Break Module (BRK)
Functional Description
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA Break Module (BRK) 205
13.4.1 Flag Protection During Break Interrupts
The BCFE bit in the break flag control register (BFCR) enables software
to clear status bits during the break state.
Register Name Bit 7654321Bit 0
Break Address Register High
(BRKH)
Read:
Bit 15 14 13 12 11 10 9 Bit 8
Write:
Reset:00000000
Break Address Register Low
(BRKL)
Read:
Bit 7654321Bit 0
Write:
Reset:00000000
Break Status and Control Register
(BSCR)
Read:
BRKE BRKA
000000
Write:
Reset:00000000
= Unimplemented R = Reserved
Figure 13-2. I/O Register Summary
Table 13-1. I/O Register Address Summary
Register BRKH BRKL BSCR
Address $FE0C $FE0D $FE0E
Break Module (BRK)
Technical Data MC68HC908AZ60A — Rev 2.0
206 Break Module (BRK) MOTOROLA
13.4.2 CPU During Break Interrupts
The CPU starts a break interrupt by:
Loading the instruction register with the SWI instruction
Loading the program counter with $FFFC:$FFFD ($FEFC:$FEFD
in monitor mode)
The break interrupt begins after completion of the CPU instruction in
progress. If the break address register match occurs on the last cycle of
a CPU instruction, the break interrupt begins immediately.
13.4.3 TIM During Break Interrupts
A break interrupt stops the timer counter.
13.4.4 COP During Break Interrupts
The COP is disabled during a break interrupt when V
Hi
is present on the
RST
pin.
13.5 Low-Power Modes
The WAIT and STOP instructions put the MCU in low power-consump-
tion standby modes.
13.5.1 Wait Mode
If enabled, the break module is active in wait mode. The SIM break wait
bit (BW) in the SIM break status register indicates whether wait was
exited by a break interrupt. If so, the user can modify the return address
on the stack by subtracting one from it. (See SIM Break Status Register
on page 166).
Break Module (BRK)
Break Module Registers
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA Break Module (BRK) 207
13.5.2 Stop Mode
The break module is inactive in stop mode. The STOP instruction does
not affect break module register states.
13.6 Break Module Registers
These registers control and monitor operation of the break module:
Break address register high (BRKH)
Break address register low (BRKL)
Break status and control register (BSCR)
13.6.1 Break Status and Control Register
The break status and control register contains break module enable and
status bits.
BRKE — Break Enable Bit
This read/write bit enables breaks on break address register matches.
Clear BRKE by writing a logic 0 to bit 7. Reset clears the BRKE bit.
1 = Breaks enabled on 16-bit address match
0 = Breaks disabled on 16-bit address match
Address: $FE0E
Bit 7654321Bit 0
Read:
BRKE BRKA
000000
Write:
Reset:00000000
= Unimplemented
Figure 13-3. Break Status and Control Register (BSCR)
