AZ8

2/27/01W

MINIATURE

PC BOARD RELAY

FEATURES

• Subminiature size

• High sensitivity, 110 mW pickup

• Coils to 48 VDC

• Hermetically sealed version available

• Epoxy sealed for automatic wave soldering

• Contacts rated at 3, 6 or 10 Amps

• Withstands 6 kV IEEE Lightning Surge (special order)

• Class B insulation (130°C) standard

• Class F insulation (155°C) version available

• UL, CUR file E44211

• VDE approved versions available

CONTACTS

Arrangement SPDT (1 Form C)

SPST (1 Form A) 10 A version only

Ratings Resistive load:

Light Duty Max. switched power: 100 W or 600 VA

Max. switched current: 3 A

Max. switched voltage: 150* VDC or 300 VAC

UL Rating: See chart on Page 3

Medium Duty Max. switched power: 180 W or 1800 VA

Max. switched current: 6 A

Max. switched voltage: 150* VDC or 300 VAC

UL Rating: See chart on Page 3

Heavy Duty Max. switched power: 300 W or 2400 VA

Max. switched current: 10 A

Max. switched voltage: 150* VDC or 300 VAC

UL Rating: See chart on Page 3

Note: If switching voltage is greater than 30 VDC, special

precautions must be taken. Please contact the factory.

Material Light duty: Silver

Medium duty: Silver nickel

Heavy duty: Silver cadmium oxide

Resistance < 100 milliohms initially

GENERAL DATA

Life Expectancy Minimum operations

Mechanical 100 million operations

Electrical Light Duty 3 x 10

at 3 A, 120 VAC

Medium Duty 1.8 x 10

at 6 A, 120 VAC

Heavy Duty 1 x 10

at 10 A, 120 VAC

Operate Time (typical) 5 ms at nominal coil voltage

Release Time (typical) 2 ms at nominal coil voltage

(with no coil suppression)

Dielectric Strength 750 Vrms contact to contact

(at sea level for 1 min.) 3000 Vrms contact to coil

Insulation 1000 megohms min. at 20°C, 500 VDC,

Resistance 50% RH

Dropout Greater than 5% of nominal coil voltage

Ambient Temperature At nominal coil voltage

Operating -55°C (-67°F) to 90°C (194°F) Class B

-55°C (-67°F) to 115°C (239°F) Class F

Storage -55°C (-67°F) to 130°C (266°F) Class B

-55°C (-67°F) to 155°C (311°F) Class F

Vibration 0.062" DA at 10–55 Hz, 10 g at 55–110 Hz

Shock 10 g

Enclosure P.E.T. polyester

Terminals Tinned copper alloy, P.C.

Max. Solder Temp. 270°C (518°F)

Max. Solder Time 5 seconds

Max. Solvent Temp. 80°C (176°F)

Max. Immersion Time 30 seconds

Weight 8 grams

COIL

Power

At Pickup Voltage Standard coil: 210 mW

(typical) Sensitive coil: 140 mW

Heavy duty: 228 mW

(110 mW available)

Max. Continuous Class B: 2.0 W 20°C (68°F) ambient

Dissipation 1.6 W 40°C (104°F) ambient

Class F: 2.5 W 20°C (68°F) ambient

2.1 W 40°C (104°F) ambient

Temperature Rise At nominal coil voltage

Standard coil: 38°C (68°F)

Sensitive coil: 28°C (50°F)

Temperature Max. 130°C (266°F) Class B

Max. 155°C (311°F) Class F

NOTES

1. All values at 20°C (68°F).

2. Relay may pull in with less than “Must Operate” value.

3. Other coil resistances and sensitivities available upon request.

4. Unsealed relays should not be dip cleaned.

5. Specifications subject to change without notice.

COIL SPECIFICATIONS ORDER NUMBER

STANDARD RELAYS: 1 Form C (SPDT) – VDE MEDIUM DUTY

Nominal Max. VDC Resistance Must Operate Unsealed Epoxy Sealed

Coil VDC Continuous ± 10% VDC 6 Amp 5 Amp

5 10.6 56 3.25 AZ8–1CH–5DA AZ8–1CH–5DEA

6 12.6 80 3.90 AZ8–1CH–6DA AZ8–1CH–6DEA

9 19.0 180 5.85 AZ8–1CH–9DA AZ8–1CH–9DEA

12 25.0 320 7.80 AZ8–1CH–12DA AZ8–1CH–12DEA

24 50.0 1,280 15.60 AZ8–1CH–24DA AZ8–1CH–24DEA

48 87.0 3,800 31.20 AZ8–1CH–48DA AZ8–1CH–48DEA

SENSITIVE RELAYS: 1 Form C (SPDT) – VDE MEDIUM DUTY

Nominal Max. VDC Resistance Must Operate Unsealed Epoxy Sealed

Coil VDC Continuous ± 10% VDC 6 Amp 5 Amp

5 12.6 80 3.25 AZ8–1CH–5DSA AZ8–1CH–5DSEA

6 14.8 110 3.90 AZ8–1CH–6DSA AZ8–1CH–6DSEA

9 22.4 250 5.85 AZ8–1CH–9DSA AZ8–1CH–9DSEA

12 30.0 440 7.80 AZ8–1CH–12DSA AZ8–1CH–12DSEA

24 60.0 1,780 15.60 AZ8–1CH–24DSA AZ8–1CH–24DSEA

48 120.0 7,120 31.20 AZ8–1CH–48DSA AZ8–1CH–48DSEA

AZ8

2/27/01W

RELAY ORDERING DATA

COIL SPECIFICATIONS ORDER NUMBER*

STANDARD RELAYS: 1 Form C (SPDT) LIGHT DUTY (3 Amp contact) MEDIUM DUTY (6 Amp contact)

Nominal Max. VDC Resistance Must Operate

Unsealed Epoxy Sealed Unsealed Epoxy Sealed

Coil VDC Continuous ± 10% VDC

5 10.6 56 3.25 AZ8–1C–5D AZ8–1C–5DE AZ8–1CH–5D AZ8–1CH–5DE

6 12.6 80 3.90 AZ8–1C–6D AZ8–1C–6DE AZ8–1CH–6D AZ8–1CH–6DE

9 19.0 180 5.85 AZ8–1C–9D AZ8–1C–9DE AZ8–1CH–9D AZ8–1CH–9DE

12 25.0 320 7.80 AZ8–1C–12D AZ8–1C–12DE AZ8–1CH–12D AZ8–1CH–12DE

24 50.0 1,280 15.60 AZ8–1C–24D AZ8–1C–24DE AZ8–1CH–24D AZ8–1CH–24DE

48 87.0 3,800 31.20 AZ8–1C–48D AZ8–1C–48DE AZ8–1CH–48D AZ8–1CH–48DE

SENSITIVE RELAYS: 1 Form C (SPDT) LIGHT DUTY (3 Amp contact) MEDIUM DUTY (6 Amp contact)

Nominal Max. VDC Resistance Must Operate

Unsealed Epoxy Sealed Unsealed Epoxy Sealed

Coil VDC Continuous ± 10% VDC

5 12.6 80 3.25 AZ8–1C–5DS AZ8–1C–5DSE AZ8–1CH–5DS AZ8–1CH–5DSE

6 14.8 110 3.90 AZ8–1C–6DS AZ8–1C–6DSE AZ8–1CH–6DS AZ8–1CH–6DSE

9 22.4 250 5.85 AZ8–1C–9DS AZ8–1C–9DSE AZ8–1CH–9DS AZ8–1CH–9DSE

12 30.0 440 7.80 AZ8–1C–12DS AZ8–1C–12DSE AZ8–1CH–12DS AZ8–1CH–12DSE

24 60.0 1,780 15.60 AZ8–1C–24DS AZ8–1C–24DSE AZ8–1CH–24DS AZ8–1CH–24DSE

48 120.0 7,120 31.20 AZ8–1C–48DS AZ8–1C–48DSE AZ8–1CH–48DS AZ8–1CH–48DSE

STANDARD RELAYS: 1 Form C (SPDT) HEAVY DUTY (10 Amp contact)

Nominal Max. VDC Resistance Must Operate

Unsealed Epoxy Sealed

Coil VDC Continuous ± 10% VDC

5 10.6 56 4.0 AZ8–1CT–5D AZ8–1CT–5DE

6 12.6 80 4.8 AZ8–1CT–6D AZ8–1CT–6DE

9 19.0 180 7.2 AZ8–1CT–9D AZ8–1CT–9DE

12 25.0 320 9.6 AZ8–1CT–12D AZ8–1CT–12DE

24 50.0 1,280 19.2 AZ8–1CT–24D AZ8–1CT–24DE

48 87.0 3,800 38.4 AZ8–1CT–48D AZ8–1CT–48DE

*To indicate Class F version, add suffix "F". Other coil resistances and sensitivities available. Please contact the factory.

Substitute “1AT” in place of “1CT” to indicate 1 Form A. For Hermetically sealed version, substitute “H” for “E”.

AZ8

2/27/01W

MECHANICAL DATA

WIRING DIAGRAM

PC BOARD LAYOUT

.840

(21.3)

.637

(16.18)

.071

(1.80)

.500

(12.69)

.200

(5.07)

.136

(3.45)

.017

(0.43)

.565

(14.35)

Viewed toward terminals Viewed toward terminals

Terminal No.

2, 5

3, 4

Dimensions

.010 - .015 X .035 - .042

.020 - .030 SQUARE

.015 - .023 X .025 - .030

1 FORM A

1 FORM C

.055 ± .005 DIA

(1.4 ± 0.1)

(5 HOLES)

.069

(1.75)

REF

.071

(1.80)

REF

0.1

(2.54)Ê

Coil Temperature Rise

Percent of Nominal Coil Voltage

20˚C Ambient

60% 80% 100% 120% 140% 160% 180% 210% 220%

Coil Temperature Rise ˚C

170

160

150

140

130

120

110

100

10A

Maximum Switching Capacity

100

200

300

400

500

600

700

800

900

1000

1.0

2.0

3.0

4.0

5.0

6.0

7.0

8.0

9.0

10.0

CURRENT

VOLTAGE

DC Resistive Load

AC Resistive

Load

ICT

ICH

Dimensions in inches with metric equivalents in parentheses. Tolerance: ± .010"

UL, CUR RATINGS

Light Duty 2 A at 28 VDC or 300 VAC

/8 HP at 120 VAC

/10 HP at 120/240 VAC (100,000 cyc)

1.2

/0.6 A at 120/240 VAC, Pilot Duty 100,000 cyc

3.0

/1.5

A at 120/240 VAC General Use 100,000 cyc

Medium Duty 6 A at 28 VDC or 300 VAC

/8 HP at 120/240 VAC (100,000 cyc)

1.5

/0.8

A at 120/240 VAC, Pilot Duty 100,000 cyc

3.8

/1.9 A at 120/240 VAC General Use 100,000 cyc

Heavy Duty SPST:

10 A at 24 VDC / 125 VAC Resistive

/4 HP at 120 / 125 VAC

2 HP at 250 VAC

7 A at 277 VAC Resistive

SPDT:

10 A at 250 VAC General Use

7 A at 277 VAC Resistive

6 A at 24 VDC Resistive

4 HP at 125 VAC

VDE RATINGS

Sealed 5 A at 250 VAC resistive, 10,000 cycles

Unsealed 6 A at 250 VAC resistive, 50,000 cycles
