Serial Communications Interface (SCI)
Technical Data MC68HC908AZ60A — Rev 2.0
262 Serial Communications Interface (SCI) MOTOROLA
processes the characters that follow. If they are not the same,
software can set the RWU bit and put the receiver back into the
standby state.
Idle input line condition — When the WAKE bit is clear, an idle
character on the RxD pin wakes the receiver from the standby
state by clearing the RWU bit. The idle character that wakes the
receiver does not set the receiver idle bit, IDLE, or the SCI receiver
full bit, SCRF. The idle line type bit, ILTY, determines whether the
receiver begins counting logic 1s as idle character bits after the
start bit or after the stop bit.
NOTE: With the WAKE bit clear, setting the RWU bit after the RxD pin has been
idle may cause the receiver to wake up immediately.
18.5.3.7 Receiver Interrupts
The following sources can generate CPU interrupt requests from the SCI
receiver:
SCI receiver full (SCRF) — The SCRF bit in SCS1 indicates that
the receive shift register has transferred a character to the SCDR.
SCRF can generate a receiver CPU interrupt request. Setting the
SCI receive interrupt enable bit, SCRIE, in SCC2 enables the
SCRF bit to generate receiver CPU interrupts.
Idle input (IDLE) — The IDLE bit in SCS1 indicates that 10 or 11
consecutive logic 1s shifted in from the RxD pin. The idle line
interrupt enable bit, ILIE, in SCC2 enables the IDLE bit to generate
CPU interrupt requests.
18.5.3.8 Error Interrupts
The following receiver error flags in SCS1 can generate CPU interrupt
requests:
Receiver overrun (OR) — The OR bit indicates that the receive
shift register shifted in a new character before the previous
character was read from the SCDR. The previous character
Serial Communications Interface (SCI)
Low-Power Modes
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA Serial Communications Interface (SCI) 263
remains in the SCDR, and the new character is lost. The overrun
interrupt enable bit, ORIE, in SCC3 enables OR to generate SCI
error CPU interrupt requests.
Noise flag (NF) — The NF bit is set when the SCI detects noise on
incoming data or break characters, including start, data, and stop
bits. The noise error interrupt enable bit, NEIE, in SCC3 enables
NF to generate SCI error CPU interrupt requests.
Framing error (FE) — The FE bit in SCS1 is set when a logic 0
occurs where the receiver expects a stop bit. The framing error
interrupt enable bit, FEIE, in SCC3 enables FE to generate SCI
error CPU interrupt requests.
Parity error (PE) — The PE bit in SCS1 is set when the SCI
detects a parity error in incoming data. The parity error interrupt
enable bit, PEIE, in SCC3 enables PE to generate SCI error CPU
interrupt requests.
18.6 Low-Power Modes
The WAIT and STOP instructions put the MCU in low power-
consumption standby modes.
18.6.1 Wait Mode
The SCI module remains active in wait mode. Any enabled CPU
interrupt request from the SCI module can bring the MCU out of wait
mode.
If SCI module functions are not required during wait mode, reduce power
consumption by disabling the module before executing the WAIT
instruction.
18.6.2 Stop Mode
The SCI module is inactive in stop mode. The STOP instruction does not
affect SCI register states. Any enabled CPU interrupt request from the
Serial Communications Interface (SCI)
Technical Data MC68HC908AZ60A — Rev 2.0
264 Serial Communications Interface (SCI) MOTOROLA
SCI module does not bring the MCU out of Stop mode. SCI module
operation resumes after the MCU exits stop mode.
Because the internal clock is inactive during stop mode, entering stop
mode during an SCI transmission or reception results in invalid data.
18.7 SCI During Break Module Interrupts
The BCFE bit in the break flag control register (BFCR) enables software
to clear status bits during the break state. (See Break Module (BRK) on
page 203).
To allow software to clear status bits during a break interrupt, write a
logic 1 to the BCFE bit. If a status bit is cleared during the break state, it
remains cleared when the MCU exits the break state.
To protect status bits during the break state, write a logic 0 to the BCFE
bit. With BCFE at logic 0 (its default state), software can read and write
I/O registers during the break state without affecting status bits. Some
status bits have a two-step read/write clearing procedure. If software
does the first step on such a bit before the break, the bit cannot change
during the break state as long as BCFE is at logic 0. After the break,
doing the second step clears the status bit.
18.8 I/O Signals
Port E shares two of its pins with the SCI module. The two SCI I/O pins
are:
PTE0/SCTxD — Transmit data
PTE1/SCRxD — Receive data
