Serial Peripheral Interface (SPI)
I/O Registers
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA Serial Peripheral Interface (SPI) 313
SPRF — SPI Receiver Full Bit
This clearable, read-only flag is set each time a byte transfers from
the shift register to the receive data register. SPRF generates a CPU
interrupt request if the SPRIE bit in the SPI control register is set also.
During an SPRF CPU interrupt, the CPU clears SPRF by reading the
SPI status and control register with SPRF set and then reading the
SPI data register. Any read of the SPI data register clears the SPRF
bit.
Reset clears the SPRF bit.
1 = Receive data register full
0 = Receive data register not full
ERRIE — Error Interrupt Enable Bit
This read-only bit enables the MODF and OVRF flags to generate
CPU interrupt requests. Reset clears the ERRIE bit.
1 = MODF and OVRF can generate CPU interrupt requests
0 = MODF and OVRF cannot generate CPU interrupt requests
OVRF — Overflow Bit
This clearable, read-only flag is set if software does not read the byte
in the receive data register before the next byte enters the shift
register. In an overflow condition, the byte already in the receive data
register is unaffected, and the byte that shifted in last is lost. Clear the
OVRF bit by reading the SPI status and control register with OVRF set
and then reading the SPI data register. Reset clears the OVRF flag.
1 = Overflow
0 = No overflow
Address: $0011
Bit 7654321Bit 0
Read: SPRF
ERRIE
OVRF MODF SPTE
MODFEN SPR1 SPR0
Write:
Reset:00001000
R= Reserved
= Unimplemented
Figure 19-12. SPI Status and Control Register (SPSCR)
Serial Peripheral Interface (SPI)
Technical Data MC68HC908AZ60A — Rev 2.0
314 Serial Peripheral Interface (SPI) MOTOROLA
MODF — Mode Fault Bit
This clearable, read-only flag is set in a slave SPI if the SS pin goes
high during a transmission. In a master SPI, the MODF flag is set if
the SS pin goes low at any time. Clear the MODF bit by reading the
SPI status and control register with MODF set and then writing to the
SPI data register. Reset clears the MODF bit.
1 = SS pin at inappropriate logic level
0 = SS
pin at appropriate logic level
SPTE — SPI Transmitter Empty Bit
This clearable, read-only flag is set each time the transmit data
register transfers a byte into the shift register. SPTE generates an
SPTE CPU interrupt request if the SPTIE bit in the SPI control register
is set also.
NOTE: Do not write to the SPI data register unless the SPTE bit is high.
For an idle master or idle slave that has no data loaded into its
transmit buffer, the SPTE will be set again within two bus cycles since
the transmit buffer empties into the shift register. This allows the user
to queue up a 16-bit value to send. For an already active slave, the
load of the shift register cannot occur until the transmission is
completed. This implies that a back-to-back write to the transmit data
register is not possible. The SPTE indicates when the next write can
occur.
Reset sets the SPTE bit.
1 = Transmit data register empty
0 = Transmit data register not empty
MODFEN — Mode Fault Enable Bit
This read/write bit, when set to 1, allows the MODF flag to be set. If
the MODF flag is set, clearing the MODFEN does not clear the MODF
flag. If the SPI is enabled as a master and the MODFEN bit is low,
then the SS pin is available as a general-purpose I/O.
If the MODFEN bit is set, then this pin is not available as a general
purpose I/O. When the SPI is enabled as a slave, the SS pin is not
available as a general-purpose I/O regardless of the value of
MODFEN. (See SS (Slave Select) on page 308).
Serial Peripheral Interface (SPI)
I/O Registers
MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA Serial Peripheral Interface (SPI) 315
If the MODFEN bit is low, the level of the SS pin does not affect the
operation of an enabled SPI configured as a master. For an enabled
SPI configured as a slave, having MODFEN low only prevents the
MODF flag from being set. It does not affect any other part of SPI
operation. (See Mode Fault Error on page 299).
SPR1 and SPR0 — SPI Baud Rate Select Bits
In master mode, these read/write bits select one of four baud rates as
shown in Table 19-6. SPR1 and SPR0 have no effect in slave mode.
Reset clears SPR1 and SPR0.
Use this formula to calculate the SPI baud rate:
where:
CGMOUT = base clock output of the clock generator module (CGM),
see Clock Generator Module (CGM) on page 169.
BD = baud rate divisor
Table 19-6. SPI Master Baud Rate Selection
SPR1:SPR0 Baud Rate Divisor (BD)
00 2
01 8
10 32
11 128
Baud rate
CGMOUT
2BD×
--------------------------=
PREVIOUS9899100101102103104105106107108109110111NEXT
