General Description
Pin Assignments
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA General Description 43
1.5.14 Port D I/O Pins (PTD7–PTD0/ATD8)
Port D is an 8-bit special-function port that shares seven of its pins with
the Analog-to-Digital Converter module (ADC-15), one of its pins with
the Timer Interface Module A (TIMA), and one more of its pins with the
Timer Interface Module B (TIMB). See Timer Interface Module A
(TIMA) on page 441, Timer Interface Module B (TIMB) on page 317,
Analog-to-Digital Converter (ADC) on page 471 and Input/Output
Ports on page 353.
1.5.15 Port E I/O Pins (PTE7/SPSCK–PTE0/TxD)
Port E is an 8-bit special function port that shares two of its pins with the
Timer Interface Module A (TIMA), four of its pins with the Serial
Peripheral Interface module (SPI), and two of its pins with the Serial
Communication Interface module (SCI). See Serial Communications
Interface (SCI) on page 243, Serial Peripheral Interface (SPI) on page
285, Timer Interface Module A (TIMA) on page 441, and Input/Output
Ports on page 353.
1.5.16 Port F I/O Pins (PTF6–PTF0/TACH2)
Port F is a 7-bit special function port that shares its pins with the Timer
Interface Module B (TIMB). Six of its pins are shared with the Timer
Interface Module A (TIMA-6). See Timer Interface Module A (TIMA) on
page 441, Timer Interface Module B (TIMB) on page 317, and
Input/Output Ports on page 353.
1.5.17 Port G I/O Pins (PTG2/KBD2–PTG0/KBD0)
Port G is a 3-bit special function port that shares all of its pins with the
Keyboard Module (KBD). See Keyboard Module (KBD) on page 431
and Input/Output Ports on page 353.
General Description
Technical Data MC68HC908AZ60A — Rev 2.0
44 General Description MOTOROLA
1.5.18 Port H I/O Pins (PTH1/KBD4–PTH0/KBD3)
Port H is a 2-bit special-function port that shares all of its pins with the
Keyboard Module (KBD). See Keyboard Module (KBD) on page 431
and Input/Output Ports on page 353.
1.5.19 CAN Transmit Pin (CANTx)
This pin is the digital output from the CAN module (CANTx). See
MSCAN Controller (MSCAN08) on page 379.
1.5.20 CAN Receive Pin (CANRx)
This pin is the digital input to the CAN module (CANRx). See MSCAN
Controller (MSCAN08) on page 379.
1.5.21 BDLC Transmit Pin (BDTxD)
This pin is the digital output from the BDLC module (BDTxD). See Byte
Data Link Controller (BDLC) on page 483.
1.5.22 BDLC Receive Pin (BDRxD)
This pin is the digital input to the CAN module (BDRxD). See Byte Data
Link Controller (BDLC) on page 483.
Table 1-1. External Pins Summary
Pin Name Function
Driver
Type
Hysteresis
(1)
Reset State
PTA7–PTA0 General-Purpose I/O Dual State No Input Hi-Z
PTB7/ATD7–PTB0/ATD0
General-Purpose I/O
ADC Channel
Dual State No Input Hi-Z
PTC5–PTC0 General-Purpose I/O Dual State No Input Hi-Z
PTD7 General Purpose I/O Dual State No Input Hi-Z
General Description
Pin Assignments
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA General Description 45
PTD6/ATD14/TACLK ADC Channel
General-Purpose I/O
ADC Channel/Timer
External Input Clock
Dual State No Input Hi-Z
PTD5/ATD13 ADC Channel
General-Purpose I/O
ADC Channel
Dual State No Input Hi-Z
PTD4/ATD12/TBCLK ADC Channel
General-Purpose I/O
ADC Channel/Timer
External Input Clock
Dual State No Input Hi-Z
PTD3/ATD11–PTD0/ATD8 ADC Channels
General-Purpose I/O
ADC Channel
Dual State No Input Hi-Z
PTE7/SPSCK
General-Purpose I/O
SPI Clock
Dual State
Open Drain
Yes Input Hi-Z
PTE6/MOSI
General-Purpose I/O
SPI Data Path
Dual State
Open Drain
Yes Input Hi-Z
PTE5/MISO
General-Purpose I/O
SPI Data Path
Dual State
Open Drain
Yes Input Hi-Z
PTE4/SS
General-Purpose I/O
SPI Slave Select
Dual State Yes Input Hi-Z
PTE3/TACH1
General-Purpose I/O
Timer A Channel 1
Dual State Yes Input Hi-Z
PTE2/TACH0
General-Purpose I/O
Timer A Channel 0
Dual State Yes Input Hi-Z
PTE1/RxD
General-Purpose I/O
SCI Receive Data
Dual State Yes Input Hi-Z
PTE0/TxD
General-Purpose I/O
SCI Transmit Data
Dual State No Input Hi-Z
PTF6 General-Purpose I/O Dual State No Input Hi-Z
PTF5/TBCH1–PTF4/TBCH0
General-Purpose
I/O/Timer B Channel
Dual State Yes Input Hi-Z
PTF3/TACH5
General-Purpose I/O
Timer A Channel 5
Dual State Yes Input Hi-Z
PTF2/TACH4
General-Purpose I/O
Timer A Channel 4
Dual State Yes Input Hi-Z
PTF1/TACH3
General-Purpose I/O
Timer A Channel 3
Dual State Yes Input Hi-Z
Table 1-1. External Pins Summary (Continued)
Pin Name Function
Driver
Type
Hysteresis
(1)
Reset State
