ambient temperature: –40°C to +60°C –40°F to +140°F;

Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature)

Ambient air pressure 760mmHg±20% (1,013mb±20%)

Load

AC DC

Expected lifeResistive (cos ϕ = 1) Inductive (cos ϕ 0.4) Resistive Inductive

Voltage 125V AC 250V AC 125V AC 250V AC 30V DC 30V DC

HC1E 5A 5A — — 3A 1A Min. 2×10

HC2E 3A 3A — — 2A 0.7A Min. 2×10

HC4E 2A 2A — — 2A 0.6A Min. 2×10

HC4ED (4 Form C twin) 1A 1A ————Min. 2×10
