TIBPAL22V10C, TIBPAL22V10AC
HIGH-PERFORMANCE IMPACT PROGRAMMABLE ARRAY LOGIC CIRCUITS
SRPS024 – D2943, OCTOBER 1986 – REVISED MARCH 1992
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
9
electrical characteristics over recommended operating free-air temperature range
TIBPAL22V10C TIBPAL22V10AC
MIN TYP
†
MAX MIN TYP
†
MAX
V
IK
V
CC
= 4.75 V, I
I
= –18 mA –1.2 –1.2 V
V
OH
V
CC
= 4.75 V, I
OH
= –3.2 mA 2.4 3.5 2.4 3.5 V
V
OL
V
CC
= 4.75 V, I
OL
= 16 mA 0.35 0.5 0.35 0.5 V
I
OZH
V
CC
= 5.25 V, V
O
= 2.7 V 0.1 0.1 mA
Any output –100 –100
Any I/O –250 –250
I
I
V
CC
= 5.25 V, V
I
= 5.5 V 1 1 mA
I
IH
V
CC
= 5.25 V, V
I
= 2.7 V 25 25 µA
I
IL
V
CC
= 5.25 V, V
I
= 0.4 V –0.25 –0.25 mA
I
OS
‡
V
CC
= 5.25 V, V
O
= 0.5 V –30 –90 –30 –90 mA
I
CC
V
CC
= 5.25 V, V
I
= GND, Outputs open 120 180 120 180 mA
switching characteristics over recommended ranges of supply voltage and operating free-air
temperature (unless otherwise noted)
FROM TO TIBPAL22V10C TIBPAL22V10AC
(INPUT) (OUTPUT) MIN TYP
†
MAX MIN TYP
†
MAX
f
max
¶
With feedback 18 28.5 MHz
t
pd
I, I/O I/O R1 = 300 Ω, 15 35 15 25 ns
t
pd
I, I/O (reset) Q R2 = 390 Ω, 15 40 15 30 ns
t
pd
CLK Q See Figure 4 10 25 10 15 ns
t
en
I, I/O I/O, Q 15 35 15 25 ns
t
dis
I, I/O I/O, Q 15 35 15 25 ns
†
All typical values are at V
CC
= 5 V, T
A
= 25°C.
‡
Not more than one output should be shorted at a time, and the duration of the short circuit should not exceed one second. V
O
is set at 0.5 V to
avoid test problems caused by test equipment ground degradation.
¶
f
max
(with feedback) =
1
t
su
t
pd
(CLK to Q)
, f
max
(without feedback) =
1
t
w
(low) t
w
(high)
