PTF0/TACH2
General-Purpose I/O
Timer A Channel 2
Dual State Yes Input Hi-Z
PTG2/KBD2–PTG0/KBD0
General-Purpose I/O/
Keyboard Wakeup
Pin
Dual State Yes Input Hi-Z
PTH1/KBD4 –PTH0/KBD3
General-Purpose I/O/
Keyboard Wakeup
Pin
Dual State Yes Input Hi-Z
V
DD
Chip Power Supply N/A N/A N/A
V
SS
Chip Ground N/A N/A N/A
V
DDA
CGM Analog Power
Supply
V
SSA
CGM Analog Ground
V
DDAREF
ADC Power Supply N/A N/A N/A
A
VSS
/V
REFL
ADC Ground/ADC
Reference Low
Voltage
N/A N/A N/A
V
REFH
A/D Reference High
Voltage
N/A N/A N/A
OSC1 External Clock In N/A N/A Input Hi-Z
OSC2 External Clock Out N/A N/A Output
CGMXFC PLL Loop Filter Cap N/A N/A N/A
IRQ
External Interrupt
Request
N/A N/A Input Hi-Z
RST
Reset N/A N/A Output Low
CANRx CAN Serial Input N/A Yes Input Hi-Z
CANTx CAN Serial Output Output No Output
BDRxD BDLC Serial Input N/A Yes Input Hi-Z
BDTxD BDLC Serial Output Output No Output
1. Hysteresis is not 100% tested but is typically a minimum of 300mV.
Table 1-1. External Pins Summary (Continued)
Pin Name Function
Driver
Type
Hysteresis
(1)
Reset State
