MC68HC908AZ60A — Rev 2.0 Technical Data

MOTOROLA General Description 31

Technical Data — MC68HC908AZ60A

Section 1. General Description

1.1 Contents

1.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

1.3 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

1.4 MCU Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

1.5 Pin Assignments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

1.5.1 Power Supply Pins (V

and V

) . . . . . . . . . . . . . . . . . .40

1.5.2 Oscillator Pins (OSC1 and OSC2). . . . . . . . . . . . . . . . . . .41

1.5.3 External Reset Pin (RST) . . . . . . . . . . . . . . . . . . . . . . . . . .41

1.5.4 External Interrupt Pin (IRQ) . . . . . . . . . . . . . . . . . . . . . . . .41

1.5.5 Analog Power Supply Pin (V

DDA

) . . . . . . . . . . . . . . . . . . .41

1.5.6 Analog Ground Pin (V

SSA

). . . . . . . . . . . . . . . . . . . . . . . . .41

1.5.7 External Filter Capacitor Pin (CGMXFC) . . . . . . . . . . . . .41

1.5.8 ADC Analog Power Supply Pin (VDDAREF) . . . . . . . . . .42

1.5.9 ADC Analog Ground Pin (AVSS/VREFL) . . . . . . . . . . . . .42

1.5.10 ADC Reference High Voltage Pin (VREFH) . . . . . . . . . . .42

1.5.11 Port A Input/Output (I/O) Pins (PTA7–PTA0) . . . . . . . . . .42

1.5.12 Port B I/O Pins (PTB7/ATD7–PTB0/ATD0) . . . . . . . . . . . .42

1.5.13 Port C I/O Pins (PTC5–PTC0) . . . . . . . . . . . . . . . . . . . . . .42

1.5.14 Port D I/O Pins (PTD7–PTD0/ATD8) . . . . . . . . . . . . . . . . .43

1.5.15 Port E I/O Pins (PTE7/SPSCK–PTE0/TxD) . . . . . . . . . . . .43

1.5.16 Port F I/O Pins (PTF6–PTF0/TACH2). . . . . . . . . . . . . . . . .43

1.5.17 Port G I/O Pins (PTG2/KBD2–PTG0/KBD0) . . . . . . . . . . .43

1.5.18 Port H I/O Pins (PTH1/KBD4–PTH0/KBD3). . . . . . . . . . . .44

1.5.19 CAN Transmit Pin (CANTx) . . . . . . . . . . . . . . . . . . . . . . . .44

1.5.20 CAN Receive Pin (CANRx). . . . . . . . . . . . . . . . . . . . . . . . .44

1.5.21 BDLC Transmit Pin (BDTxD) . . . . . . . . . . . . . . . . . . . . . . .44

1.5.22 BDLC Receive Pin (BDRxD) . . . . . . . . . . . . . . . . . . . . . . .44

1.6 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

1.6.1 MC Order Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

General Description

Technical Data MC68HC908AZ60A — Rev 2.0

32 General Description MOTOROLA

1.2 Introduction

The MC68HC908AS60A and MC68HC908AZ60A are members of the

low-cost, high-performance M68HC08 Family of 8-bit microcontroller

units (MCUs). The M68HC08 Family is based on the customer-specified

integrated circuit (CSIC) design strategy. All MCUs in the family use the

enhanced M68HC08 central processor unit (CPU08) and are available

with a variety of modules, memory sizes and types, and package types.

These parts are designed to emulate the MC68HC08ASxx and

MC68HC08AZxx automotive families and may offer extra features which

are not available on those devices. It is the user’s responsibility to ensure

compatibility between the features used on the MC68HC908AS60A and

MC68HC908AZ60A and those which are available on the device which

will ultimately be used in the application.

1.3 Features

Features of the MC68HC908AS60A and MC68HC908AZ60A include:

• High-Performance M68HC08 Architecture

• Fully Upward-Compatible Object Code with M6805, M146805,

and M68HC05 Families

• 8.4 MHz Internal Bus Frequency

• 60 Kbytes of FLASH Electrically Erasable Read-Only Memory

(FLASH)

• FLASH Data Security

• 1 Kbyte of On-Chip Electrically Erasable Programmable Read-

Only Memory with Security Option (EEPROM)

• 2 Kbyte of On-Chip RAM

• Clock Generator Module (CGM)

• Serial Peripheral Interface Module (SPI)

• Serial Communications Interface Module (SCI)

• 8-Bit, 15-Channel Analog-to-Digital Converter (ADC-15)

General Description

Features

MC68HC908AZ60A — Rev 2.0 Technical Data

MOTOROLA General Description 33

• 16-Bit, 6-Channel Timer Interface Module (TIMA-6)

• Programmable Interrupt Timer (PIT)

• System Protection Features

– Computer Operating Properly (COP) with Optional Reset

– Low-Voltage Detection with Optional Reset

– Illegal Opcode Detection with Optional Reset

– Illegal Address Detection with Optional Reset

• Low-Power Design (Fully Static with Stop and Wait Modes)

• Master Reset Pin and Power-On Reset

• 16-Bit, 2-Channel Timer Interface Module (TIMB) (AZ only)

• 5-Bit Keyboard Interrupt Module (64-Pin QFP only)

• MSCAN Controller (Motorola Scalable CAN) implements CAN

2.0b Protocol as Defined in BOSCH Specification September

1991 (AZ only)

• SAE J1850 Byte Data Link Controller Digital Module (AS only)

Features of the CPU08 include:

• Enhanced HC05 Programming Model

• Extensive Loop Control Functions

• 16 Addressing Modes (Eight More Than the HC05)

• 16-Bit Index Register and Stack Pointer

• Memory-to-Memory Data Transfers

•Fast 8 × 8 Multiply Instruction

• Fast 16/8 Divide Instruction

• Binary-Coded Decimal (BCD) Instructions

• Optimization for Controller Applications

• C Language Support
