TPS5430DDA

Part # TPS5430DDA
Description 5.5V -36V INPUT, 3-A STEP DOWN CONVERTER - Rail/Tube
Category IC
Availability Out of Stock
Qty 0
Qty Price
1 + $3.02424



Technical Document


DISCLAIMER: The information provided herein is solely for informational purposes. Customers must be aware of the suitability of this product for their application, and consider that variable factors such as Manufacturer, Product Category, Date Codes, Pictures and Descriptions may differ from available inventory.

www.ti.com
FEATURES APPLICATIONS
DESCRIPTION
SIMPLIFIED SCHEMATIC
VIN
NC
NC
ENA
GND
VSENSE
BOOT
PH
TPS5430
VIN VOUT
50
55
60
65
70
75
80
85
90
95
100
0 0.5 1 1.5 2 2.5 3 3.5
Efficiency %
I
O
Output Current A
V = 12 V,
V = 5 V,
fs = 500 kHz
I
0
Efficiency vs Output Current
TPS5430
SLVS632 JANUARY 2006
5.5-V to 36-V, 3-A STEP-DOWN SWIFT™ CONVERTER
Consumer: Set-top Box, DVD, LCD Displays
Wide Input Voltage Range: 5.5 V to 36 V
Industrial and Car Audio Power Supplies
Up to 3-A Continuous (4-A Peak) Output
Battery Chargers, High Power LED Supply
Current
12V/24V Distributed Power Systems
High Efficiency up to 95% Enabled by 110-m
Integrated MOSFET Switch
Wide Output Voltage Range: Adjustable Down
to 1.22 V with 1.5% Initial Accuracy
As a member of the SWIFT™ family of DC/DC
regulators, the TPS5430 is a high-output-current
Internal Compensation Minimizes External
PWM converter that integrates a low resistance high
Parts Count
side N-channel MOSFET. Included on the substrate
Fixed 500 kHz Switching Frequency for Small
with the listed features are a high performance
Filter Size
voltage error amplifier that provides tight voltage
regulation accuracy under transient conditions; an
Improved Line Regulation and Transient
under-voltage-lockout circuit to prevent start-up until
Response by Input Voltage Feed Forward
the input voltage reaches 5.5V; an internally set
System Protected by Over Current Limiting
slow-start circuit to limit inrush currents; and a voltage
and Thermal Shutdown
feed-forward circuit to improve the transient
–40 ° C to 125 ° C Operating Junction
response. Other features include an active high
Temperature Range
enable, over current protection and thermal
shutdown. To reduce design complexity and external
Available in Small Thermally Enhanced 8-Pin
component count, the TPS5430 feedback loop is
SOIC PowerPAD™ Package
internally compensated.
For SWIFT Documentation, Application Notes
The TPS5430 device is available in a thermally
and Design Software, See the TI Website at
enhanced, easy to use 8-pin SOIC PowerPAD™
www.ti.com/swift
package. TI provides evaluation modules and the
SWIFT™ Designer software tool to aid in quickly
achieving high-performance power supply designs to
meet aggressive equipment development cycles.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
SWIFT, PowerPAD are trademarks of Texas Instruments.
PRODUCTION DATA information is current as of publication date.
Copyright © 2006, Texas Instruments Incorporated
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
www.ti.com
ABSOLUTE MAXIMUM RATINGS
DISSIPATION RATINGS
(1) (2)
RECOMMENDED OPERATING CONDITIONS
TPS5430
SLVS632 JANUARY 2006
These devices have limited built-in ESD protection. The leads should be shorted together or the device
placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
ORDERING INFORMATION
T
J
OUTPUT VOLTAGE PACKAGE PART NUMBER
–40 ° C to 125 ° C Adjustable to 1.22 V Thermally Enhanced SOIC (DDA)
(1)
TPS5430DDA
(1) The DDA package is also available taped and reeled. Add an R suffix to the device type (i.e., TPS5430DDAR). See applications section
of data sheet for PowerPAD™ drawing and layout information.
over operating free-air temperature range (unless otherwise noted)
(1) (2)
VALUE UNIT
VIN –0.3 to 38
ENA –0.3 to 7
VSENSE –0.3 to 3
V
I
Input voltage range BOOT –0.3 to 48 V
BOOT-PH 10
PH (steady-state) –0.6 to 38
PH (transient < 10 ns) –1.2
I
O
Source current PH Internally Limited
I
O
Leakage current PH 10 µ A
T
J
Operating virtual junction temperature range –40 to 125 ° C
T
STG
Storage temperature –65 to 150 ° C
Lead temperature 1,6 mm (1/16-inch) from case for 10 seconds 300 ° C
(1) Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) All voltage values are with respect to network ground terminal.
PACKAGE THERMAL IMPEDANCE
JUNCTION-TO-AMBIENT
8 Pin DDA (2-layer board with solder)
(3)
33 ° C/W
8 Pin DDA (4-layer board with solder)
(4)
26 ° C/W
(1) Maximum power dissipation may be limited by overcurrent protection.
(2) Power rating at a specific ambient temperature T
A
should be determined with a junction temperature of 125 ° C. This is the point where
distortion starts to substantially increase. Thermal management of the final PCB should strive to keep the junction temperature at or
below 125 ° C for best performance and long-term reliability. See Thermal Calculations in applications section of this data sheet for more
information.
(3) Test board conditions:
a. 3 in x 3 in, 2 layers, thickness: 0.062 inch.
b. 2 oz. copper traces located on the top and bottom of the PCB.
c. 6 thermal vias in the PowerPAD area under the device package.
(4) Test board conditions:
a. 3 in x 3 in, 4 layers, thickness: 0.062 inch.
b. 2 oz. copper traces located on the top and bottom of the PCB.
c. 2 oz. copper ground planes on the 2 internal layers.
d. 6 thermal vias in the PowerPAD area under the device package.
MIN NOM MAX UNIT
VIN Input voltage range 5.5 36 V
T
J
Operating junction temperature –40 125 ° C
2
www.ti.com
ELECTRICAL CHARACTERISTICS
TPS5430
SLVS632 JANUARY 2006
T
J
= –40 ° C to 125 ° C, VIN = 5.5 V to 36.0 V (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
SUPPLY VOLTAGE (VIN PIN)
VIN Input voltage range 5.5 36 V
VSENSE = 2 V, Not switching, PH pin
3 4.4 mA
open
I
Q
Quiescent current
Shutdown, ENA = 0 V 18 50 µ A
UNDER VOLTAGE LOCK OUT (UVLO)
Start threshold voltage, UVLO 5.3 5.5 V
Hysteresis voltage, UVLO 330 mV
VOLTAGE REFERENCE
T
J
= 25 ° C 1.202 1.221 1.239
Voltage reference accuracy V
Io = 0 A 3 A 1.196 1.221 1.245
OSCILLATOR
Internally set free-running frequency 400 500 600 kHz
Minimum controllable on time 150 200 ns
Maximum duty cycle 87 89 %
ENABLE (ENA PIN)
Start threshold voltage, ENA 1.3 V
Stop threshold voltage, ENA 0.5 V
Hysteresis voltage, ENA 450 mV
Internal slow-start time (0~100%) 6.6 8 10 ms
CURRENT LIMIT
Current limit 4.0 5.0 6.0 A
Current limit hiccup time 13 16 20 ms
THERMAL SHUTDOWN
Thermal shutdown trip point 135 162 ° C
Thermal shutdown hysteresis 14 ° C
OUTPUT MOSFET
VIN = 5.5 V 150
R
DS-ON
High side power MOSFET switch m
VIN = 10 V 36 V 110 230
3
