Section 2. Memory Map
2.1 Contents
2.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
2.3 I/O Section. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
2.4 Additional Status and Control Registers . . . . . . . . . . . . . . .58
2.5 Vector Addresses and Priority . . . . . . . . . . . . . . . . . . . . . . .61
2.2 Introduction
The CPU08 can address 64K bytes of memory space. The memory
map, shown in Figure 2-1, includes:
• 60K Bytes of FLASH EEPROM
• 2048 Bytes of RAM
• 1024 Bytes of EEPROM with Protect Option
• 52 Bytes of User-Defined Vectors
• 256 Bytes of Monitor ROM
The following definitions apply to the memory map representation of
reserved and unimplemented locations.
• Reserved — Accessing a reserved location can have
unpredictable effects on MCU operation.
• Unused — These locations are reserved in the memory map for
future use, accessing an unused location can have unpredictable
effects on MCU operation.
