Part Number C4OAC C4OACA C4OACR C4OACAR C4ODC C4ODCA
Nominal Voltage VDC 4-32 4-32 4-32 4-32 4-32 4-32
Minimum Voltage VDC 4.0 4.0 4.0 4.0 4.0 4.0
Maximum Voltage VDC 32 32 32 32 32 32
Drop-out Voltage 1.0 1.0 1.0 1.0 1.0 1.0
Maximum Current (2) (3) 22 22 22 22 16 16
Resistance Regulated Input Regulated Input Regulated Input Regulated Input Regulated Input Regulated Input
Nominal Line Voltage 120 VAC 240 VAC 120 VAC 240 VAC 5-48 VDC 5-150 VDC
Minimum Line Voltage 12 VAC 12 VAC 12 VAC 12 VAC 5.0 VDC 3 VDC
Maximum Line Voltage 140 VAC 280 VAC 140 VAC 280 VAC 60 VDC 250 VDC
Max Off-State Voltage (4) 600 Vpeak 600 Vpeak 600 Vpeak 600 Vpeak 60 VDC 250 VDC
Max Off-State Leakage (5) 0.1mArms 0.1mArms 0.1mArms 0.1mArms 10 uA 10 uA
Static Off-State dv/dt (6) 200 V/usec 200 V/usec 200 V/usec 200 V/usec n/a n/a
Maximum Rated On-State Current (7) 3.0 Arms 3.0 Arms 3.0 Arms 3.0 Arms 3.0 A 1.0 A
Minimum On-State Current 50 mArms 50 mArms 50 mArms 50 mArms 10 mA 10 mA
Max Surge Current (8) 100 Apeak 100 Apeak 100 Apeak 100 Apeak 5.0 Apeak 5.0 Apeak
On-State Voltage Drop or Resistance
(9)
1.6 V 1.6 V 1.6 V 1.6 V 1.6 V 1.6 V
HP Rating 1/4 1/4 1/4 1/4 n/a n/a
Maximum Turn-On Time [msec] (10) 8.33 8.33 0.1 0.1 0.05 0.05
Maximum Turn-Off Time [msec] 8.33 8.33 8.33 8.33 0.05 0.05
Input/Output Isolation Voltage (11) 4000 4000 4000 4000 4000 4000
Input/Output Capacitance 4 4 4 4 4 4
Operating Temperature Range -30 to 80°C -30 to 80°C -30 to 80°C -30 to 80°C -30 to 80°C -30 to 80°C
Storage Temperature Range -40 to 100°C -40 to 100°C -40 to 100°C -40 to 100°C -40 to 100°C -40 to 100°C
Line Frequency Range 47 to 63 Hz 47 to 63 Hz 47 to 63 Hz 47 to 63 Hz DC DC
Weight 1.1 oz. (31.2g) 1.1 oz. (31.2g) 1.1 oz. (31.2g) 1.1 oz. (31.2g) 1.1 oz. (31.2g) 1.1 oz. (31.2g)
