TPS5430DDA

Part # TPS5430DDA
Description 5.5V -36V INPUT, 3-A STEP DOWN CONVERTER - Rail/Tube
Category IC
Availability Out of Stock
Qty 0
Qty Price
1 + $3.02424



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

www.ti.com
PIN ASSIGNMENTS
1
2
3
4
8
7
6
5
PowerPAD
(Pin 9)
BOOT
NC
NC
VSENSE
PH
VIN
GND
ENA
DDA PACKAGE
(TOP VIEW)
TPS5430
SLVS632 JANUARY 2006
TERMINAL FUNCTIONS
TERMINAL
DESCRIPTION
NAME NO.
BOOT 1 Boost capacitor for the high-side FET gate driver. Connect 0.01 µ F low ESR capacitor from BOOT pin to PH pin.
NC 2, 3 Not connected internally.
VSENSE 4 Feedback voltage for the regulator. Connect to output voltage divider.
ENA 5 On/off control. Below 0.5 V, the device stops switching. Float the pin to enable.
GND 6 Ground. Connect to PowerPAD.
Input supply voltage. Bypass VIN pin to GND pin close to device package with a high quality, low ESR ceramic
VIN 7
capacitor.
PH 8 Source of the high side power MOSFET. Connected to external inductor and diode.
PowerPAD 9 GND pin must be connected to the exposed pad for proper operation.
4
www.ti.com
TYPICAL CHARACTERISTICS
460
470
480
490
500
510
520
530
50 25 0 25 50 75 100 125
f Oscillator Frequency kHz
T Junction Temperature °C
2.5
2.75
3
3.25
3.5
50 25 0 25 50 75 100 125
T
J
Junction Temperature °C
I
Q
Quiescent Current mA
5
10
15
20
25
0 5 10 15 20 25 30 35 40
T
J
= 125
°C
T
J
= 27°C
T
J
=
°40 C
ENA = 0 V
V
I
Input V oltage V
I
SD
Shutdown Current
Aµ
7
7.5
8
8.5
9
50 25 0 25 50 75 100 125
T
J
Junction Temperature °C
T
SS
Internal Slow Start Time ms
80
90
100
110
120
130
140
150
160
170
180
50 25 0 25 50 75 100 125
mOn Resistance
r
DS(on)
T
J
Junction Temperature °C
V
I
= 12 V
TPS5430
SLVS632 JANUARY 2006
OSCILLATOR FREQUENCY NON-SWITCHING QUIESCENT CURRENT
vs vs
JUNCTION TEMPERATURE JUNCTION TEMPERATURE
Figure 1. Figure 2.
SHUTDOWN QUIESCENT CURRENT VOLTAGE REFERENCE
vs vs
INPUT VOLTAGE JUNCTION TEMPERATURE
Figure 3. Figure 4.
ON RESISTANCE INTERNAL SLOW START TIME
vs vs
JUNCTION TEMPERATURE JUNCTION TEMPERATURE
Figure 5. Figure 6.
5
www.ti.com
7
7.25
7.50
7.75
8
-50 -25 0 25
50
75 100 125
T - Junction Temperature - °C
J
Minimum Duty Ratio - %
120
130
140
150
160
170
180
50 25 0 25 50 75 100 125
T
J
Junction Temperature °C
Minimum Controllable On Time ns
TPS5430
SLVS632 JANUARY 2006
TYPICAL CHARACTERISTICS (continued)
MINIMUM CONTROLLABLE ON TIME MINIMUM CONTROLLABLE DUTY RATIO
vs vs
JUNCTION TEMPERATURE JUNCTION TEMPERATURE
Figure 7. Figure 8.
6
