15.4.3 COPCTL Write
Writing any value to the COP control register (COPCTL) (see COP
Control Register on page 227), clears the COP counter and clears
stages 12 through 4 of the COP prescaler. Reading the COP control
register returns the reset vector.
15.4.4 Power-On Reset
The power-on reset (POR) circuit clears the COP prescaler 4096
CGMXCLK cycles after power-up.
15.4.5 Internal Reset
An internal reset clears the COP prescaler and the COP counter.
15.4.6 Reset Vector Fetch
A reset vector fetch occurs when the vector address appears on the data
bus. A reset vector fetch clears the COP prescaler.
15.4.7 COPD
The COPD signal reflects the state of the COP disable bit (COPD) in the
configuration register. (See Configuration Register (CONFIG-1) on
page 197).
15.4.8 COPL
The COPL signal reflects the state of the COP rate select bit. (COPL) in
the configuration register. (See Configuration Register (CONFIG-1) on
page 197).
