EEPROM-2 Memory
EEPROM-2 Register Descriptions
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA EEPROM-2 Memory 125
EEDIVSECD — EEPROM-2 Divider Security Disable
This bit enables/disables the security feature of the EE2DIV registers.
When EE2DIV security feature is enabled, the state of the registers
EE2DIVH and EE2DIVL are locked (including EEDIVSECD bit). The
EE2DIVHNVR and EE2DIVLNVR non-volatile memory registers are
also protected from being erased/programmed.
1 = EE2DIV security feature disabled
0 = EE2DIV security feature enabled
EEDIV[10:0] — EEPROM-2 timebase prescaler
These prescaler bits store the value of EE2DIV which is used as the
divisor to derive a timebase of 35µs from the selected reference clock
source (CGMXCLK or bus block in the CONFIG-2 register) for the
EEPROM-2 related internal timer and circuits. EEDIV[10:0] bits are
readable at any time. They are writable when EELAT = 0 and
EEDIVSECD = 1.
The EE2DIV value is calculated by the following formula:
EE2DIV= INT[Reference Frequency(Hz) x 35 x10
-6
+0.5]
Where the result inside the bracket is rounded down to the nearest
integer value
For example, if the reference frequency is 4.9152MHz, the EE2DIV
value is 172
NOTE: Programming/erasing the EEPROM with an improper EE2DIV value
may result in data lost and reduce endurance of the EEPROM device.
