Vectron International 267 Lowell Road, Hudson NH 03051 Tel: 1-88-VECTRON-1 e-mail: vectron@vectron.com
VCC1 series
1.8, 2.5, 3.3, 5.0 volt CMOS Oscillator
The VCC1 Crystal Oscillator
Features
CMOS output
Output frequencies to 190 MHz
Low jitter, Fundamental or 3
rd
OT Crystal
Tristate output for board test and debug
-10/70 or 40/85 °C operating temperature
Gold over nickel contact pads
Hermetically sealed ceramic SMD package
Product is compliant to RoHS directive
and fully compatible with lead free assembly
Applications
SONET/SDH/DWDM
Ethernet, Gigabit Ethernet
Storage Area Network
Digital Video
Broadband Access
Microprocessors/DSP/FPGA
Description
Vectron’s VCC1 Crystal Oscillator (XO) is quartz
stabilized square wave generator with a CMOS
output, operating off either a 1.8, 2.5, 3.3 or a 5.0
volt supply.
The VCC1 is uses fundamental or 3
rd
overtone
crystals resulting in low jitter performance,
typically 0.5pS rms in the 12 kHz to 20MHz
band. Also a monolithic IC, which improves
reliability and reduces cost, is hermitically
sealed.
f
o
Output
Buffer /
Disable
Vectron International 267 Lowell Rd, Hudson NH 03051 Tel: 1-88-VECTRON-1 e-mail: vectron@vectron.com
Performance Characteristics
Table 1. Electrical Performance, 5V option
Parameter Symbol
Min Typical Maximum Units
Frequency f
O
0.012 125.000 MHz
Operating Supply Voltage
1
V
DD
4.5 5.5 V
Absolute Maximum Supply Voltage -0.7 7.0 V
Supply Current, Output Enabled
<1.5 MHz
1.5 to 20 MHz
20.01 to 50 MHz
50.00 to 85 MHz
85.01 to 125 MHz
I
DD
7
10
30
50
60
mA
Supply Current, Out disabled I
DD
30 uA
Output Logic Levels
Output Logic High
2
Output Logic Low
2
Output Logic High Drive
Output Logic Low Drive
V
OH
V
OL
I
OH
I
OL
0.9*V
DD
16
16
0.1*V
DD
V
V
mA
mA
Output Rise/Fall Time
2
< 1.00 MHz
1.0 to 20.00 MHz
20.01 to 50.00 MHz
50.01 to 125.00 MHz
t
R/
t
F
200
8
5
2
ns
Duty Cycle
3
(ordering option)
SYM 45/55 %
Operating temperature (ordering option) -10/70 or -40/85 °C
Stability
4
(ordering option) ±20, ±25, ±32, ±50, ±100 ppm
RMS Jitter, 12kHz to 20 MHz 0.5 1 ps
Period Jitter, RMS 2.5 ps
Output Enable/Disable
5
Output Enabled
Output Disabled
4.0
0.8
V
Internal Enable Pull-Up resistor
5
100 Kohm
Start-up time 10 ms
1. A 0.01uF and a 0.1uF capacitor should be located as close to the supply as possible (to ground) is recommended.
2. Figure 1 defines these parameters. Figure 2 illustrates the operating conditions under which these parameters are tested and
specified.
3. Symmetry is measured defined as Vs, On Time/Period.
4. Includes calibration tolerance, operating temperature, supply voltage variations, aging and shock and vibration (not under
operation).
5. Output will be enabled if enable/disable is left open.
Figure 1. Output Waveform Figure 2. Typical Output Test Conditions (25±5°C)
+
-
+
-
IC
V
C
3
2
.1µF
.01µF
15pF
4
1
I
DD
V
DD
V
OH
50%
V
OL
tFt
R
Period
On Time
VCC1 Data sheet
Vectron International 267 Lowell Rd, Hudson NH 03051 Tel: 1-88-VECTRON-1 e-mail: vectron@vectron.com
Table 2. Electrical Performance, 3.3V option
Parameter Symbol
Min Typical Maximum Units
Frequency f
O
0.012 189.000 MHz
Operating Supply Voltage
1
V
DD
2.97 3.3 3.63 V
Absolute Maximum Operating Voltage -0.5 5.0 V
Supply Current, Output Enabled
< 1.500 MHz
1.5 to 20 MHz
20.01 to 50 MHz
50.00 to 85 MHz
85.01 to 189 MHz
I
DD
5
7
20
30
50
mA
Supply Current, Output disabled I
DD
30 uA
Output Logic Levels
Output Logic High
2
Output Logic Low
2
Output Logic High Drive
Output Logic Low Drive
V
OH
V
OL
I
OH
I
OL
0.9*V
DD
8
8
0.1*V
DD
V
V
mA
mA
Output Rise/Fall Time
2
< 1.00 MHz
1.00 to 20.00 MHz
20.01 to 50.00 MHz
50.01 to 90.00 MHz
90.01 to 189.00 MHz
t
R/
t
F
200
6
4
3
2
ns
Duty Cycle
3
(ordering option) SYM 45/55 %
Operating temperature (ordering option) -10/70 or 40/85 °C
Stability
4
(ordering option) ±20, ±25, ±32, ±50, ±100 ppm
RMS Jitter, 12kHz to 20 MHz 0.5 1 ps
RMS Jitter 2.5 ps
Output Enable/Disable
5
Output Enabled
Output Disabled
2.0
0.5
V
Internal Enable Pull-Up resistor
5
100 Kohm
Start-up time 10 ms
1. A 0.01uF and a 0.1uF capacitor should be located as close to the supply as possible (to ground) is recommended.
2. Figure 3 defines these parameters. Figure 4 illustrates the operating conditions under which these parameters are tested and
specified. For Fo>90MHz, rise and fall time is measured 20 to 80%.
3. Symmetry is measured defined as Vs, On Time/Period.
4. Includes calibration tolerance, operating temperature, supply voltage variations, aging and shock and vibration (not under
operation).
5. Output will be enabled if enable/disable is left open.
Figure 3. Output Waveform Figure 4. Typical Output Test Conditions (25±5°C)
+
-
+
-
IC
V
C
3
2
.1µF
.01µF
15pF
4
1
I
DD
V
DD
V
OH
50%
V
OL
tFt
R
Period
On Time
