UCH INTERNATIONAL 160A-604G

Cross Number:

Item Description: INDICATOR GRN TRANSLUC SUBMIDGET

Qty Price
1 + $1.27130



Other Cross Reference

Manufacturer Date Code Qty Available Qty
UCH INTERNATIONAL
  • Freelance Stock: 20
    Ships Immediately





Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

engineered to light up your design
www.vcclite.com
1.800.522.5546
CML and Chicago Miniature Lamp are registered trademarks of Visual Communications Company, LLC.
Gemlite Relampable Indicator Lights
Description and Features
Specifications
All dimensions in inches.
7/32-64 THD.
.215
Ø.277
5/16-64 THD.
.380
.062
.563
5160-458 160A-604X
BODY LENS
Lens Part Number
160A-604R
160A-604Y
160A-604G
160A-604W
Description
Translucent Red
Translucent Yellow
Translucent Green
Translucent White
Mounting Hole:
Mounting Centers:
Maximum Panel Thickness:
Housing/Material:
Terminals:
Hex Nut:
Ø.313 with provision for a "Double D" anti-rotation hole if desired (.288 across flats)
.469
.218
Black Nickel Plated Brass
Turret type, center contact terminal is gold plated brass, shell contact terminal is silver plated brass
Nickel plated brass
Lockwasher:
Lens:
Nickel plated bronze
High temperature lexan
Lens Shank:
Electrical rating:
Nickel plated brass
up to 30 Volts, up to 1 Watt
The Chicago Miniature Lamp Gemlite Indicator Light is a versatile design capable of accepting all T-1 sub-midget flange
based lamps. These high quality indicators provide reliable service in a vast array of military and commercial applications
where a miniature relampable front panel indicator is required. The lamp is not included with this indicator light. Please
order the required lamp separately.
