P2600SBRP

Part # P2600SBRP
Description SIDACTOR 220V 250A SURG DO-214AA
Category OSCILLATOR
Availability In Stock
Qty 1365
Qty Price
1 - 286 $0.33583
287 - 573 $0.26714
574 - 859 $0.25188
860 - 1,146 $0.23407
1,147 + $0.20862
Manufacturer Available Qty
TECCOR ELECTRONICS
  • Shipping Freelance Stock: 1365
    Ships Immediately



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

SIDACtor
®
Protection Thyristors
Revised: February 4, 2013
© 2013 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Baseband Protection (Voice-DS1)
SIDACtor
®
Series, DO-214
Electrical Characteristics
SIDACtor
®
Series - DO-214
SIDACtor
®
Series DO-214AA are designed to protect
baseband equipment such as modems, line cards, CPE and
DSL from damaging overvoltage transients.
The series provides a surface mount solution that enables
equipment to comply with global regulatory standards.
Description
AGENCY AGENCY FILE NUMBER
E133083
Agency Approvals
Features and Benefits
t Low voltage overshoot
t Low on-state voltage
t Does not degrade surge
capability after multiple
surge events within
limit.
t Fails short circuit when
surged in excess of
ratings
t Low capacitance
Part Number Marking
V
DRM
@l
DRM
=5μA
V
S
@100V/μs
I
H
I
S
I
T
V
T
@I
T
=2.2 Amps
Capacitance
@1MHz, 2V bias
V min V max mA min mA max A max V max pF min pF max
P0080SALRP
P-8A
6 25 50 800 2.2 4 25 150
P0220SALRP P22A 15 32 50 800 2.2 4 25 150
P0300SALRP P03A 25 40 50 800 2.2 4 15 140
P0640SALRP P06A 58 77 150 800 2.2 4 40 60
P0720SALRP P07A 65 88 150 800 2.2 4 35 60
P0900SALRP P09A 75 98 150 800 2.2 4 25 55
P1100SALRP P11A 90 130 150 800 2.2 4 30 50
P1300SALRP P13A 120 160 150 800 2.2 4 25 45
P1500SALRP P15A 140 180 150 800 2.2 4 25 40
P1800SALRP P18A 170 220 150 800 2.2 4 25 35
P2100SALRP P21A 180 240 150 800 2.2 4 20 35
P2300SALRP P23A 190 260 150 800 2.2 4 25 35
P2600SALRP P26A 220 300 150 800 2.2 4 20 35
P3100SALRP P31A 275 350 150 800 2.2 4 20 35
P3500SALRP P35A 320 400 150 800 2.2 4 20 35
P0080SBLRP P-8B 6 25 50 800 2.2 4 25 150
P0220SBLRP P22B 15 32 50 800 2.2 4 25 150
P0300SBLRP P03B 25 40 50 800 2.2 4 15 140
P0640SBLRP P06B 58 77 150 800 2.2 4 40 80
P0720SBLRP P07B 65 88 150 800 2.2 4 35 75
Applicable Global Standards
t TIA-968-A
t TIA-968-B
t ITU K.20/21 Enhanced
Level*
t ITU K.20/21 Basic Level
t GR 1089 Inter-building*
t GR 1089 Intra-building
t IEC 61000-4-5
t YD/T 1082
t YD/T 993
t YD/T 950
*A/B-rated parts require series resistance
Pinout Designation
Schematic Symbol
Not Applicable
Table continues on next page.
RoHS
SIDACtor
®
Protection Thyristors
Revised: February 4, 2013
© 2013 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Baseband Protection (Voice-DS1)
SIDACtor
®
Series, DO-214
Electrical Parameters (continued)
Part Number Marking
V
DRM
@l
DRM
=5μA
V
S
@100V/μs
I
H
I
S
I
T
V
T
@I
T
=2.2 Amps
Capacitance
@1MHz, 2V bias
V min V max mA min mA max A max V max pF min pF max
P0900SBLRP P09B 75 98 150 800 2.2 4 35 70
P1100SBLRP P11B 90 130 150 800 2.2 4 30 70
P1300SBLRP P13B 120 160 150 800 2.2 4 25 60
P1500SBLRP P15B 140 180 150 800 2.2 4 25 55
P1800SBLRP P18B 170 220 150 800 2.2 4 25 50
P2100SBLRP P21B 180 240 150 800 2.2 4 20 35
P2300SBLRP P23B 190 260 150 800 2.2 4 25 50
P2600SBLRP P26B 220 300 150 800 2.2 4 20 45
P3100SBLRP P31B 275 350 150 800 2.2 4 20 45
P3500SBLRP P35B 320 400 150 800 2.2 4 20 40
P0080SCLRP P-8C 6 25 50 800 2.2 4 45 260
P0220SCLRP P22C 15 32 50 800 2.2 4 30 240
P0300SCLRP P03C 25 40 50 800 2.2 4 25 250
P0640SCLRP P06C 58 77 150 800 2.2 4 55 155
P0720SCLRP P07C 65 88 150 800 2.2 4 50 150
P0900SCLRP P09C 75 98 150 800 2.2 4 45 140
P1100SCLRP P11C 90 130 150 800 2.2 4 45 115
P1300SCLRP P13C 120 160 150 800 2.2 4 40 105
P1500SCLRP P15C 140 180 150 800 2.2 4 35 95
P1800SCLRP P18C 170 220 150 800 2.2 4 35 90
P2100SCLRP P21C 180 240 150 800 2.2 4 30 90
P2300SCLRP P23C 190 260 150 800 2.2 4 30 80
P2600SCLRP P26C 220 300 150 800 2.2 4 30 80
P3100SCLRP P31C 275 350 150 800 2.2 4 30 70
P3500SCLRP P35C 320 400 150 800 2.2 4 25 65
P4500SCLRP
P45C
400 530 150 800 2.2 4 25 65
Surge Ratings
Series
I
PP
I
TSM
50/60 Hz
di/dt
0.2x310
1
0.5x700
2
2x10
1
2x10
2
8x20
1
1.2x50
2
10x160
1
10x160
2
10x560
1
10x560
2
5x320
1
9x720
2
10x360
1
10x360
2
10x1000
1
10x1000
2
5x310
1
10x700
2
A min A min A min A min A min A min A min A min A min A min Amps/μs max
A2015015090507575457520 500
B 25 250 250 150 100 100 125 80 100 25 500
C 50 500 400 200 150 200 175 100 200
3
30 500
Notes:
- Absolute maximum ratings measured at T
A
= 25ºC (unless otherwise noted).
- Devices are bi-directional.
Notes:
1 Current waveform in μs
2 Voltage waveform in μs
3 For surge rating of P4500SCLRP 10x700μs min=150A & typical=180A
- Peak pulse current rating (I
PP
) is repetitive and guaranteed for the life of the product.
- I
PP
ratings applicable over temperature range of -40ºC to +85ºC
- The device must initially be in thermal equilibrium with -40°C < T
J
< +150°C
SIDACtor
®
Protection Thyristors
Revised: February 4, 2013
© 2013 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Baseband Protection (Voice-DS1)
SIDACtor
®
Series, DO-214
25°C
Case Temperature (T
C
) - ºC
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
-40 -20 0 20 40 60 80 100 120 140 160
Ratio of
I
H
I
H
(T
C
= 25ºC)
Normalized V
S
Change vs. Junction Temperature
Normalized DC Holding Current vs. Case Temperature
I
H
I
T
I
S
I
DRM
V
DRM
V
T
+V
-V
+I
-I
V
S
50
100
0
t
r
t
d
0
Peak
Value
Half Value
t – Time (μs)
I
PP
– Peak Pulse Current – %I
PP
t
r
= rise time to peak value
t
d
= decay time to half value
Waveform = t
r
x t
d
V-I Characteristics t
r
x t
d
Pulse Waveform
Package Symbol Parameter Value Unit
DO-214AA
T
J
Operating Junction Temperature Range -40 to +150 °C
T
S
Storage Temperature Range -65 to +150 °C
R
0JA
Thermal Resistance: Junction to Ambient 90 °C/W
Thermal Considerations
-8
-40 -20 0 20 40 60 80 100 120 140 160
-6
-4
0
2
4
6
8
10
12
14
Junction Temperature (T
J
) – °C
Percent of V
S
Change – %
25 °C
