MC68HC908AZ60A — Rev 2.0 Technical Data
MOTOROLA List of Paragraphs 5
Technical Data — MC68HC908AZ60A
List of Paragraphs
Section 1. General Description . . . . . . . . . . . . . . . . . . . . 31
Section 2. Memory Map . . . . . . . . . . . . . . . . . . . . . . . . . .49
Section 3. RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Section 4. FLASH-1 Memory . . . . . . . . . . . . . . . . . . . . . . 65
Section 5. FLASH-2 Memory . . . . . . . . . . . . . . . . . . . . . . 77
Section 6. EEPROM-1 Memory. . . . . . . . . . . . . . . . . . . . .89
Section 7. EEPROM-2 Memory. . . . . . . . . . . . . . . . . . . . 109
Section 8. Central Processor Unit (CPU) . . . . . . . . . . . 129
Section 9. System Integration Module (SIM) . . . . . . . . 147
Section 10. Clock Generator Module (CGM). . . . . . . . . 169
Section 11. Configuration Register (CONFIG-1). . . . . . 197
Section 12. Configuration Register (CONFIG-2). . . . . . 201
Section 13. Break Module (BRK) . . . . . . . . . . . . . . . . . . 203
Section 14. Monitor ROM (MON) . . . . . . . . . . . . . . . . . . 209
Section 15. Computer Operating Properly (COP) . . . . 223
Section 16. Low Voltage Inhibit (LVI) . . . . . . . . . . . . . . 229
Section 17. External Interrupt Module (IRQ). . . . . . . . . 235
Section 18. Serial Communications Interface (SCI). . .243
Section 19. Serial Peripheral Interface (SPI). . . . . . . . . 285
Section 20. Timer Interface Module B (TIMB) . . . . . . . . 317
