MODEL NUMBERS
AC CONTROL A1210 A1225 A1240 A2410 A2425 A2450 A2475 A2490
DC CONTROL D1210 D1225 D1240 D2410 D2425 D2450 D2475 D2490
OUTPUT SPECIFICATIONS
➀
Operating Voltage (47-63 Hz) [Vrms] 24-140 24-140 24-140 24-280 24-280 24-280 24-280 24-280
Max. Load Current ➂ [Arms] 10 25 40 10 25 50 75 90
Min. Load Current, [mArms] 40 40 40 40 40 40 40 40
Transient Overvoltage [Vpk] 400 400 400 600 600 600 600 600
Max. Surge Current, (16.6ms) [Apk] 120 250 625 120 250 625 1000 1200
Max. On-State Voltage Drop @ Rated Current [Vpk] 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6
Thermal Resistance Junction to Case (R
θJC
) [˚C/W] 1.48 1.02 0.63 1.48 1.02 0.63 0.31 0.28
Maximum I
2
t for Fusing, (8.3 msec.) [A
2
sec] 60 260 1620 60 260 1620 4150 6000
Max. Off-State Leakage Current @ Rated Voltage [mArms] 8 8 8 1010101010
Min. Off-State dv/dt @ Max. Rated Voltage [V/µsec]➁ 500 500 500 500 500 500 500 500
Max. Turn-On Time ➃ 1/2 Cycle (DC Control), 10.0 msec (AC Control)
Max. Turn-Off Time 1/2 Cycle (DC Control), 40.0 msec(AC Control)
Power Factor (Min.) with Max. Load 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
INPUT SPECIFICATIONS ➀ DC CONTROL AC CONTROL AC CONTROL
(E SUFFIX)
Control Voltage Range 3-32 Vdc 90-280 Vrms (60Hz) 18-36 Vrms
Max. Reverse Voltage -32 Vdc --- ---
Max. Turn-On Voltage 3.0 Vdc 90 Vrms 18 Vrms
Min. Turn-Off Voltage 1.0 Vdc 10 Vrms 4.0 Vrms
Nominal Input Impedance 1500 Ohms 60K Ohms 9.0K Ohms
Typical Input Current 3.4mA @ 5 Vdc, 20mA @ 28Vdc 2mA @ 120 Vrms, 4mA @ 240 Vrms 3mA @ 24 Vrms
GENERAL NOTES
➀ All parameters at 25ºC unless otherwise specified.
➁ Off-State dv/dt test method per EIA/NARM standard RS-443, paragraph 13.11.1
➂ Heat sinking required, for derating curves see page 2.
➃ Turn-on time for random turn-on versions is 0.02 msec (DC Control Models).
• Zero Voltage and Random
Turn-On Switching
• Panel Mount
• 600V Blocking Capability
• Internal Snubber
• 110 & 125A Models
Available
FastFax Document No. 151
SERIES1.032698, PAGE 1 OF 3
Featuring state-of-the-art Surface
Mount Technology, these SPST-NO
relays deliver proven reliability in the
most demanding applications. Output
consists of an SCR AC switch and is
available in zero-cross, random turn-
on (phase controllable) and normally
closed (Form B) versions with either
AC or DC input (coil) control.
Manufactured in Crydom’s ISO 9002
Certified facility for optimum product
performance and reliability.
Series 1
10-90Amp • 120, 240 Vac • AC Output
